  • Page 1 3307553 Full-size Single Board Computer User’s manual Edition...
  • Page 2 Copyright © Copyright 2003 - 2004. All rights reserved. This document is copyrighted and all rights are reserved. The information in this document is subject to change without prior notice to make improvements to the products. This document contains proprietary information and protected by copyright. No part of this document may be reproduced, copied, or translated in any form or any means without prior written permission of the manufacturer.

  • Page 3: Packing List

    Packing List: Please check the package material before you install the system. Hardware: 3307553 Single Board Computer x 1 Cable Kit: Floppy flat cable x 1 40-pin ATA100 IDE flat cable x 1 DB25 & DB9 cable with bracket x 1...

  • Page 4: Other Accessories

    CPU Cooler x 1 Audio cable with bracket x 1 4-pin to 3-pin ATX cable x 1 PS/2 Keyboard & Mouse Cable x 1 Other Accessories: Divers CD (including User’s Manual)
  • Page 5 Index Chapter 1 <Introductions> ................... 7 1.1 < Product Overview>................7 1.2 <Product Specifications>................8 1.3 <Component Placement> ..............10 1.4 <Block Diagram>..................11 Chapter 2 <Hardware Setup>................13 2.1 <Connectors Location> ................13 2.2 <Jumper Reference> ................14 2.3 <Connectors Reference> ............... 15 2.3.1 <Internal Connectors>...
  • Page 6 2.12 <GPIO interface> ................. 31 2.13 <Switch and Indicator>................. 32 Chapter 3 <Display Mode Setup> ..............33 Chapter 4 <BIOS Setup> ..................37 Appendix A <I/O ports pin assignment>............39 A.1 <IDE Port> ..................... 39 A.2 <Floppy Port> ..................40 A.3 <...
  • Page 7 Chapter 1 <Introductions> 1.1 < Product Overview> The 3307553 is an all-in-one single board computer with PICMG interface. Based on Intel Mobile solutions with 855GME chipset, it supports Intel Pentium M processor with socket479, DDR266/333 SDRAM up to 2GB of capacity, Intel Extreme Graphics 2 Technology of onboard VGA display interface, AC97 2 channel audio, USB2.0 interface...
  • Page 8 1.2 <Product Specifications> General Specification Form Factor Full-size PICMG CPU card Intel Pentium M Processor with FC-PGA478/FC-BGA479 Battery Mode is not supported Intel Speed Step Technology function is not supported Memory 2GBytes DDR200/266/333 SDRAM on one 184-pin DIMM socket ECC is supported Chipset Intel 82855GME GMCH and 82801DB ICH4 BIOS...
  • Page 9 C (32 ~ 140 Storage within -20 ~ 85 C (-4 ~ 185 Ordering Code 3307553 Full-size PICMG single board computer with Intel Socket 479 Pentium-M processor Motherboard with Intel onboard VGA, Dual LAN, Audio, Hi-Speed USB 2.0, Compact Flash socket and LVDS...
  • Page 10 1.3 <Component Placement> Intel 82540EM Gigabit LAN Compact Flash Socket Intel 82562ET ISA Bridge Super I/O BIOS ICH4 Audio Codec Mini-AGP 2 x DDR266/333 DIMM Intel 855GME up to 2GB Intel Pentium M Processor at 400MHz FSB...
  • Page 11 1.4 <Block Diagram> Intel Pentium M processor with FC-PGA2/FC-BGA2 400MHz FSB 2 x 184-pin DDR266/333 DIMM LVDS Up to 2GB 4xAGP Mini-AGP 855GME 82562ET LAN UltraATA100 ATAPI Devices PCI Bus USB2.0 USB Devices ICH4 Audio AC97 Codec Gigabit Ethernet Controller ISA Bus IrDA PS/2...
  • Page 12 This page left blank intentionally...
  • Page 13 Chapter 2 <Hardware Setup> 2.1 <Connectors Location> RJ45_1 RJ45_2 PS/2 CN_USB2 CN_ATKB CN_COM2 CN_IR CN_USB1 CN_COM1 CN_WOL SYSFAN CN_VGA CN_LPT IDE2 IDE1 CN_AUDIO MINI_AGP CDIN DIMM1 DIMM2 CN_LVDS CN_INV CN_PS CN_DIO JFRNT CPUFAN CN_P...
  • Page 14 2.2 <Jumper Reference> Jumper Function JRTC CMOS Operating/Clear Setting JCFSEL Compact Flash Addressing Setting JDOM IDE1 Pin-20 voltage setting JVLCD LCD Panel Voltage Setting JLAN Ethernet Controller Enable/Disable Setting JLAN JCFSEL JDOM JRTC JVLCD...
  • Page 15 2.3 <Connectors Reference> 2.3.1 <Internal Connectors> Connector Function Remark mPGA479 CPU socket Standard DIMM1/2 184 -pin DDR SDRAM DIMM socket Standard IDE1 40-pin primary IDE connector Standard IDE2 44-pin secondary IDE connector Standard 34-pin floppy connector Standard CN_VGA 8 x 2-pin VGA connector (pitch = 2.0mm) Standard CN_USB1/2 5 x 2-pin USB connector (pitch =2.54mm)
