Global American 3302670 Manual

Pentium 4 pci-isa bus industrial single board computer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
3302670
Pentium® 4 PCI-ISA Bus
Industrial Single Board Computer
•Mini PCI•DDR•DVI/CRT•Dual LAN•
•Wireless LAN•Audio•ATA/33/66/100•
•USB2.0•WDT•H/W Monitor•
•PCI-ISA Bus Industrial Single Board computer•

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3302670 and is the answer not in the manual?

Questions and answers

Related Manuals for Global American 3302670

Summary of Contents for Global American 3302670

  • Page 1 3302670 Pentium® 4 PCI-ISA Bus Industrial Single Board Computer •Mini PCI•DDR•DVI/CRT•Dual LAN• •Wireless LAN•Audio•ATA/33/66/100• •USB2.0•WDT•H/W Monitor• •PCI-ISA Bus Industrial Single Board computer•...
  • Page 2 Copyright Disclaimers The accuracy of contents in this manual has passed thorough checking and review before publishing. Global American Inc., the manufacturer and publisher, is not liable for any infringements of patents or other rights resulting from its use. The...

  • Page 3: Table Of Contents

    Table of Contents Chapter 1 General Description Major Features ............. 2 Specifications .............. 3 Board Dimensions............4 Chapter 2 Unpacking Opening the Delivery Package ........5 Inspection..............5 Chapter 3 Hardware Installation ...7 Before Installation ............7 Board Layout ............... 8 Jumper List ..............
  • Page 4 Chapter 4 Award BIOS Setup ..25 Starting Setup ............25 Using Setup..............26 Main Menu ..............27 Standard CMOS Features ......... 28 Advanced BIOS Features ......... 29 Advanced Chipset Features ........30 Integrated Peripherals..........31 Power Management Setup........32 PnP/PCI Configurations..........33 4.10 PC Health Status............
  • Page 5 Fasten the ALLIGATOR clip of the strap to the end of the shielded wire lead from a grounded object. Please wear and connect the strap before handling the 3302670 to protect yourself from the discharge of any static electricity through the strap.

  • Page 6: General Description

    Its onboard ATA/33/66/100 connected to IDE drive interface architecture allows the 3302670 to support data transfers of 33, 66 or ® 100MB/sec. for each IDE drive connection. Designed with the Intel 82845GV/82801DB core logic chipset, the board supports all PGA 478 Pentium®...

  • Page 7: Major Features

    Additional onboard connectors include an advanced USB2.0 port providing faster data transmission, and two external RJ-45 connectors for use of two 10/100 Base-TX Ethernet interfaces. Major Features The 3302670 comes with the following features: ® ® ¾ PGA 478 for Intel Pentium 4 up to 2.8GHz CPU...

  • Page 8: Specifications

    Specifications ® ® „ CPU: PGA 478 for Intel Pentium 4 up to 2.8GH z CPU „ Bus Interface: PCI-ISA Bus and Mini PCI Local Bus support (no 3.3V output through goldfinger) „ Memory: One DDR socket supporting up to 512MB ®...

  • Page 9: Board Dimensions

    Board Dimensions...

  • Page 10: Unpacking

    Chapter 2 Unpacking Opening the Delivery Package The 3302670 is packed in an anti-static bag. The board has components that are easily damaged by static electricity. Do not remove the anti-static wrapping until proper precautions have been taken. Safety Instructions in front of this manual describe anti-static precautions and procedures.
  • Page 11 It is recommended that you keep all the parts of the delivery package intact and store them in a safe/dry place for any unforeseen event requiring the return shipment of the product. In case you discover any missing and/or damaged items from the list of items, please contact your dealer immediately.

  • Page 12: Hardware Installation

    +12V lead which should connect to PW2 connector of 3302670. NOTE: Since AD22 has been assigned for ISA bridge at 3302670, please make sure do not use this address for other PCI cards to avoid confliction. In order to get detailed information, please contact...

  • Page 13: Board Layout

    Board Layout...

  • Page 14: Jumper List

    USB Connectors Mini PCI Connector Configuring the CPU The 3302670 offers the convenience in CPU installation with its auto-detect feature. After installing a new microprocessor onboard, the 3302670 automatically identifies the frequency and clock speed of the installed microprocessor chip, thereby eliminating the need for user to...

