User's Manual
3308440
EPIC ATOM SBC
Version 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3308440 and is the answer not in the manual?

Questions and answers

Related Manuals for Global American 3308440

Summary of Contents for Global American 3308440

  • Page 1 User’s Manual 3308440 EPIC ATOM SBC Version 1.0...
  • Page 2 Copyrights This document is copyrighted and all rights are reserved. It does not allow any non authorization in copied, photocopied, translated or reproduced to any electronic or machine readable form in whole or in part without prior written consent from the manufacturer.
  • Page 3 Packing List The items listed below should all be included in the 3308440 package. 1 x 3308440 Single Board Computer 2 x RS-232 cable (P/N: 32200-000049-RS) 2 x SATA Cable (P/N: 32000-062800-RS) 1 x KB/MS Cable (P/N: 32000-000138-RS) 1 x Power Cable (P/N: 32100-087100-RS)
  • Page 4 ..................VERVIEW H 3 4 4 1 .2.1 3308440 Overview Photo ................... H 4 4 4 1 .2.2 3308440 Peripheral Connectors and Jumpers............ H 5 4 4 1 .2.3 Technical Specifications..................H 6 4 4 DETAILED SPECIFICATIONS ................H 7 4 4 2 .1 D...
  • Page 5 ® 2 .5.4 Intel ICH7-M Low Pin Count (LPC) Interface ..........3 1 H 4 7 0 H ® 2 .5.5 Intel ICH7-M PCI Interface................3 2 H 4 7 1 H ® 2 .5.6 Intel ICH7-M PCIe Bus ................. 3 3 H 4 7 2 H 2 .5.6.1 PCIe GbE Ethernet..................
  • Page 6 4 .1.1 3308440 Layout....................H 4 6 H 3 0 5 4 .2 P ..............ERIPHERAL NTERFACE ONNECTORS H 5 6 H 4 0 5 4 .2.1 External Interface Panel Connectors............... H 6 6 H 5 0 5 4 .3 I ..............
  • Page 7 5 .2.1 Installation Notices ..................H 8 9 H 7 3 5 5 .2.2 Installation Checklist ..................H 9 9 H 8 3 5 5 .3 U ......................NPACKING H 0 0 1 H 9 3 5 5 .4 SO-DIMM CF C ..............
  • Page 8 BIOS SCREENS....................1 08 H 2 3 1 H 1 7 5 6 .1 I ...................... 1 09 NTRODUCTION H 3 3 1 H 2 7 5 6 .1.1 Starting Setup....................1 09 H 4 3 1 H 3 7 5 6 .1.2 Using Setup ....................
  • Page 9 7 .6 A ................1 71 UDIO RIVER NSTALLATION 1 6 6 H 6 0 5 H 7 .6.1 HD Audio Installation..................1 72 1 6 7 H 6 0 6 H 7 .6.2 AC’97 Driver Installation ................1 75 1 6 8 H 6 0 7 H BIOS MENU OPTIONS..................

  • Page 10: Table Of Contents

    List of Figures F igure 1-1: 3308440....................... H 5 8 1 H 4 2 6 F igure 1-2: 3308440 SBC Overview [Front View] ............H 6 8 1 H 5 2 6 F igure 1-3: 3308440 SBC Overview [Solder Side] ............
  • Page 11 F igure 4-11: Front Panel Connector Pinout Locations (8-pin) ....... H 3 1 2 H 2 5 6 F igure 4-12: Secondary IDE Device Connector Locations........H 4 1 2 H 3 5 6 F igure 4-13: Infrared Connector Pinout Locations ..........H 5 1 2 H 4 5 6 F igure 4-14: Keyboard/Mouse Connector Location..........
  • Page 12 F igure 5-15: IDE Cable Connection ................H 5 4 2 H 4 8 6 F igure 5-16: SATA Drive Cable Connection ............. H 6 4 2 H 5 8 6 F igure 5-17: SATA Power Drive Connection ............H 7 4 2 H 6 8 6 F igure 5-18: Single RS-232 Cable Installation............
  • Page 13 F igure 7-20: LAN Driver Installation Complete ............. 1 71 H 7 7 2 H 6 1 7 F igure 7-21: Audio Driver Options................1 72 H 8 7 2 H 7 1 7 F igure 7-22: Extract HD Audio Driver Installation Files ........1 73 H 9 7 2 H 8 1 7...
  • Page 14 List of Tables T able 1-1: Technical Specifications ................2 8 7 H 7 2 6 H T able 2-1: Supported HDD Specifications ..............2 8 8 H 7 2 7 H T able 2-2: Power Consumption ................. 2 8 9 H 7 2 8 H T able 4-1: Peripheral Interface Connectors..............
  • Page 15 T able 4-26: RJ-45 Ethernet Connector LEDs............H 5 1 3 H 4 5 7 T able 4-27: RS-232 Serial Port (COM 1) Pinouts ............H 6 1 3 H 5 5 7 T able 4-28: USB Port Pinouts ..................H 7 1 3 H 6 5 7 T able 4-29: VGA Connector Pinouts .................
  • Page 16 List of BIOS Menus M enu 1: Main......................1 11 3 2 9 H 7 6 8 H M enu 2: Advanced....................1 13 3 3 0 H 7 6 9 H M enu 3: CPU Configuration ..................1 14 3 3 1 H 7 7 0 H M enu 4: IDE Configuration ..................
  • Page 17 Chapter Introduction Page 1...
  • Page 20 Figure 1-3: 3308440 Overview [Solder Side] 1.2.2 3308440 SBC Peripheral Connectors and Jumpers The 3308440 has the following connectors on-board: 1 x +12V power source connector 1 x 5V power connector 1 x Audio connector 1 x ATX power control connector 2 x Backlight inverter connectors 1 x CompactFlash®...
  • Page 21 1 x RS-232/422/485 serial port connector 1 x TV Out connector 2 x USB 2.0 connectors (supports four USB 2.0 devices) The 3308440 SBC has the following external peripheral interface connectors on the board rear panel. 2 x Ethernet connectors...
  • Page 22 Front Side Bus (FSB) 533 MHz Northbridge: Intel® 945GSE System Chipset Southbridge: Intel® ICH7-M One 200-pin SO-DIMM socket supports one 533 MHz 2.0 Memory GB (max.) DDR2 SDRAM SO-DIMM CompactFlash® One CompactFlash® Type II socket Super I/O ITE IT8718 Intel® Generation 3.5 integrated GFX core (133 MHz) HDTV with 1080i maximum resolution supported Dual LVDS support Display...
  • Page 23 SATA Two 1.5 Gbps SATA drives supported Keyboard/mouse One external PS/2 connector One 26-pin parallel port connector Parallel Port One PCI-104 expansion slot (PCI bus) Expansion One PCIe mini card (PCIe bus) One 8-bit digital input/output connector; 4-bit input/4-bit Digital I/O output through the ITE IT8718 super I/O Software programmable 1-255 sec.
  • Page 24 Chapter Detailed Specifications Page 8...
  • Page 25 2.1 Dimensions 2.1.1 Board Dimensions The dimensions of the board are listed below: Length: 165 mm Width: 115 mm Page 9...

  • Page 26: F Igure 2-2: External Interface Panel Dimensions

    Figure 2-1: 3308440 Dimensions (mm) 2.1.2 External Interface Panel Dimensions External peripheral interface connector panel dimensions are shown in F igure 2-2. H 2 9 7 H 8 4 7 Figure 2-2: External Interface Panel Dimensions (mm) 2.2 Data Flow...

  • Page 27: Figure 2-3: Data Flow Block Diagram

    2.3 Embedded 3308440 Processor 2.3.1 Overview The 3308440 comes with an embedded 45 nm 1.60 GHz Intel® Atom™ processor N270. The processor supports a 533 MHz FSB and has a 1.6 GHz 512 KB L2 cache. The low power processor has a maximum power of 2.5 W. The processor is covered with a heat sink and is shown in F igure 2-4 below.

  • Page 28: Figure 2-4: Embedded Processor Covered By Heat Sink

    Figure 2-4: Embedded Processor Covered by Heat Sink 2.3.2 Features Some of the features of the Intel® Atom™ processor N270 are listed below On-die, primary 32-kB instructions cache and 24-kB write-back data cache 533-MHz source-synchronous front side bus (FSB) 2-Threads support On-die 512-kB, 8-way L2 cache Support for IA 32-bit architecture Intel®...