  • Page 16 2.4 <System Setup> 2.4.1 <CPU Installation> 3307553 has one 479-pin CPU socket to support Intel Pentium M 478-pin processor. Please follow the instruction to install the processor well. CPU Socket 2. Find the pin direction and 1. Use flat-type Screw Driver to...
  • Page 17 2.4.2 <Memory Module Installation> 3307553 supports two DDR266/333 SDRAM sockets up to 2GB of capacity. It also supports ECC (error- correcting code function. DIMM1/2 104-pin 80-pin Please check the pin number to match the socket side well before installing memory module.
  • Page 18 2.4.3 <CPU Cooler Installation> There is a cooler attached with the board package, please follow the instructions to install the cooler on the processor. 1. Remove the sticker of the base. 2. Put the base through the fixing hole of the processor and paste on the solder side. Then put the cooler through the base pillar.
  • Page 19 2.4.4 <Complete the system installation> After installing the CPU, CPU cooler and the memory module, please slot the main board into PICMG slot of the backplane carefully. If you connect an ATX power supply with the backplane, you will need to connect an ATX function cable between the main board and the backplane.
  • Page 20 2.5 <CMOS Setup> The board’s data of CMOS can be setting in BIOS. If the board refuses to boot due to inappropriate CMOS settings, here is how to proceed to clear (reset) the CMOS to its default values. Jumper: JRTC Type: Onboard 3-pin jumper JRTC Mode...
  • Page 21 2.6 <Watchdog Timer Setting> The watchdog timer makes the system auto-reset while it stops to work for a period. The integrated watchdog timer can be setup as system reset mode by program. Timeout Value Range - 1 to 255 - Second or Minute Program Sample Watchdog timer setup as system reset w t i h 5 second of timeout 2E, 87...
  • Page 22 DOM (DiskOnModule) or M-systems DiskOnChip IDE Pro flash disk with or without the additional VCC power cable. The 3307553 also supports Compact Flash Card Type I/II interface. The jumper JCFSEL provides you to setup the CF card on master or slave mode.
  • Page 23 2.8 <Power and Fan Setup> 3307553 has one 4-pin power input connector expect PICMG bus powering; it also has two fan connectors. For ATX function, you should connect the ATX connector on the backplane with CN_PS on 3307553. Connector: CN_PWR...
  • Page 24 2.9 <Display Interface> 2.9.1 <Analog VGA interface> The board is integrated with Intel 855GM GMCH chipset built-in Intel Extreme Graphics 2 with 266 MHz VGA core, 256-bit 3D engine and Intel Dynamic Video Memory up to 64MBytes shared with system memory. The CRT / analog VGA interface includes one external DB15 female connector on bracket and one 8 x 2-pin header connector on board.
  • Page 25 2.9.2 <Digital VGA interface> The board provides one 20 x 2-pi DS interface for LCD panel, it supports 18/24-bit V n L single/dual channel up to 1600 x 1200 of resolution. The jumper JVLCD can let you select your panel whether supports +5V or +3.3V of voltage, and the CN_INV provides panel inverter interface includes backlight controlling and powering.
  • Page 26 Connector: CN_INV Connector: JVLCD Type: 5-pin LVDS Power Header Type: 3-pin Power select Header Description Description +12V LCDVCC VCC3 ENABKL Connector: CN_LVDS Type: onboard 40-pin connector for LVDS connector Connector model: HIROSE DF13-40S Signal Signal LCDVCC LCDVCC BTX0- ATX0- BTX0+ ATX0+ BTX1- ATX1-...
  • Page 27 LCD installing guide: Prepare a panel, inverter and 3307553. 3307553 Inverter LCD panel Please check the datasheet of the panel to see the voltage of the panel, and set the jumper JVLCD to +5V or +3.3V. Prepare a LVDS type LCD cable...
  • Page 28 After setting up the devices, you need to select the LCD panel type in the BIOS. The panel type mapping is list below: BIOS panel type selection form For 18-bit color For 24-bit color Output for Output format 640 x 480 1024 x 768 800 x 600 1280 x 1024 Dual Channel...
  • Page 29 2.10 < Ethernet Network Interface> The 3307553 is integrated with one Intel 82562ET PRO/100+ Ethernet interface at the type of 10Base-T/100Base-TX auto-switching Ethernet with full duplex and IEEE 802.3U compliant. The secondary Ethernet controller is Intel 82540EM PRO/1000+ at the type of 10Base-T/100Base-TX/1000Base-T auto-switching Ethernet with full duplex and IEEE 802.3U compliant.