  • Page 15: System Memory

    VGA Controller The onboard Intel 82845GV with 1MB or 8MB memory supports CRT display up to 1920 x 1200 x 32-bit at 60Hz. The 3302670 provides two methods of connecting VGA device. CN11 offers a single standard CRT connector (DB15), or DVI connector.

  • Page 16: Pci E-Ide Drive Connector

    PCI E-IDE Drive Connector ID1 and ID2 are standard 40-pin daisy-chain driver connector that serves the PCI E-IDE drive provisions onboard the 3302670. A maximum of four ATA/33/66/100 IDE drives can be connected to the 3302670 via IDE1 and IDE2.
  • Page 17 ID2: Secondary IDE Connector Description Description RESET SDATA 7 SDATA 8 SDATA 6 SDATA 9 SDATA 5 SDAT A 10 SDATA 4 SDAT A 11 SDATA 3 SDAT A 12 SDATA 2 SDAT A 13 SDATA 1 SDAT A 14 SDATA 0 SDAT A 15 SDREQ...

  • Page 18: Floppy Disk Drive Connector

    Floppy Disk Drive Connector The 3302670 uses a standard 34-pin header connector, FD1, for floppy disk drive connection. A total of two FDD drives may be connected to FD1 at any given time. z FD1: FDD Connector Description Description DRVDEN0...

  • Page 19: Serial Port Connectors

    3.10 Serial Port Connectors The 3302670 offers one NS16C550 compatible UARTs with Read/Receive 16-byte FIFO serial ports and two internal 10-pin headers. z CN5: COM1 Connector (5x2 Header) PIN Description PIN Description DCD0 DSR0 DCD0 DSR0 RXDD0 RTS0 RXDD0 RTS0...

  • Page 20: Parallel Connector

    3.11 Parallel Connector LP1 is a standard 26-pin flat cable connector designed to accommodate parallel port connection onboard the 3302670. z LP1: Parallel Connector Description PIN Description Strobe Auto Form Feed DATA 0 ERROR# DATA 1 Initialize DATA 2 Printer Select LN#...

  • Page 21: Ethernet Connector

    Short 1-2 Disabled Short 2-3 3.13 USB Connector The 3302670 provides one 8-pin USB2.0 connector at location US2 and two 4-pin USB1.1 connectors, at locations US1 and US3, for four USB connections to the 3302670. z US1: USB Connector PIN Description PIN Description...

  • Page 22: Cmos Data Clear

    3302670 provides one 20-pin and one 4-pin ATX power connectors at PW1 and PW2. 3302670 must use P4 power supply. One of 4-pin connectors is for +12V lead which should be connected to PW2. 20-pin ATX Power Connector can be connected to Backplane or to PW1.

  • Page 23: Keyboard/Mouse Connector

    +12V CN7: 2-pin ATX Power On/Off Switch Description Pull 220 to VCCSTBY PANSW IN FAN1 and FAN2 onboard 3302670 are 3-pin fan power connectors. z FAN1: Fan Power Connector Description +12V Fan In 1 z FAN2: Fan Power Connector Description...

  • Page 24: System Front Panel Connectors

    MCLK 3.17 System Front Panel Connectors The 3302670 has one LED at location CN3 that indicates the system front panel status. This visual feature of the HDD LED may also be connected to an external HDD LED via connector CN8.

  • Page 25: External Speaker

    3.18 External Speaker Aside from the buzzer at location BZ1 onboard, the 3302670 also offers a connector (CN2) for an external speaker connection. The table below lists the pin assignments of CN2. z CN2: Speaker Connector Description Speak In 3.19 Watchdog Timer Once the Enable cycle is active, a Refresh cycle is requested before the time-out period.

  • Page 26: Audio Connectors

    Disable, 01H = 1sec, 02H = 2sec…..FFH = 255sec. 3.20 Audio Connectors The 3302670 has an onboard AC97 3D audio interface. The following tables list the pin assignments of the CD-ROM Analog Input, the Line In and the MIC In/Line Out connectors.

  • Page 27: Mini Pci Connector

    3302670 supports a Mini PCI interface which is a very popular notebook computer expansion interface for Modem, Video, LAN, etc. The Mini PCI onboard 3302670 is at location PC1 with pin definitions listed on the table below. z PC1: Mini PCI Connector Pin Information...
  • Page 28 Description Description AD[9] AD[8] C/BE[0]# AD[7] 3.3V 3.3V AD[6] AD[5] AD[4] RESERVED AD[2] AD[3] AD[0] RESERVED_W IP2 AD[1] RESERVED_W IP2 AC_SYNC M66EN AC_SDATA_IN AC_SDATA_OUT AC_BIT_CLK AC_CODEC_IDO# AC_CODEC_ID1# AC_RESET# MOD_AUDIO_MON RESERVED AUDIO_GND SYS_AUDIO_OUT SYS_AUDIO_IN Mini PCI Socket pin orientation...
  • Page 29 This page is intentionally left blank.