  • Page 30: Figure 2-6: Ddr2 So-Dimm Socket

    Intel® Atom™ N270 processor. The Intel 945GSE is interfaced to the processor through a 533 MHz FSB. 2.4.2 Intel® 945GSE DDR2 Controller There is one 200-pin DDR2 SO-DIMM socket on the 3308440 . The socket supports DDR2 SO-DIMM with the following specifications:...
  • Page 31 2.4.3 Intel® 945GSE Graphics The Intel® 945GSE supports CRT, LVDS, TV-OUT and SDVO. The SDVO bus is interfaced through a Chrontel SDVO-to-LVDS transmitter to a second LVDS connector. The internal graphics engine has the following features: Intel® Gen 3.5 Integrated Graphics Engine 250-MHz core render clock and 200 MHz core display clock at 1.05-V core voltage Supports TV-Out, LVDS, CRT and SDVO...
  • Page 33 Spread spectrum clocking supported Panel Power Sequencing support Integrated PWM interface for LCD backlight inverter control 2.4.3.3 TV Out Interface The TV Out interface has the following features. Three integrated 10-bit DACS Overscaling NTSC/PAL Component, S-Video and Composite Output interfaces HDTV support 480p/720p/1080i/1080p 2.4.3.4 Chrontel CH7308B SDVO / LVDS Support...
  • Page 35 The controllers share the same pins and only one can be activated at a time. The controllers are interfaced to the 3308440 audio connector which is in turn connected to an option audio kit with either an AC’97 codec or an HD Audio codec.

  • Page 37: Table 2-1: Supported Hdd Specifications

    PIO IDE transfers up to 16MB/s and Ultra ATA transfers of 100MB/s. The integrated IDE interface is able to support the following IDE HDDs: Ultra ATA/100, with data transfer rates up to 100MB/s Ultra ATA/66, with data transfer rates up to 66MB/s Specification Ultra Ultra...
  • Page 40 Supports PCI Express™ 1.1 Supports pair swap/polarity/skew correction Crossover Detection & & Auto-Correction Wake-on-LAN and remote wake-up support Microsoft® NDIS5, NDIS6 Checksum Offload (IPv4, IPv6, TCP, UDP) and Segmentation Task-offload (Large send and Giant send) support Supports Full Duplex flow control (IEEE 802.3x) Fully compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab Supports IEEE 802.1P Layer 2 Priority Encoding Supports IEEE 802.1Q VLAN tagging...

  • Page 41: Figure 2-12: Pcie Mini Slot

    The integrated SATA controller on the ICH7-M southbridge supports up to four SATA drives with independent DMA operations. Two SATA controllers are connected to two SATA connectors on the 3308440 . The SATA connectors are shown in F igure 2-13.
  • Page 45 Keyboard Controller Watchdog Timer Some of the Super I/O features are described in more detail below: 2.6.3.1 Super I/O LPC Interface ® The LPC interface on the Super I/O complies with the Intel Low Pin Count Specification Rev. 1.0. The LPC interface supports both LDRQ# and SERIRQ protocols as well as PCI PME# interfaces.
  • Page 46 2.6.3.6 Super I/O Keyboard/Mouse Controller The Super I/O keyboard/mouse controller can execute the 8042 instruction set. Some of the keyboard controller features are listed below: The 8042 instruction is compatible with a PS/2 keyboard and PS/2 mouse Gate A20 and Keyboard reset output Supports multiple keyboard power on events Supports mouse double-click and/or mouse move power on events 2.6.3.7 Super I/O Parallel Port...
  • Page 47 2.7.1 System Monitoring Two thermal inputs on the 3308440 Super I/O Enhanced Hardware Monitor monitor the following temperatures: System temperature CPU temperature Eight voltage inputs on the 3308440 epic Super I/O Enhanced Hardware Monitor monitor the following voltages: CPU Core +1.05V +3.3V +12V +1.5V...

  • Page 48: Table 2-2: Power Consumption

    2.7.3 Power Consumption T able 2-2 shows the power consumption parameters for the 3308440 running with a H 4 0 8 H 2 6 7 1.6 GHz Intel® Atom™ with 2.0 GB DDR2 memory.
  • Page 49 Chapter Unpacking Page 33...
  • Page 50 Electrostatic discharge (ESD) can cause serious damage to electronic components, including the 3308440 epic Dry climates are especially susceptible to ESD. It is therefore critical that whenever the 3308440 epic, or any other electrical component is handled, the following anti-static precautions are strictly adhered to.
  • Page 52 Mini jumper pack (2.0mm) Utility CD Quick Installation Guide 3.3.2 Optional Items The 3308440 is shipped with the following components: Item and Part Number Image Dual USB cable (wo bracket) LPT cable (wo bracket) RS-232/422/485 cable ATX cable HDTV output cable...
  • Page 53 IDE-cable SATA power cable Audio kit_ 5.1 Channel Audio kit_ 7.1 Channel Page 37...
  • Page 54 Chapter Connectors Page 38...

  • Page 55: Figure 4-1: Connector And Jumper Locations [Front Side]

    F igure 4-1 shows the on-board peripheral connectors, rear panel peripheral connectors H 7 0 8 H 8 6 7 and on-board jumpers. Figure 4-1: Connector and Jumper Locations [Front Side] F igure 4-2 shows the solder side of the 3308440. H 8 0 8 Page 39...

  • Page 56: Figure 4-2: Connector And Jumper Locations [Solder Side]

    Figure 4-2: Connector and Jumper Locations [Solder Side] 4.2 Peripheral Interface Connectors T able 4-1 shows a list of the peripheral interface connectors on the 3308440. H 9 0 8 H 9 6 7 Detailed descriptions of these connectors can be found below.
  • Page 57 USB 2.0 connector Table 4-1: Peripheral Interface Connectors 4.2.1 External Interface Panel Connectors T able 4-2 lists the rear panel connectors on the 3308440. Detailed descriptions of H 0 1 8 H 0 7 7 these connectors can be found in Section 4 .4 on page...

  • Page 58: Table 4-2: Rear Panel Connectors

    Internal peripheral connectors are found on the motherboard and are only accessible when the motherboard is outside of the chassis. This section has complete descriptions of all the internal, peripheral connectors on the 3308440. 4.3.1 5V Power Connector CN Label:...

  • Page 59: Figure 4-3: 5V Power Connector Pinouts

    Figure 4-3: 5V Power Connector Pinouts PIN NO. DESCRIPTION Table 4-3: 5V Power Connector Pinouts 4.3.2 AT Power Connector CN Label: CN1 & CN2 4-pin AT power connector (1x4) CN Type: CN Location: F igure 4-4 8 1 5 H CN Pinouts: T able 4-4 8 1 6 H...

  • Page 60: Figure 4-4: At Power Connector Location

    The ATX power supply enable connector enables the 3308440 to be connected to an ATX power supply. In default mode, the 3308440 can only us an AT power supply. To enable an ATX power supply the AT Power Select jumper must also be configured.

  • Page 61: Figure 4-5: Atx Power Supply Enable Connector Location

    Figure 4-5: ATX Power Supply Enable Connector Location PIN NO. DESCRIPTION PS-ON +5V Standby Table 4-5: ATX Power Supply Enable Connector Pinouts 4.3.4 Audio Connector (9-pin) CN Label: J_AUDIO1 9-pin header (2x5) CN Type: CN Location: F igure 4-6 8 1 9 H CN Pinouts: T able 4-6 8 2 0 H...

  • Page 62: Figure 4-6: Audio Connector Location (9-Pin)

    5-pin wafer (1x5) CN Location: F igure 4-7 H 1 2 8 CN Pinouts: T able 4-7 H 2 2 8 The backlight inverter connectors provide the backlights on the LCD display connected to the 3308440 with +12V of power. Page 46...

  • Page 63: Figure 4-7: Panel Backlight Connector Pinout Locations

    F igure 4-8 H 3 2 8 CN Pinouts: T able 4-8 H 4 2 8 A CF Type I or Type II memory card is inserted to the CF socket on the solder side of the 3308440. Page 47...

  • Page 64: Figure 4-8: Cf Card Socket Location

    Figure 4-8: CF Card Socket Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION GROUND VCC-IN CHECK1 DATA 3 DATA 11 DATA 4 DATA 12 DATA 5 DATA 13 DATA 6 DATA 14 DATA 7 DATA 15 HDC_CS0# HDC_CS1 GROUND IOR# IOW# VCC_COM IRQ15 VCC_COM...