  • Page 30 2.11 <Audio Interface> 3307553 provides a stereo audio interface with Realtek ALC201A AC97 Codec. The CN_AUDIO provides the interface to use attached audio cable, the CDIN can let you connect audio output from CD-ROM drives. Connnector: CN_AUDIO Type: 10-pin (2 x 5) 2.54-pitch header...
  • Page 31 2.12 <GPIO interface> The board offers 8-bit digital I/O to customize its configuration to your control needs. For example, you may configure the digital I/O to control the opening and closing of the cash drawer or to sense the warning signal from a tripped UPS. The following is a detailed description of how the digital I/O is controlled via software programming.
  • Page 32 2.13 <Switch and Indicator> The JFRNT provides front control panel of the board, such as power button, reset and beeper, etc. Connector: JFRNT Type: onboard 14-pin (2 x 7) 2.54-pitch header Function Signal Signal Function VCC(+) (+) VCC IDE LED Power A t c ive Reset...
  • Page 33 Chapter 3 <Display Mode Setup> This chapter shows you how to setup the display device under Windows OS. e B fore you using your display device: 1. Check your software Before you can use the display device properly, please install the VGA driver. 2.
  • Page 34 For advanced display settings, please click Advanced… button and choose Intel(R) Extreme Graphics. Please click Graphics Properties button to enter the advanced setup.
  • Page 35 While you entering the Graphics Properties, you will see the options below: This option can let you configure the CRT monitors for Colors, Screen Area (Resolution) and Refresh Rate. This option can let you configure the LCD panel for Colors, Screen Area (Resolution) and Full Screen option.
  • Page 36 This option can let you configure the Dual Display for clone mode (same display on two devices) This option can let you configure the Dual Display for Extended Desktop mode...
  • Page 37 Chapter 4 <BIOS Setup> The single board computer uses the Award BIOS for the system configuration. The Award BIOS in the single board computer is a customized version of the industrial standard BIOS for IBM PC AT-compatible computers. It supports Intel x86 and compatible CPU architecture based processors and computers.
  • Page 38 This page left blank intentionally...
  • Page 39 Appendix A <I/O ports pin assignment> A.1 <IDE Port> Connector: IDE1/2 Type: 40-pin (20 x 2) box header Description Description Reset Ground Ground Ground IOW-/STOP Ground IOR-/HDMARDY Ground IORDY/DDMARDY IDESEL DACK- Ground CBLID CS0 (MASTER CS) CS1 (SLAVE CS) LED ACT- Ground IDE2 IDE1...
  • Page 40 A.2 <Floppy Port> Connector: FDD Type: 34-pin (2 x 17) 2.54-pitch header Description Description Ground DRIVE DENSITY SELECT 0 Ground DRIVE DENSITY SELECT 1 Ground Ground INDEX- Ground MOTOR ENABLE A- Ground DRIVER SELECT B- Ground DRIVER SELECT A- Ground MOTOR ENABLE B- Ground DIRECTION-...
  • Page 41 A.3 < Parallel Port> Connector: CN_LPT Type: 26-pin (2 x 13) 2.54-pitch box header Description Description STROB - E AUTO FEED- ERROR- INITIALIZE- SELECT INPUT- Ground Ground Ground Ground Ground ACKNOWLEDGE- Ground BUSY Ground PAPER EMPTY Ground SELECT+ CN_LPT...
  • Page 42 A.4 <Serial Port> A.4.1 <Internal COM1/2> Connector: CN_COM1/2 Type: 10-pin (2 x 5) 2.54-pitch header Description Description Ground CN_COM2 CN_C M1 O...
  • Page 43 A.5 <USB Port> Connector: CN_USB1, CN_USB2 Type: 10-pin (2 x 5) header for dual USB Ports Description Description Data0- Data1- Data0+ Data1+ Ground Ground Ground CN_USB1 CN_USB2 A.6 <IrDA Port> Connector: CN_IR Type: 5-pin (1 x 5) 2.54-pitch header for SIR Port Description IRRXD Ground...
  • Page 44 A.7 <VGA Port> Connector: VGA Type: 15-pin D-sub female connector on bracket Description Description Description Ground GREEN Gr u o 5VCDA BLUE HSYNC Ground VSYNC Ground Ground 5VCLK...
  • Page 45 A.8 <LAN Port> A.8.1 < Ethernet Co t n roller> Connector: RJ45_1 Type: RJ45 connector with LED on bracket D s e cription X- R A.8.2 <Gigabit Ethernet Controller> Connector: RJ45_2 Type: RJ45 connector with LED on bracket Description TRD0+ TRD0- TRD1+ TRD1- Description NC TRD2+ TRD2- TRD3+ TRD3- RJ45_1...
  • Page 46 A.9 <AT Keyboard Port> Connector: CN_ATKB Type: 5-pin box header Description DATA Ground CN_ATKB A.10 <PS/2 Keyboard & Mouse Port> Connector: PS2 Type: 6-pin Mini-DIN connect r on brack o Description Ground Note: The PS/2 connector supports standard PS/2 keyboard directly or both PS/2 keyboard and mouse through the PS/2 Y-type cable.