  • Page 30: Award Bios Setup

    Chapter 4 Award BIOS Setup The 3302670 uses Award BIOS for the system configuration. The Award BIOS setup program is designed to provide the maximum flexibility in configuring the system by offering various options that could be selected for end-user requirements. This chapter is written to assist you in the proper usage of these features.

  • Page 31: Using Setup

    Using Setup In general, you use the arrow keys to highlight items, press <Enter> to select, use the <PageUp> and <PageDown> keys to change entries, press <F1> for help and press <Esc> to quit. The following table provides more detail about how to navigate the Setup program using the keyboard.

  • Page 32: Main Menu

    Main Menu Once you enter the Award BIOS CMOS Setup Utility, the Main Menu will appear on the screen. The Main Menu allows you to select from several setup functions and two exit choices. Use the arrow keys to select among the items and press <Enter> to enter the sub-menu. CMOS Setup Utility –...

  • Page 33: Standard Cmos Features

    Standard CMOS Features The Standard Setup is used for the basic hardware system configuration. The main function is for Data/Time and Floppy/Hard Disk Drive settings. Please refer to the following screen for the setup. When the IDE hard disk drive you are using is larger than 528MB, you must set the HDD mode to LBA mode.

  • Page 34: Advanced Bios Features

    Advanced BIOS Features This section allows you to configure your system for the basic operation. You have the opportunity to select the system’s default speed, boot-up sequence, keyboard operation, shadowing and security. CMOS Setup Utility Copyright ©1984-2001 Award Software Advanced BIOS Features Virus Warning Disabled Item Help...

  • Page 35: Advanced Chipset Features

    Advanced Chipset Features This section allows you to configure the system based on the specific features of the installed chipset. This chipset manages bus speeds and the access to the system memory resources, such as DRAM and the external cache. It also coordinates the communications between the conventional ISA and PCI buses.

  • Page 36: Integrated Peripherals

    Integrated Peripherals The IDE hard drive controllers can support up to two separate hard drives. These drives have a master/slave relationship that is determined by the cabling configuration used to attach them to the controller. Your system supports two IDE controllers--a primary and a secondary--so you can install up to four separate hard disks.

  • Page 37: Power Management Setup

    Power Management Setup The Power Management Setup allows user to configure the system for saving energy in a most effective way while operating in a manner consistent with his own style of computer use. CMOS Setup Utility Copyright ©1984-2001 Award Software Power Management Setup ACPI function Enabled...

  • Page 38: Pnp/Pci Configurations

    PnP/PCI Configurations This section describes the configuration of the PCI bus system. PCI, or Peripheral Components Interconnect, is a system that allows I/O devices to operate at speeds nearing the speed the CPU itself uses when communicating with its own special components. This section covers some very technical items and it is strongly recommended that only experienced users should make any changes to the default settings.

  • Page 39: Pc Health Status

    4.10 PC Health Status CMOS Setup Utility Copyright ©1984-2001 Award Software PC Health Status CPU Warning Temperature Disabled Item Help Current System Temp Menu Level Current CPU Temperature Current CPU FAN Speed XXXX RPM Change the day, month, Current System FAN Speed XXXX RPM year and century Vcore...

  • Page 40: Load Fail-Safe Defaults

    4.12 Load Fail-Safe Defaults When you press <Enter> on this item you will get a confirmation dialog box with a message shown below. This option allows you to load/restore the BIOS default values permanently stored in the BIOS ROM. Pressing ‘Y’ loads the BIOS default values for the most stable, minimal-performance system operations.

  • Page 41: Load Optimized Defaults

    4.13 Load Optimized Defaults When you press <Enter> on this item you get a confirmation dialog box with a message similar to the figure below. This option allows you to load/restore the default values to your system configuration, optimizing and enabling all high performance features. Pressing ‘Y’ loads the default values that are factory settings for optimal performance system operations.