  • Page 65: Figure 4-9: Dio Connector Connector Locations

    PIN NO. DESCRIPTION PIN NO. DESCRIPTION HDD_RESET IORDY SDREQ SDACK# HDD_ACTIVE# DATA 0 66DET DATA 1 DATA 8 DATA 2 DATA 9 DATA 10 VCC-IN CHECK2 GROUND Table 4-8: CF Card Socket Pinouts 4.3.7 Digital Input/Output (DIO) Connector CN Label: DIO1 CN Type: 10-pin header (2x5)

  • Page 66: Table 4-9: Dio Connector Connector Pinouts

    PIN NO. DESCRIPTION PIN NO. DESCRIPTION Output 3 Output 2 Output 1 Output 0 Input 3 Input 2 Input 1 Input 0 Table 4-9: DIO Connector Connector Pinouts 4.3.8 Fan Connector (+12V, 3-pin) CN Label: CPU_FAN1 3-pin header CN Type: CN Location: F igure 4-10 7 7 7 H 8 2 7 H...

  • Page 67: Figure 4-10: +12V Fan Connector Location

    Figure 4-10: +12V Fan Connector Location PIN NO. DESCRIPTION +12V Fan Speed Detect Table 4-10: +12V Fan Connector Pinouts 4.3.9 Front Panel Connector (8-pin) F_PANEL1 CN Label: CN Type: 8-pin header (2x4) CN Location: F igure 4-11 8 2 9 H CN Pinouts: T able 4-11 8 3 0 H...

  • Page 68: Figure 4-11: Front Panel Connector Pinout Locations (8-Pin)

    HDD LED Figure 4-11: Front Panel Connector Pinout Locations (8-pin) FUNCTION DESCRIPTION FUNCTION DESCRIPTION Power PWR_BTN Reset VCC5 Button Button HDD LED HDD_LED+ Reset SYSRST- HDD_LED- Table 4-11: Front Panel Connector Pinouts (8-pin) 4.3.10 IDE Connector(44-pin) CN Label: IDE1 CN Type: 44-pin header (2x22) CN Location: F igure 4-12...

  • Page 69: Figure 4-12: Secondary Ide Device Connector Locations

    Figure 4-12: Secondary IDE Device Connector Locations PIN NO. DESCRIPTION PIN NO. DESCRIPTION RESET# GROUND DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA 10 DATA 4 DATA 11 DATA 3 DATA 12 DATA 2 DATA 13 DATA 1 DATA 14 DATA 0 DATA 15...

  • Page 70: Figure 4-13: Infrared Connector Pinout Locations

    HDC CS0# HDC CS1# HDD ACTIVE# GROUND GROUND Table 4-12: Secondary IDE Connector Pinouts 4.3.11 Infrared Interface Connector (5-pin) CN Label: CN Type: 5-pin header (1x5) F igure 4-13 CN Location: 7 8 7 H 8 3 3 H T able 4-13 CN Pinouts: 7 8 8 H 8 3 4 H The infrared interface connector supports both Serial Infrared (SIR) and Amplitude Shift...

  • Page 71: Figure 4-14: Keyboard/Mouse Connector Location

    IR-TX Table 4-13: Infrared Connector Pinouts 4.3.12 Keyboard/Mouse Connector CN Label: CN Type: 6-pin header (1x6) CN Location: F igure 4-14 8 3 5 H CN Pinouts: T able 4-14 8 3 6 H The keyboard and mouse connector can be connected to a standard PS/2 cable or PS/2 Y-cable to add keyboard and mouse functionality to the system.

  • Page 72: Figure 4-15: Lvds Lcd Connector Pinout Locations

    PIN NO. DESCRIPTION KB CLK GROUND Table 4-14: Keyboard/Mouse Connector Pinouts 4.3.13 LVDS LCD Connector CN Label: LVDS1 and LVDS2 CN Type: 30-pin crimp (2x10) CN Location: F igure 4-15 7 8 9 H 8 3 7 H CN Pinouts: T able 4-15 7 9 0 H 8 3 8 H The 30-pin LVDS LCD connectors can be connected to single channel or dual channel,...

  • Page 73: Table 4-15: Lvds Lcd Port Connector Pinouts

    PIN NO. DESCRIPTION PIN NO. DESCRIPTION GND1 GND2 A_Y0 A_Y0# A_Y1 A_Y1# A_Y2 A_Y2# A_CK A_CK# GND3 GND4 B_Y0 B_Y0# B_Y1 B_Y1# B_Y2 B_Y2# B_CK B_CK# GND5 GND6 VCC_LCD VCC_LCD VCC_LCD VCC_LCD Table 4-15: LVDS LCD Port Connector Pinouts 4.3.14 Parallel Port Connector CN Label: LPT1 CN Type:...

  • Page 74: Figure 4-16: Parallel Port Connector Location

    Figure 4-16: Parallel Port Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION STROBE# DATA 0 DATA 1 DATA 2 DATA 3 DATA 4 DATA 5 DATA 6 DATA 7 ACKNOWLEDGE BUSY PAPER EMPTY PRINTER SELECT AUTO FORM FEED # ERROR# INITIALIZE PRINTER SELECT LN# GROUND...

  • Page 75: Figure 4-17: Pcie Mini Card Slot Location

    CN Type: 52-pin Mini PCIe Card Slot CN Location: F igure 4-17 H 1 4 8 H 1 9 7 CN Pinouts: T able 4-17 H 2 4 8 The PCIe mini card slot enables a PCIe mini card expansion module to be connected to the board.

  • Page 76: Table 4-17: Pcie Mini Card Slot Pinouts

    PETN2 SMBDATA PETP2 USBD- USBD+ RF_LINK# BLUELED# 1.5V VCC3 Table 4-17: PCIe Mini Card Slot Pinouts 4.3.16 PCI-104 Slot CN Label: PC104_PLUS1 CN Type: 120-pin PCI-104 slot CN Location: F igure 4-18 8 4 3 H CN Pinouts: T able 4-18 8 4 4 H The PCI-104 slot enables a PCI-104 compatible expansion module to be connected to the board.

  • Page 77: Figure 4-18: Pci-104 Slot Location

    Figure 4-18: PCI-104 Slot Location Pin No. Column A Column B Column C Column D GND/5V TBD1 AD00 VI/O1 AD02 AD01 AD05 AD04 AD03 C/BE0# AD07 AD06 AD09 AD08 AD11 VI/O2 AD10 M66EN Page 61...

  • Page 78: Table 4-18: Pci-104 Slot Connector Pinouts

    Pin No. Column A Column B Column C Column D AD14 AD13 AD12 +3.3V C/BE1# AD15 +3.3V SERR# SB0# PERR# +3.3V SDONE STOP# +3.3V LOCK# +3.3V TRDY# DEVSEL# FRAME# IRDY# +3.3V AD16 +3.3V C/BE2# AD18 +3.3V AD17 AD21 AD20 AD19 +3.3V AD23 AD22...

  • Page 79: Figure 4-19: Sata Drive Connector Locations

    4.3.17 SATA Drive Connectors CN Label: SATA1, SATA2 CN Type: 7-pin SATA drive connectors CN Location: F igure 4-19 7 9 3 H 8 4 5 H CN Pinouts: T able 4-19 7 9 4 H 8 4 6 H The four SATA drive connectors are each connected to a first generation SATA drive.

  • Page 80: Figure 4-20: Com Connector Pinout Locations

    4.3.18 Serial Port Connectors (COM 3 and COM4) COM3 and COM4 CN Label: CN Type: 10-pin header (2x5) CN Location: F igure 4-20 H 7 4 8 H 5 9 7 CN Pinouts: T able 4-20 H 8 4 8 H 6 9 7 The 10-pin serial port connector provides a second RS-232 serial communications channel.

  • Page 81: Figure 4-21: Rs-232/422/485 Serial Port Connector Location

    CN Type: 14-pin header (2x7) CN Location: F igure 4-21 8 4 9 H CN Pinouts: T able 4-21 8 5 0 H The 14-pin serial port connector connects to the COM2 serial communications channels. COM2 is a multi function channel. In default mode COM2 is an RS-232 serial communication channel but, with the COM2 function select jumper, can be configured as either an RS-422 or RS-485 serial communications channel.

  • Page 82: Figure 4-22: Tv Connector Pinout Locations

    CN Type: 6-pin header (2x3) CN Location: F igure 4-22 7 9 9 H 8 5 1 H CN Pinouts: T able 4-22 8 0 0 H 8 5 2 H The 2x3 pin TV out connector connects to a TV output by using an S-Video or RCA connector.

  • Page 83: Figure 4-23: Usb Connector Pinout Locations

    Table 4-23: USB Port Connector Pinouts 4.4 External Peripheral Interface Connector Panel F igure 4-24 shows the 3308440 epic external peripheral interface connector (EPIC) H 5 5 8 H 3 0 8 panel. The 3308840 EPIC panel consists of the following:...