  • Page 47: Bios Auto Flash Tool

    Appendix B <Flash BIOS> B.1 BIOS Auto Flash Tool The board is based on Award BIOS and can be updated easily by the BIOS auto flash tool. You can download the tool online at the address below: http://www.award.com File name of the tool is “awdflash.exe”, it’s the utility that can write the data into the BIOS flash ship and update the BIOS.
  • Page 48 This page left blank intentionally...
  • Page 49 Appendix C <Watchdog Timer Programming Guide> WDT source from : WinBond 83627HF (1) General Description Winbond has a WDT feature inside its chip. We implement its function into our circuit . There are many configuration Registors ( CR ) in 83627HF. The following sequence must be followed for CR programming : (*1) Enter the extended function mode (*2) Configure...
  • Page 50 ** Chip ( Global ) Control Register ( CCR ) : CR02 -->CR2F. CR07 = Logical Device Number Register ( LDNR ) ** Logical Device 0 ( LD0 ) = FDC , with CR : CR30 -->CRF5 . When LDNR (= CR07) = 00h , you can program the CR30 --CRF5 related to FDC f a e ture .
  • Page 51 LD8-CRF7- Bit[3..0] : Select IRQ resource for WDT time-out ( Setting of 2 selects SMI ) (3) WDT Programmimg guide Step 1 . Enter extended function mode as mentioned as above. Step 2 . Program WDT relat (2-1) CR2B-b[4]P[0] ; Set pin output as WDT function (2-2) CR07-P08h ;...
  • Page 52 MOV DX,2Fh MOV AL,08H OUT DX,AL ; select logical device 8 MOV DX,2Eh MOV AL,0F5H OUT DX,AL MOV DX,2Fh AL,DX AL,08h ; SELECT MINUTE MOV AH,AL MOV DX,2Eh MOV AL,0F5h OUT DX,AL MOV DX,2Fh MOV AL,AH OUT DX,AL MOV DX,2Eh ;...

  • Page 53: Contact Information

    Contact Information Any advise or comments about our products or service, or anything we can help you with, please don’t hesitate to contact us, we will do our best to service you. Global American Inc. Address 17 Hampshire Drive Hudson...