  • Page 42: Set Supervisor/User Password

    4.14 Set Supervisor/User Password CMOS Setup Utility Copyright ©1984-2001 Award Software X Standard CMOS Features X Frequency/Voltage Control X Advanced BIOS Features Load Fail-Safe Defaults X Advanced Chipset Features Load Optimized Defaults X Integrated Peripherals Set Supervisor Password X Power Management Setup Set User Password X PnP/PCI Configurati t Setup...

  • Page 43: Save & Exit Setup

    When a password has been enabled, you will be prompted to enter it every time you try to enter Setup. This prevents an unauthorized person from changing any part of your system configuration. Additionally, when a password is enabled, you can also require the BIOS to request a password every time your system is rebooted.

  • Page 44: Exit Without Saving

    4.16 Exit Without Saving Pressing <Enter> on this item asks for confirmation: Quit without saving (Y/N)? Y This allows you to exit Setup without storing any change in CMOS. The previous selections remain in effect. This exits the Setup utility and restarts your computer.
  • Page 45 This Page is intentionally left blank.

  • Page 46: Software Utilities

    5.1.1 Installing Intel Chipset Software Utility Insert Utility CD Disk to your CD ROM drive. The main menu will pop up as shown below. Select on the 3302670 button to launch the installation program. Immediately after clicking the IDE button in Step 1, the program launches the InstallShield Wizard that will assist you in the installation process.
  • Page 47 The Intel OEM Software License Agreement dialog box then appears on the screen. Choose Yes to proceed. When the Readme Information dialog box pops up, just click on the Next button to proceed.
  • Page 48 Once the Install Shield Wizard finishes updating your system, it will prompt you to restart the computer. Tick on the Yes, I want to restart my computer now followed by a click on the Finish button to reboot. Only after your computer boots will the new settings take effect.
  • Page 49 5.1.2 Installing Intel Application Accelerator Insert Utility CD Disk into your CD ROM drive. The main menu will pop up as shown below. Select on the 3302670 button to launch the installation program. When the dialog box below appears, make sure you close all other Windows applications then click on the Next >...
  • Page 50 Setup will then prompt you to specify the path where you would like the Security driver installed. Select the Next > button after you have made your path/installation choice. Once the setup program finishes copying files into your system, it will prompt you to restart the computer.

  • Page 51: Vga Driver Installation

    5.2.1 Win 98 Insert Utility CD Disk into your CD ROM drive. The main menu will pop up as shown below. Select on the 3302670 button to launch the installation program. When the dialog box below appears, make sure you close all other Windows applications then click on the Next >...
  • Page 52 The Intel OEM Software License Agreement dialog box then appears on the screen. Choose Yes to proceed. Once the setup program finishes copying files into your system, it will prompt you to restart the computer. Tick on the Yes, I want to restart my computer now followed by a click on the Finish button to reboot.
  • Page 53 Please make sure you have already installed Service Pack 6.0. Insert Utility CD Disk into your CD ROM drive. The main menu will pop up as shown below. Select on the 3302670 button to launch the installation program. When the dialog box below appears, make sure you close all other Windows applications then click on the Next >...
  • Page 54 The Intel OEM Software License Agreement dialog box then appears on the screen. Choose Yes to proceed. Once the setup program finishes copying files into your system, it will prompt you to restart the computer. Tick on the Yes, I want to restart my computer now followed by a click on the Finish button to reboot.
  • Page 55 5.2.3 Win 2000 Insert Utility CD Disk into your CD ROM drive. The main menu will pop up as shown below. Select on the 3302670 button to launch the installation program. When the dialog box below appears, make sure you close all other Windows applications then click on the Next >...
  • Page 56 The Intel OEM Software License Agreement dialog box then appears on the screen. Choose Yes to proceed. Once the setup program finishes copying files into your system, it will prompt you to restart the computer. Tick on the Yes, I want to restart my computer now followed by a click on the Finish button to reboot.
  • Page 57 5.3.1 Win 98 Insert Utility CD Disk into your CD ROM drive. The main menu will pop up as shown below. Select on the 3302670 button to launch the installation program. When the dialog box below appears, make sure you close all other Windows applications then click on the Next >...
  • Page 58 The Intel OEM Software License Agreement dialog box then appears on the screen. Choose Accept to proceed. The Setup Type dialog box then appears on the screen. Choose Typical to proceed.
  • Page 59 When the dialog box below appears, make sure you close all other Windows applications then click on the Install button to proceed. When the dialog box below appears, it means your driver is install completed. Click Finish button to proceed.
  • Page 60 Once the setup program finishes copying files into your system, it will prompt you to restart the computer. Tick on the Yes to reboot. Only after your computer boots will the new settings take effect. 5.3.2 Win NT NOTE: Please make sure you have already installed Service Pack 6.0. The system automatically detects the absence of Windows NT Networking.
  • Page 61 Click on the Start Search button for the program to locate the Network Adapter. Once setup finishes the search, it will list a number of adapters for you to choose from. Press on the Have Disk button to assign the driver path location.