  • Page 84: Figure 4-25: Ps/2 Pinout And Configuration

    CN Pinouts: F igure 4-25, T able 4-24 H 7 5 8 H 8 5 8 The 3308440 keyboard and mouse connector is a standard PS/2 connector. Figure 4-25: PS/2 Pinout and Configuration DESCRIPTION KB DATA MS DATA KB CLOCK...

  • Page 85: Figure 4-26: Rj-45 Ethernet Connector

    T able 4-25 H 0 6 8 H 9 0 8 The 3308440 is equipped with two built-in RJ-45 Ethernet controllers. The controllers can connect to the LAN through two RJ-45 LAN connectors. There are two LEDs on the connector indicating the status of LAN. The pin assignments are listed in the following...

  • Page 86: Figure 4-27: Com1 Pinout Locations

    DESCRIPTION STATUS DESCRIPTION STATUS GREEN Activity YELLOW Linked Table 4-26: RJ-45 Ethernet Connector LEDs 4.4.3 Serial Port Connector (COM1) CN Label: COM1 CN Type: DB-9 connectors CN Location: F igure 4-24 (see 2) 8 1 1 H 8 6 2 H CN Pinouts: T able 4-27 and F igure 4-27...

  • Page 87: Table 4-28: Usb Port Pinouts

    H 5 6 8 H 4 1 8 CN Pinouts: T able 4-28 H 6 6 8 H 5 1 8 The 3308440 has two external USB 2.0 ports. The ports connect to both USB 2.0 and USB 1.1 devices. PIN NO. DESCRIPTION PIN NO. DESCRIPTION DATA-...

  • Page 88: Figure 4-28: Vga Connector

    Figure 4-28: VGA Connector DESCRIPTION DESCRIPTION GREEN BLUE CRT_PLUG- DDC DAT HSYNC VSYNC DDCCLK Table 4-29: VGA Connector Pinouts Page 72...
  • Page 89 Chapter Installation Page 73...
  • Page 90 Electrostatic discharge (ESD) can cause serious damage to electronic components, including the 3308440 SBC Dry climates are especially susceptible to ESD. It is therefore critical that whenever the 3308440 SBC, or any other electrical component is handled, the following anti-static precautions are strictly adhered to.
  • Page 91 3308440 is installed. All installation notices pertaining to the installation of the 3308440 should be strictly adhered to. Failing to adhere to these precautions may lead to severe damage of the 3308440 and injury to the person installing the motherboard. 5.2.1 Installation Notices...
  • Page 92 Allow screws to come in contact with the PCB circ uit, co nnector pins, or its components. 5.2.2 Installation Checklist The following checklist is provided to ensure the 3308440 is properly installed. All the items in the packing list are present A compatible memory module is properly inserted into the slot...

  • Page 93: Figure 5-1: So-Dimm Installation

    5.3 Unpacking When the 3308440 is unpacked, please check all the unpacking list items listed in Chapter 3 are indeed present. If any of the unpacking list items are not available please contact the 3308440 card vendor reseller/vendors 5.4 SO-DIMM and CF Card Installation 5.4.1 SO-DIMM Installation...
  • Page 94 The 3308440 can support both CF Type I cards and CF Type II cards. For the complete specifications of the supported CF cards please refer to Chapter 2. To install the a CF card (Type 1 or Type 2) onto the 3308440, please follow the steps below: Step 1: Locate the CF card socket.

  • Page 95: Figure 5-2: Cf Card Installation

    Figure 5-2: CF Card Installation 5.5 Jumper Settings NOTE: A jumper is a metal bridge used to close an electrical circuit. It consists of two or three metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them.

  • Page 96: Table 5-1: Jumpers

    Description Label Type AT Power Mode Setting ATXCTL1 2-pin header CF Card Setting JCF1 2-pin header Clear CMOS J_CMOS1 3-pin header COM2 Mode Setting 6-pin header LVDS1 Panel Resolution J_LCD_TYPE1 8-pin header LVDS1 Voltage Select J_VLVDS1 3-pin header LVDS2 Voltage Select J_VLVDS2 3-pin header PCI-104 VIO Select...

  • Page 97: Figure 5-4: At Power Select Jumper Location

    AT Power Select Description Short 1 – 2 Use AT power Default Open Use ATX power Table 5-2: AT Power Select Jumper Settings The location of the AT Power Select jumper is shown in F igure 5-4 below. 8 7 8 H Figure 5-4: AT Power Select Jumper Location 5.5.2 CF Card Setup Jumper Label:...

  • Page 98: Figure 5-5: Cf Card Setup Jumper Location

    H 4 8 8 H 1 3 8 If the 3308440 SBC fails to boot due to improper BIOS settings, the clear CMOS jumper clears the CMOS data and resets the system BIOS information. To do this, use the jumper cap to close pins 2 and 3 for a few seconds then reinstall the jumper clip back to pins 1 and 2.

  • Page 99: Table 5-4: Clear Cmos Jumper Settings

    Load Optimal Defaults Load Failsafe Defaults. After having done one of the above, save the changes and exit the CMOS Setup menu. The clear CMOS jumper settings are shown in T able 5-4. H 5 8 8 H 2 3 8 AT Power Select Description Short 1 - 2...

  • Page 100: Figure 5-7: Com 2 Function Select Jumper Location

    The COM 2 Function Select jumper sets the communication protocol used by the second serial communications port (COM 2) as RS-232, RS-422 or RS-485. The COM 2 Function Select settings are shown in T able 5-5. H 9 8 8 COM 2 Function Select Description Short 1-2...

  • Page 101: Figure 5-8:Lvds Panel Resolution Jumper Pinout Locations

    DESCRIPTION (LVDS1) Pin 1-2 Pin 3-4 LVDS1 800 x 600 (18-bit) 024 x 768 (18-bit) 1280 x 1024 (36-bit) 1400 x 1050 (36-bit) DESCRIPTION (LVDS2) Pin 5-6 Pin 7-8 LVDS2 1024 X 768 (18-bit) 1024 X 768 (24-bit) 1280X1024 (36-bit) 1280X1024 (48-bit) Table 5-6: LVDS Panel Resolution Jumper Settings The LVDS Panel Resolution jumper location.

  • Page 102: Table 5-7: Lvds Voltage Selection Jumper Settings

    5.5.6 LVDS Voltage Selection WARNING: Permanent damage to the screen and 3308440 may occur if the wrong voltage is selected with this jumper. Please refer to the user guide that cam with the monitor to select the correct voltage. Jumper Label:...

  • Page 103: Figure 5-9: Lvds Voltage Selection Jumper Pinout Locations

    Figure 5-9: LVDS Voltage Selection Jumper Pinout Locations 5.5.7 PCI-104 Voltage Setup Jumper Label: 3-pin header Jumper Type: Jumper Settings: T able 5-7 8 9 9 H Jumper Location: F igure 5-9 9 0 0 H The PCI-104 Voltage Setup jumper allows the LVDS screen voltage to be set. The PCI-104 Voltage Setup jumper settings are shown in T able 5-7.

  • Page 104: Figure 5-10: Pci-104 Voltage Setup Jumper Pinout Locations

    The 3308440 card must be installed in a chassis with ventilation holes on the sides allowing airflow to travel through the heat sink surface. In a system with an individual power supply unit, the cooling fan of a power supply can also help generate airflow through the board surface.

  • Page 105: Table 5-9:Provided Cables

    Keyboard and Mouse cable SATA drive cable Power cable RS-232 cable Table 5-9:Provided Cables Some optional items that can be purchased separately and installed on the 3308440 include: Dual port USB cable Parallel port cable RS-232/422/485 cable ATX power cable HDTV out cable 44-pin 2.5”...

  • Page 106: Figure 5-11: Power Cable To Motherboard Connection

    5.7.2 AT Power Connection Follow the instructions below to connect the 3308440 to an AT power supply. WARNING: Disconnect the power supply power cord from its AC power source to prevent a sudden power surge to the 3308440. Step 1: Locate the power cable.

  • Page 107: Figure 5-12: Connect Power Cable To Power Supply

    Figure 5-12: Connect Power Cable to Power Supply 5.7.3 5.1 Channel Audio Kit Installation The optional 5.1 channel audio kit connects to the 10-pin audio connector on the 3308440. The audio kit consists of three audio jacks. One audio jack, Mic In, connects Page 91...
  • Page 108 Connect the audio kit cable. The audio kit is shipped with a cable that connects the audio kit to the 3308440. Connect the cable to the connector on the back of the audio kit. Make sure the pins are properly aligned (i.e. pin 1 connects to pin 1).
  • Page 109 Connect the audio kit cable. The audio kit is shipped with a cable that connects the audio kit to the 3308440. Connect the cable to the connector on the back of the audio kit. Make sure the pins are properly aligned (i.e. pin 1 connects to pin 1).

  • Page 110: Figure 5-14: 7.1 Channel Audio Kit

    Refer to Chapter 7 for driver installation instructions.Step 0: 5.7.5 ATA Flat Cable Connection The ATA 66/100 flat cable connects to the 3308440 to one or two IDE devices. To connect an IDE HDD to the 3308440 please follow the instructions below. Step 1: Locate the IDE connector.

  • Page 111: Figure 5-15: Ide Cable Connection

    1 on the connector. Step 0: 5.7.6 SATA Drive Connection The 3308440 is shipped with two SATA drive cables and one SATA drive power cable. To connect the SATA drives to the connectors, please follow the steps below. Step 1: Locate the connectors.

  • Page 112: Figure 5-16: Sata Drive Cable Connection

    Figure 5-16: SATA Drive Cable Connection Step 3: Connect the cable to the SATA disk. Connect the connector on the other end of the cable to the connector at the back of the SATA drive. See F igure 5-17. 8 5 3 H 9 0 9 H Step 4: Connect the SATA power cable.

  • Page 113: Figure 5-17: Sata Power Drive Connection

    Figure 5-17: SATA Power Drive Connection 5.7.7 Single RS-232 Cable (w/o Bracket) The single RS-232 cable consists of one serial port connector attached to a serial communications cable that is then attached to a D-sub 9 male connector. To install the single RS-232 cable, please follow the steps below.

  • Page 114: Figure 5-18: Single Rs-232 Cable Installation

    Step 0: 5.7.8 USB Cable (Dual Port without Bracket) The 3308440 SBC is shipped with a dual port USB 2.0 cable. To connect the USB cable connector, please follow the steps below. Step 1: Locate the connectors. The locations of the USB connectors are shown in Chapter 3.

  • Page 115: Figure 5-19: Dual Usb Cable Connection

    1 on the 3308440 USB connector. Step 3: Insert the cable connectors . Once the cable connectors are properly aligned with the USB connectors on the 3308440, connect the cable connectors to the on-board connectors. See F igure 5-19 . H 2 1 9...

  • Page 116: Figure 5-20: Lpt Cable Connection

    Step 3: Insert the cable connectors. Once the cable connector is properly aligned with the 26-pin box-header connector on the PCIE-9452, connect the cable connector to the on-board connector. See F igure 5-20. 9 1 4 H Figure 5-20: LPT Cable Connection Step 4: Attach the LPT connector to the chassis.

  • Page 117: Figure 5-21: Connect The Lpt Device

    Figure 5-21: Connect the LPT Device 5.7.10 Dual RS-422/485 Cables The 3308440 SBC is shipped with one RS-422/485 dual serial port connector cable. The dual serial port connector cable connects the serial port connectors on the cable to the RS-422/485 serial port connectors on the 3308440 SBC. Follow the steps below to connect the dual serial port connector cable.

  • Page 118: Figure 5-22: Dual Serial Port Connector Cable Connection

    PS/2 devices Serial port devices USB devices VGA monitors To install these devices, connect the corresponding cable connector from the actual device to the corresponding 3308440 SBC external peripheral interface connector making sure the pins are properly aligned. Page 102...
  • Page 119 The 3308440 has a PS/2 connector on the external peripheral interface panel. The dual PS/2 connector is connected to the PS/2 Y-cable that came with the 3308440. One of the PS/2 cables is connected to a keyboard and the other to a mouse to the system.

  • Page 120: Figure 5-24: Ps/2 Keyboard/Mouse Connector

    Step 0: 5.8.3 Serial Device Connection The 3308440 SBC has a single female DB-9 connector on the external peripheral interface panel for a serial device. Follow the steps below to connect a serial device to the 3308440. Step 1: Locate the DB-9 connector.

  • Page 121: Figure 5-25: Serial Device Connector

    The external USB Series "A" receptacle connectors provide easier and quicker access to external USB devices. Follow the steps below to connect USB devices to the 3308440. Step 1: Locate the USB Series "A" receptacle connectors. The location of the USB Series "A"...
  • Page 122 5.8.5 VGA Monitor Connection The 3308440 EPIC SBC has a single female DB-15 connector on the external peripheral interface panel. The DB-15 connector is connected to a CRT or VGA monitor. To connect a monitor to the 3308440, please follow the instructions below.

  • Page 123: Figure 5-27: Vga Connector

    Figure 5-27: VGA Connector Step 4: Secure the connector. Secure the DB-15 VGA connector from the VGA monitor to the external interface by tightening the two retention screws on either side of the connector. Step 0: Page 107...
  • Page 124 Chapter BIOS Screens Page 108...
  • Page 125 6.1 Introduction A licensed copy of AMI BIOS is preprogrammed into the ROM BIOS. The BIOS setup program allows users to modify the basic system configuration. This chapter describes how to access the BIOS setup program and the configuration options that may be changed.