  • Page 62: Lan Driver Installation

    Setup now asks you for the location of the driver. When you have entered the new driver path, press on the OK button to continue. When Setup finds the information it needs about the new driver, it will display the device it found on the following screen. If using 82551 or 82562, please choose Intel(R) PRO/100 Family Adapter .
  • Page 63 Setup then returns to Network Setup Wizard screen and displays your new Network Adapter. Click on Next to continue. The Network Setup Wizard then allows you to set the Network Protocols on your network. Select the appropriate protocol and then click on Next to continue.
  • Page 64 Before Setup starts installing the components found and the settings you made, it will give you the option to proceed or go back for changes from the following screen. Click on the Next button once you are sure of your devices. 10.
  • Page 65 12. Setup then starts the Networking installation and copies the files. 13. When the screen below appears, click on Next to continue. 14. Setup then prompts you that it is ready to start the network. You may complete the installation thereafter. Click on Next to continue.
  • Page 66 15. Assign the workgroup or domain setting of your computer. Click on Next to continue. 16. Click on the Yes button to restart your computer. The LAN1 driver installation for WIN NT4.0 is now complete.
  • Page 67 17. With the Utility CD Disk still in your CD ROM drive, we can install LAN2. Right click on Network Neighborhood icon from the desktop. Select on Properties and then proceed to the Network from the main menu. Click on Add to continue. 18.

  • Page 68: Audio Driver Installation

    Audio Driver Installation Insert Utility CD Disk into your CD ROM drive. The main menu will pop up as shown below. Select on the 3302670 button to launch the installation program. When the dialog box below appears, make sure you close all other Windows applications then click on the Next >...
  • Page 69 USB2.0 Driver Installation 5.5.1 Win 98 With the Utility CD Disk still in your CD ROM drive, right click on My Computer icon from the Windows menu. Select on System Properties and then proceed to the Device Manager from the main menu.
  • Page 70 Select on Other Devices from the list of devices then double-click on PCI Universal Serial Bus. The PCI Universal Serial Bus Properties screen then appears, allowing you to re-install the driver. Select Driver from the main menu to proceed.
  • Page 71 When the dialog box below appears, make sure you close all other Windows applications then click on the Next > button to proceed. Tick on the Search for a better driver once the following screen appears. Click on the Next to proceed.
  • Page 72 Once the program returns to the Add New Hardware Wizard screen, your specified location will appear. Press on the Next button to continue When Setup finds the information it needs about the new driver, it will display the device it found on the following screen. Press on the Next button to accept and proceed.
  • Page 73 Once the InstallShield Wizard completes the operation and update of your USB2.0 driver. Click on the Finish button to complete the installation process. 5.5.2 Win 2000 With the Utility CD Disk still in your CD ROM drive, right click on My Computer icon from the Windows menu.
  • Page 74 The PCI Universal Serial Bus Properties screen then appears, allowing you to re-install the driver. Select Driver from the main menu to proceed. When the dialog box below appears, make sure you close all other Windows applications then click on the Next > button to proceed.
  • Page 75 Tick on the Search for a suitable driver once the following screen appears. Click on the Next to proceed. Once the program returns to the Add New Hardware Wizard screen, your specified location will appear. Press on the Next button to continue...

  • Page 76: Usb2.0 Driver Installation

    Choose sisusb2.inf and press on the Open button to accept and proceed. Once the InstallShield Wizard completes the operation and update of your USB2.0 driver. Click on the Finish button to complete the installation process.
  • Page 77 5.5.3 Win XP Insert Utility CD Disk into your CD ROM drive. The main menu will pop up as shown below. Select on the 3302670 button to launch the installation program. When the dialog box below appears, make sure you close all other Windows applications then click on the Next >...
  • Page 78 Once the InstallShield Wizard completes the operation and update of your USB2.0 driver. Click on the Finish button to complete the installation process.
  • Page 79 This page is intentionally left blank.