  • Page 126: Table 6-1: Bios Navigation Keys

    F1 key General help, only for Status Page Setup Menu and Option Page Setup Menu F2 /F3 key Change color from total 16 colors. F2 to select color forward. F10 key Save all the CMOS changes, only for Main Menu Table 6-1: BIOS Navigation Keys 6.1.3 Getting Help When F1 is pressed a small help window describing the appropriate keys to use and the...
  • Page 127 6.2 Main The Main BIOS menu ( B IOS Menu 1) appears when the BIOS Setup program is entered. 8 6 4 H 9 2 2 H The Main menu gives an overview of the basic system information. BIOS Menu 1: Main System Overview The System Overview lists a brief summary of different system components.
  • Page 128 Count: The number of CPUs on the motherboard System Memory: Displays the auto-detected system memory. Size: Lists memory size The System Overview field also has two user configurable fields: System Time [xx:xx:xx] Use the System Time option to set the system time. Manually enter the hours, minutes and seconds.
  • Page 129 BIOS Menu 2: Advanced 6.3.1 CPU Configuration Use the CPU Configuration menu ( B IOS Menu 3) to view detailed CPU specifications 8 7 3 H 9 3 1 H and configure the CPU. Page 113...
  • Page 130 BIOS Menu 3: CPU Configuration The CPU Configuration menu ( B IOS Menu 3) lists the following CPU details: 8 7 4 H 9 3 2 H Manufacturer: Lists the name of the CPU manufacturer Brand String: Lists the brand name of the CPU being used Frequency: Lists the CPU processing speed FSB Speed: Lists the FSB speed Cache L1: Lists the CPU L1 cache size...
  • Page 131 BIOS Menu 4: IDE Configuration ATA/IDE Configurations [Compatible] Use the ATA/IDE Configurations option to configure the ATA/IDE controller. Disabled Disables the on-board ATA/IDE controller. Compatible Configures the on-board ATA/IDE controller to be in compatible mode. In this mode, a SATA channel will replace one of the IDE channels.
  • Page 132 Legacy IDE Channels [PATA Pri, SATA Sec] SATA Only Only the SATA drives are enabled. The IDE drives are enabled on the Primary SATA Pri, PATA Sec EFAULT IDE channel. The SATA drives are enabled on the Secondary IDE channel. PATA Only The IDE drives are enabled on the primary and secondary IDE channels.
  • Page 133 BIOS Menu 5: IDE Master and IDE Slave Configuration Auto-Detected Drive Parameters The “grayed-out” items in the left frame are IDE disk drive parameters automatically detected from the firmware of the selected IDE disk drive. The drive parameters are listed as follows: Device: Lists the device type (e.g.
  • Page 134 interrupt if block mode is not used. Block mode allows transfers of up to 64 KB per interrupt. PIO Mode: Indicates the PIO mode of the installed device. Async DMA: Indicates the highest Asynchronous DMA Mode that is supported. Ultra DMA: Indicates the highest Synchronous DMA Mode that is supported. S.M.A.R.T.: Indicates whether or not the Self-Monitoring Analysis and Reporting Technology protocol is supported.
  • Page 135 LBA/Large Mode [Auto] Use the LBA/Large Mode option to disable or enable BIOS to auto detects LBA (Logical Block Addressing). LBA is a method of addressing data on a disk drive. In LBA mode, the maximum drive capacity is 137 GB. Disabled BIOS is prevented from using the LBA mode control on the specified channel.
  • Page 136 PIO mode 0 selected with a maximum transfer rate of 3.3MBps PIO mode 1 selected with a maximum transfer rate of 5.2MBps PIO mode 2 selected with a maximum transfer rate of 8.3MBps PIO mode 3 selected with a maximum transfer rate of 11.1MBps PIO mode 4 selected with a maximum transfer rate of 16.6MBps (This setting generally works with all hard disk drives manufactured after 1999.
  • Page 137 Ultra DMA mode 0 selected with a maximum data transfer UDMA1 rate of 16.6MBps Ultra DMA mode 1 selected with a maximum data transfer UDMA1 rate of 25MBps Ultra DMA mode 2 selected with a maximum data transfer UDMA2 rate of 33.3MBps Ultra DMA mode 3 selected with a maximum data transfer UDMA3 rate of 44MBps (To use this mode, it is required that an...
  • Page 138 Prevents the BIOS from using 32-bit data transfers. Disabled Enabled Allows BIOS to use 32-bit data transfers on supported EFAULT hard disk drives. 6.3.3 Super IO Configuration Use the Super IO Configuration menu ( B IOS Menu 6) to set or change the H 6 3 9 H 8 7 8 configurations for the FDD controllers, parallel ports and serial ports.
  • Page 139 Parallel Port I/O port address is 278 Parallel Port I/O port address is 3BC Parallel Port Mode [Normal] Use the Parallel Port Mode option to select the mode the parallel port operates in. Normal The normal parallel port mode is the standard mode EFAULT for parallel port operation.
  • Page 140 Serial Port1 Address [3F8/IRQ4] Use the Serial Port1 Address option to select the Serial Port 1 base address. Disabled No base address is assigned to Serial Port 1 3F8/IRQ4 Serial Port 1 I/O port address is 3F8 and the interrupt EFAULT address is IRQ4 3E8/IRQ4...
  • Page 141 2E8/IRQ3 Serial Port 2 I/O port address is 2E8 and the interrupt address is IRQ3 Serial Port2 Mode [Normal] Use the Serial Port2 Mode option to select the Serial Port2 operational mode. Normal Serial Port 2 mode is normal EFAULT IrDA Serial Port 2 mode is IrDA ASK IR...
  • Page 142 Disabled No base address is assigned to serial port 3 Serial port 4 I/O port address is 3E8 Serial port 4 I/O port address is 2E8 EFAULT Serial port 4 I/O port address is 2F0 Serial port 4 I/O port address is 2E0 Serial Port4 IRQ [10] Use the Serial Port4 IRQ option to select the interrupt address for serial port 4.
  • Page 143 BIOS Menu 7: Hardware Health Configuration CPU FAN Mode Setting [Full On Mode] Use the CPU FAN Mode Setting option to configure the second fan. Full On Mode Fan is on all the time EFAULT Automatic mode Fan is off when the temperature is low enough.
  • Page 144 CPU Fan Start PWM Slope PWM 1 When the CPU FAN Mode Setting option is in the PWM Manual Mode, the following parameters can be set. CPU Fan PWM control CPU Temp. Limit of OFF [000] WARNING: Setting this value too high may cause the fan to stop when the CPU is at a high temperature and therefore cause the system to be damaged.
  • Page 145 The CPU Temp. Limit of Start option can only be set if the CPU FAN Mode Setting option is set to Automatic Mode. Use the CPU Temp. Limit of Start option to select the CPU temperature at which the cooling fan should automatically turn on. When the fan starts, it rotates using the starting pulse width modulation (PWM) specified in the Fan 3 Start PWM option below.
  • Page 146 16 PWM 32 PWM 64 PWM The following system parameters and values are shown. The system parameters that are monitored are: System Temperatures: The following system temperatures are monitored CPU Temperature System Temperature Fan Speeds: The CPU cooling fan speed is monitored. CPU Fan Speed Voltages: The following system voltages are monitored CPU Core...
  • Page 147 BIOS Menu 8: Power Configuration 6.3.5.1 ACPI configuration The ACPI Configuration menu ( B IOS Menu 9) configures the Advanced Configuration 8 8 0 H 9 3 9 H and Power Interface (ACPI). Page 131...
  • Page 148 BIOS Menu 9: ACPI Configuration Suspend Mode [S1(POS)] Use the Suspend Mode BIOS option to specify the sleep state the system enters when it is not being used. S1 (POS) System appears off. The CPU is stopped; RAM is EFAULT refreshed;...
  • Page 149 BIOS Menu 10:Advanced Power Management Configuration Restore on AC Power Loss [Last State] Use the Restore on AC Power Loss BIOS option to specify what state the system returns to if there is a sudden loss of power to the system. Power Off The system remains turned off Power On...
  • Page 150 turned on or off Suspend When the power button is pressed the system goes into suspend mode Resume on Keyboard/Mouse [Disabled] Use the Resume on Keyboard/Mouse BIOS option to enable activity on either the keyboard or mouse to rouse the system from a suspend or standby state. That is, the system is roused when the mouse is moved or a button on the keyboard is pressed.
  • Page 151 activity Resume On RTC Alarm [Disabled] Use the Resume On RTC Alarm option to specify the time the system should be roused from a suspended state. Disabled The real time clock (RTC) cannot generate a wake EFAULT event Enabled If selected, the following appears with values that can be selected: RTC Alarm Date (Days) System Time...
  • Page 152 BIOS Menu 11: Remote Access Configuration [Advanced] Remote Access [Disabled] Use the Remote Access option to enable or disable access to the remote functionalities of the system. Disabled Remote access is disabled. EFAULT Enabled Remote access configuration options shown below appear: Serial Port Number Serial Port Mode...
  • Page 153 Terminal Type VT-UTF8 Combo Key Support These configuration options are discussed below. Serial Port Number [COM1] Use the Serial Port Number option allows to select the serial port used for remote access. System is remotely accessed through COM1 COM1 EFAULT COM2 System is remotely accessed through COM2 NOTE: Make sure the selected COM port is enabled through the Super I/O configuration...
  • Page 154 Flow Control [None] Use the Flow Control option to report the flow control method for the console redirection application. None No control flow, EFAULT Hardware Hardware is set as the console redirection Software Software is set as the console redirection Redirection After BIOS POST [Always] Use the Redirection After BIOS POST option to specify when console redirection should occur.
  • Page 155 The VT100 Terminal Definition is the standard convention used to configure and conduct emergency management tasks with UNIX-based servers. VT100 does not support all keys on the standard PC 101-key layout, however. The VT-UTF8 convention makes available additional keys that are not provided by VT100 for the PC 101 keyboard. Disabled Disables the VT-UTF8 terminal keys EFAULT...
  • Page 156 BIOS Menu 12: USB Configuration USB Functions [Enabled] Use the USB Function option to enable or disable the USB controllers. Disabled USB controllers are enabled Enabled USB controllers are disabled EFAULT USB 2.0 Controller [Enabled] The USB 2.0 Controller BIOS option enables or disables the USB 2.0 controller Disabled USB function disabled Enabled...
  • Page 157 The USB2.0 Controller Mode BIOS option sets the speed of the USB2.0 controller. FullSpeed The controller is capable of operating at full speed 12 Mb/s HiSpeed The controller is capable of operating at high speed EFAULT 480 Mb/s Legacy USB Support [Enabled] Use the Legacy USB Support BIOS option to enable USB mouse and USB keyboard support.
  • Page 158 BIOS Menu 13: PCI/PnP Configuration IRQ# [Available] Use the IRQ# address to specify what IRQs can be assigned to a particular peripheral device. Available The specified IRQ is available to be used by EFAULT PCI/PnP devices Reserved The specified IRQ is reserved for use by Legacy ISA devices Available IRQ addresses are: IRQ3...
  • Page 159 IRQ9 IRQ10 IRQ 11 IRQ 14 IRQ 15 DMA Channel# [Available] Use the DMA Channel# option to assign a specific DMA channel to a particular PCI/PnP device. The specified DMA is available to be used by Available EFAULT PCI/PnP devices The specified DMA is reserved for use by Legacy Reserved ISA devices...
  • Page 160 54KB reserved for legacy ISA devices 6.5 Boot Use the Boot menu ( B IOS Menu 14) to configure system boot options. H 4 4 9 H 5 8 8 BIOS Menu 14: Boot 6.5.1 Boot Settings Configuration Use the Boot Settings Configuration menu ( B IOS Menu 14) to configure advanced system 8 8 6 H 9 4 5 H boot options.
  • Page 161 BIOS Menu 15: Boot Settings Configuration Quick Boot [Enabled] Use the Quick Boot BIOS option to make the computer speed up the boot process. Disabled No POST procedures are skipped Enabled Some POST procedures are skipped to decrease EFAULT the system boot time Quiet Boot [Disabled] Use the Quiet Boot BIOS option to select the screen display when the system boots.
  • Page 162 The AddOn ROM Display Mode option allows add-on ROM (read-only memory) messages to be displayed. Allows the computer system to force a third party Force BIOS EFAULT BIOS to display during system boot. Allows the computer system to display the Keep Current information during system boot.
  • Page 163 Can be booted from a remote system through the Enabled EFAULT 6.5.2 Boot Device Priority Use the Boot Device Priority menu ( B IOS Menu 16) to specify the boot sequence from H 6 4 9 H 7 8 8 the available devices.
  • Page 164 6.6 Security Use the Security menu ( B IOS Menu 17) to set system and user passwords. 8 8 8 H 9 4 7 H BIOS Menu 17: Security Change Supervisor Password Use the Change Supervisor Password to set or change a supervisor password. The default for this option is Not Installed.
  • Page 165 password. After the password has been added, Install appears next to Change User Password. 6.7 Chipset Use the Chipset menu ( B IOS Menu 18) to access the NorthBridge and SouthBridge 8 8 9 H 9 4 8 H configuration menus WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction.
  • Page 166 6.7.1 North Bridge Chipset Configuration Use the North Bridge Chipset Configuration menu ( B IOS Menu 18) to configure the H 9 4 9 H 0 9 8 Northbridge chipset settings. BIOS Menu 19:North Bridge Chipset Configuration Memory Hole [Disabled] The Memory Hole reserves the memory space between 15MB and 16MB for ISA expansion cards that require a specified area of memory to work properly.
  • Page 167 The Internal Graphic Mode Select option determines the amount of system memory that can be used by the Internal graphics device. Disable Enable, 1MB 1MB of memory used by internal graphics device Enable, 8MB 8MB of memory used by internal graphics device EFAULT DVMT Mode Select [DVMT Mode] Use the DVMT Mode Select option to select the Intel Dynamic Video Memory Technology...
  • Page 168 Boot Display Device [CRT] The Boot Display Device BIOS option selects the display device the system uses when it boots. The available options are listed below: Auto EFAULT LFP1 LVDS Panel Type Use the LVDS Panel Type to determine the LCD panel resolution. Configuration options are listed below: 640 x 480 18b 800 x 480 18b...
  • Page 169 TV type is set to PAL SECAM TV type is set to SECAM TV type is set to SMPTE240M SMPTE240M ITU-R television TV type is set to ITU-R television SMPTE260M TV type is set to SMPTE260M SMPTE295M TV type is set to SMPTE295M SMPTE296M TV type is set to SMPTE296M EIA-770.2...
  • Page 170 Audio Controller [All Disabled] The Audio Controller option enables or disables the audio controller. Azalia Audio controller configured as Azalia AC’97 Audio Only The on-board AC’97 audio controller is enabled. All Disabled The on-board audio controller is disabled. EFAULT 6.8 Exit Use the Exit menu ( B IOS Menu 21) to load default BIOS values, optimal failsafe values 8 9 3 H 9 5 1 H...
  • Page 171 Save Changes and Exit Use the Save Changes and Exit option to save the changes made to the BIOS options and to exit the BIOS configuration setup program. Discard Changes and Exit Use the Discard Changes and Exit option to exit the BIOS configuration setup program without saving the changes made to the system.
  • Page 172 Chapter Software Drivers Page 156...
  • Page 173 7.1 Available Software Drivers The following drivers can be installed on the system: Chipset Audio Installation instructions are given below. 7.2 Starting the Driver Program To access the driver installation programs, please do the following. Step 1: Insert the CD-ROM that came with the system into a CD-ROM drive attached to the system.

  • Page 174: Figure 7-2: Select Operating System

    Step 4: The screen in appears. Figure 7-2: Select Operating System Page 158...

  • Page 175: Figure 7-3: Drivers

    Step 5: Select the operating system installed on the 3308440 system. This ma nual des cribes the installation for a Wind ows XP operating system. Step 6: The list of drivers in F igure 7-3 appears. Step 0: 9 5 3 H Figure 7-3: Drivers 7.3 Chipset Driver Installation...

  • Page 176: Figure 7-4: Chipset Driver Screen

    Figure 7-4: Chipset Driver Screen Step 4: When the setup files are completely extracted the Welcome Screen in F igure 9 5 7 H 7-5 appears. Figure 7-5: Chipset Driver Welcome Screen Step 5: Click Next to continue. Page 160...

  • Page 177: Figure 7-6: Chipset Driver License Agreement

    Step 6: The license agreement in F igure 7-6 appears. 9 5 8 H Step 7: Read the License Agreement. Step 8: Click the Yes icon to continue. Figure 7-6: Chipset Driver License Agreement Step 9: The Read Me file in F igure 7-7 appears.

  • Page 178: Figure 7-7: Chipset Driver Read Me File

    Figure 7-7: Chipset Driver Read Me File Step 11: Setup Operations are performed as shown in F igure 7-8. 9 6 0 H Page 162...

  • Page 179: Figure 7-8: Chipset Driver Setup Operations

    Figure 7-8: Chipset Driver Setup Operations Step 12: Once the Setup Operations are complete, click the Next icon to continue. Step 13: The Finish screen appears. Step 14: Select “Yes, I want to restart the computer now” and click the Finish icon. F igure 7-9.Step 0: 9 6 1 H...

  • Page 180: Figure 7-9: Chipset Driver Installation Finish Screen

    Figure 7-9: Chipset Driver Installation Finish Screen 7.4 VGA Driver Installation To install the VGA driver, please do the following. Step 1: Access the driver list shown in F igure 7-3. (See Section 7 .2) 9 6 2 H 9 6 3 H Step 2: Click “2-VGA”...

  • Page 181: Figure 7-10: Vga Driver Read Me File

    Figure 7-10: VGA Driver Read Me File Step 5: The installation files are extracted. See F igure 7-11. 9 6 5 H Figure 7-11: VGA Driver Setup Files Extracted Step 6: The Welcome Screen in F igure 7-12 appears. 9 6 6 H Page 165...

  • Page 182: Figure 7-12: Vga Driver Welcome Screen

    Figure 7-12: VGA Driver Welcome Screen Step 7: Click Next to continue. Step 8: The license agreement in F igure 7-13 appears. 9 6 7 H Step 9: Read the License Agreement. Step 10: Click the Yes icon to continue. Page 166...

  • Page 183: Figure 7-13: Vga Driver License Agreement

    Figure 7-13: VGA Driver License Agreement Step 11: The Read Me file in F igure 7-14 appears. 9 6 8 H Step 12: Click Next to continue. Figure 7-14: VGA Driver Read Me File Step 13: Setup Operations are performed as shown in F igure 7-15.

  • Page 184: Figure 7-15: Vga Driver Setup Operations

    Figure 7-15: VGA Driver Setup Operations Step 14: Once the Setup Operations are complete, click the Next icon to continue. Step 15: The Finish screen appears. Step 16: Select “Yes, I want to restart the computer now” and click the Finish icon. F igure 7-16.Step 0: 9 7 0 H...

  • Page 185: Figure 7-17: Lan Driver Welcome Screen

    7.5 LAN Driver Installation To install the chipset driver, please do the following. Step 1: Access the driver list shown in F igure 7-3. (See Section 7 .2) H 1 7 9 H 2 7 9 Step 2: Click “3-LAN” Step 3: The Welcome screen in F igure 7-17 appears.

  • Page 186: Figure 7-18: Lan Driver Welcome Screen

    Figure 7-18: LAN Driver Welcome Screen Step 7: The program begins to install. Step 8: The installation progress can be monitored in the progress bar shown in F igure 9 7 5 H 7-19. Figure 7-19: LAN Driver Installation Page 170...

  • Page 187: Figure 7-20: Lan Driver Installation Complete

    Step 9: When the driver installation is complete, the screen in F igure 7-20 appears. H 6 7 9 Step 0: Figure 7-20: LAN Driver Installation Complete 7.6 Audio Driver Installation To install the chipset driver, please do the following. Step 1: Access the driver list shown in F igure 7-3.

  • Page 188: Figure 7-21: Audio Driver Options

    Figure 7-21: Audio Driver Options 7.6.1 HD Audio Installation To install the HD Audio driver, please do the following: Step 1: Select “1-HDAudio” in F igure 7-21. 9 8 0 H Step 2: Installation files are extracted as shown in F igure 7-22.

  • Page 189: Figure 7-22: Extract Hd Audio Driver Installation Files

    Figure 7-22: Extract HD Audio Driver Installation Files Step 3: The Welcome screen in F igure 7-23 appears. 9 8 2 H Page 173...

  • Page 190: Figure 7-23: Hd Audio Driver Welcome Screen

    Figure 7-23: HD Audio Driver Welcome Screen Step 4: Click Next to continue. Step 5: The system updates. See F igure 7-24. 9 8 3 H Page 174...

  • Page 191: Figure 7-24: System Update

    Figure 7-24: System Update Step 6: Follow the installation instructions until the HD Audio driver installation is complete.Step 0: 7.6.2 AC’97 Driver Installation To install the AC’97 audio driver, please do the following: Step 1: Select “2-AC’97” in F igure 7-21 9 8 4 H Step 2: The installation files are extracted as shown in...

  • Page 192: Figure 7-25: Ac'97 Driver Installation File Extraction

    Figure 7-25: AC’97 Driver Installation File Extraction Step 3: The AC’97 Driver Installation screen in F igure 7-26 appears. 9 8 6 H Step 4: Click Next to continue. Figure 7-26: AC’97 Driver Installation Welcome Screen Step 5: The Verification window in F igure 7-27 may appear.

  • Page 193: Figure 7-27: Ac'97 Driver Installation Verification

    Figure 7-27: AC’97 Driver Installation Verification Step 7: The driver installation begins. See F igure 7-28. 9 8 8 H Figure 7-28: AC’97 Driver Installation Step 8: When the driver is installed, the driver installation finish screen in F igure 7-29 9 8 9 H appears.

  • Page 194: Figure 7-29: Ac'97 Driver Installation Complete

    Figure 7-29: AC’97 Driver Installation Complete Step 10: The system reboots.Step 0: Page 178...
  • Page 195 Appendix BIOS Menu Options Page 179...
  • Page 196 System Overview ..................... 1 11 3 5 5 H 9 9 0 H System Time [xx:xx:xx]................... 1 12 3 5 6 H 9 9 1 H System Date [xx/xx/xx]..................1 12 3 5 7 H 9 9 2 H ATA/IDE Configurations [Compatible] ............1 15 3 5 8 H 9 9 3 H...
  • Page 197 Slope PWM [0.5 PWM] .................. 1 29 H 6 8 3 H 1 2 0 1 Suspend Mode [S1(POS)] ................1 32 H 7 8 3 H 2 2 0 1 Restore on AC Power Loss [Last State]............1 33 H 8 8 3 H 3 2 0 1 Power Button Mode [On/Off] ................
  • Page 198 Quick Boot [Enabled] ..................1 45 H 8 1 4 H 3 5 0 1 Quiet Boot [Disabled]..................1 45 H 9 1 4 H 4 5 0 1 AddOn ROM Display Mode [Force BIOS]............1 45 H 0 2 4 H 5 5 0 1 Bootup Num-Lock [Off]...................
  • Page 199 Appendix Terminology Page 183...
  • Page 200 AC ’97 Audio Codec 97 (AC’97) refers to a codec standard developed by Intel® in 1997. ACPI Advanced Configuration and Power Interface (ACPI) is an OS-directed configuration, power management, and thermal management interface. AHCI Advanced Host Controller Interface (AHCI) is a SATA Host controller register-level interface.
  • Page 201 computer is usually a male DE-9 connector. The Digital-to-Analog Converter (DAC) converts digital signals to analog signals. Double Data Rate refers to a data bus transferring data on both the rising and falling edges of the clock signal. Direct Memory Access (DMA) enables some peripheral devices to bypass the system processor and communicate directly with the system memory.
  • Page 202 The Media Access Control (MAC) protocol enables several terminals or network nodes to communicate in a LAN, or other multipoint networks. PCIe PCI Express (PCIe) is a communications bus that uses dual data lines for full-duplex (two-way) serial (point-to-point) communications between the SBC components and/or expansion cards and the SBC chipsets.
  • Page 203 asynchronous communications on the system and manages the system’s serial communication (COM) ports. UHCI The Universal Host Controller Interface (UHCI) specification is a register-level interface description for USB 1.1 Host Controllers. The Universal Serial Bus (USB) is an external bus standard for interfacing devices.
  • Page 204 Appendix DIO Interface Page 188...
  • Page 205 C.1 DIO Interface Introduction The DIO connector on t he 3308440 is interfaced to GPIO ports on the ITE IT8718 Super I/O chipset. The DIO has both 4-bit digital inputs and 4-bit digital outputs. The digital inputs and digital outputs are generally control si gnals that control the on/o circuit of external devices or TTL devices.
  • Page 206 C.3 Assembly Language Samples C.3.1 Enable the DIO Input Function The BIOS interrupt call INT 15H controls the digital I/O. An assembly program to enable digital I/O input functions is listed below. AX, 6F08H Sets the digital port as input Initiates the INT 15H BIOS call C.3.2 Enable the DIO Output Function The BIOS interrupt call INT 15H controls the digital I/O.
  • Page 207 Appendix Watchdog Timer Page 191...
  • Page 208 The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash. This condition may have occurred by external EMI or a software bug. When the CPU stops working correctly, Watchdog Timer either performs a hardware reset (cold boot) or a Non-Maskable Interrupt (NMI) to bring the system back to a known state.
  • Page 209 NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. Example program: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30 ;time-out value is 48 seconds ; ADD THE APPLICATION PROGRAM HERE EXIT_AP, 1 ;is the application over? W_LOOP...
  • Page 210 Appendix Address Mapping Page 194...
  • Page 211 E.1 I/O Address Map Page 195...
  • Page 212 Table E-1: IO Address Map...
  • Page 213 E.2 IRQ Address Map Table E-2: IRQ Address Map Page 197...
  • Page 214 E.3 Memory Address Map Table E-3: Memory Address Map Page 198...
  • Page 215 Appendix Hazardous Materials Disclosure Page 199...
  • Page 216 F.1 Hazardous Material Disclosure Table for IPB Products Certified as RoHS Compliant Under 2002/95/EC Without Mercury The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
  • Page 217 Part Name Toxic or Hazardous Substances and Elements Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated (Pb) (Hg) (Cd) Chromium Biphenyls Diphenyl Ethers (CR(VI)) (PBB) (PBDE) Housing Display Printed Circuit Board Metal Fasteners Cable Assembly Fan Assembly Power Supply Assemblies Battery O: This toxic or hazardous substance is contained in all of the homogeneous materials for the part is below the limit requirement in SJ/T11363-2006 X: This toxic or hazardous substance is contained in at least one of the homogeneous materials for this part is above the limit requirement in SJ/T11363-2006...
  • Page 218 Index Page 203...
  • Page 219 +12V power source connector backlight inverter connector 4, 46 location and pinouts BIOS 27, 109, 110, 111, 112, 113, 114, 115, 116, 117, 122, 126, 127, 130, 131, 5V power connector 132, 133, 135, 136, 138, 139, 140, 141, location and pinouts 142, 144, 145, 146, 147, 148, 149, 150, 153, 154, 155 BIOS chipset...

  • Page 220: F Igure 4-24: External Peripheral Interface Connector

    front panel northbridge clear CMOS jumper 5, 82 infrared interface location keyboard/mouse t t e LVDS LCD (30-pin) parallel port clear CMOS jumper PCI-104 slot serial port (COM 2) ’ C TV out COM 2 USB (internal) COM 2 function select connector location and pinouts f r i RS-232, RS-422 or RS-485...

  • Page 221: F Igure 2-9: Ide Connector

    Ethernet controllers ASKIR external indicators Serial Infrared external peripheral interface connection infrared interface connector 4, 54 connectors location and pinouts External Peripheral Interface Connectors installation checklist Keyboard/Mouse IrDA 124, 125 external switches IrDA connector fan connector 4, 50 jumper location and pinouts RS-232/422/485 COM2 setup fan speed controller jumper...
  • Page 222 LCD display backlight inverter connector LPC bus northbridge chipset LPC interface 21, 29 cable connection parallel port LPT cable cable connection LPT connection parallel port LVDS connector parallel port cable LVDS display parallel port connection voltage select parallel port connector LVDS LCD connector location and pinouts location and pinouts...

  • Page 223: F Igure 2-15: Super I

    power cable SATA drive connector 5, 63 RAID location and pinouts real time clock SATA drives RJ-45 connection Serial Device single connector connection RJ-45 connector serial port RJ-45 connector serial port connector 64, 65, 70 RJ-45 Ethernet connector location and pinouts 64, 65, 70 RJ-45 LAN connector serial ports...

  • Page 224: F Igure 2-7: Vga Connector

    USB2.0 140, 141 external USB device connection USB 1.1 VGA connector USB 2.0 VGA monitor USB 1.1 connection USB 2.0 67, 140 USB 2.0 port USB cable dual port warranty validation USB connector, internal 5, 67 location and pinouts USB device connection Y-cable dual connector USB port...
  • Page 225 We will do our best to support your products, projects and business. Address: Global American, Inc. 17 Hampshire Drive Hudson, NH 03051 Telephone: Toll Free U.S. Only (800) 833-8999 (603) 886-3900 FAX: (603) 886-4545 Website: http://www.globalamericaninc.com Support: Technical Support at Global American...
