User's Manual
Single Board Computer 3307114
Version 1.0, 2004

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3307114 and is the answer not in the manual?

Questions and answers

Related Manuals for Global American 3307114

Summary of Contents for Global American 3307114

  • Page 1 User’s Manual Single Board Computer 3307114 Version 1.0, 2004...
  • Page 2 Copyrights This manual is copyrighted and all rights are reserved. It does not allow any non authorization in copied, photocopied, translated or reproduced to any electronic or machine readable form in whole or in part without prior written consent from the manufacturer.
  • Page 3 (Universal Serial Bus) ports provide high-speed data communication between peripherals and PC. 3307114 was designed to meet all kind of applied computing application. It is built not only to satisfy the requirements for Internet application's high computing performance and advanced LAN system but also for CTI application.
  • Page 4 Introduction 1-2 Check List The 3307114 package should cover the following basic items with the Quick Installation Guide. ü One 3307114 board computer ü One Parallel port cable kit ü One serial port cable to support two interfaces ü One FDC cable ü...
  • Page 5 Floppy Drive Interface Support one FDD port up to two floppy drives and 5-1/4"(360K, 1.2MB), 3-1/2" (720K, 1.2MB, 1.44MB, 2.88MB) diskette format and 3-mode FDD Serial Ports Support two high-speed 16C550 compatible UARTs with 16- byte T/R FIFOs 3307114 User’s Manual...
  • Page 6 Support two USB (Universal Serial Bus) ports for high-speed I/O peripheral devices Note: For a standalone application, both USB ports may be available. For installing 3307114 in a standard Chassis, physical limitation will only allow one USB port to be available. PS/2 Mouse and Keyboard Interface...
  • Page 7 PCB layout : 6 layer Power Requirements : +5V @8A, +12V @150mA, -12V @20mA Operating Temperature : 0°C ~ 55°C ( 32°F ~ 131°F ) Storage Temperature : -20°C ~ 75°C (-4°F ~ 167°F) l Relative Humidity : 5% 3307114 User’s Manual...

  • Page 8: System Architecture

    Introduction 1-4 System Architecture The most up-to-date system architecture of 3307114 includes two main VIA chips, VT8601A (Graphics and Memory Controller) to supportCeleron/Pentium III processor, SDRAM, 2D/3D graphic display, and VT82C686B (I/O Controller) supports PCI bus interface, APM, ACPI compliant power management, USB port, SMBus communication, and Ultra DMA/33/66/100 IDE Master.
  • Page 9 The jumper settings are used to select options for different features. The adjustment made aims to let users customize 3307114’ s features. In the following sections, short means covering a jumper cap over jumper pins; open or NC (Not Connected) means removing a jumper cap from jumper pins.
  • Page 10 DiskOnChip Jumper Setting (JP6) Function D8000-D9FFF ê Short DA000-DBFFF Short DC000-DDFFF Short Short DE000-DFFFF 2-2 Connector Allocation I/O peripheral devices and flash disk are connected to the interface connectors and DOC socket on this single board computer (Figure 2-2) 3307114 User’ s Manual...
  • Page 11 PS/2 Keyboard& Mouse connector 68 pins PCI connector External Keyboard connector FAN power connector PIN1 : GND PIN2 : +12V PIN3 : Pull-up +3V ( Reserved for sense signal) Standard P8 power connector VGA DSUB-15 connector 3307114 User’ s Manual...
  • Page 12 Data 12 Data 2 Data 13 Data 1 Data 14 Data 0 Data 15 Ground DMA REQ Ground IOW# Ground IOR# Ground IOCHRDY Pull-down DMA ACK# Ground INT REQ CBLID# HDC CS0# HDC CS1# HDD Active# Ground 3307114 User’ s Manual...

  • Page 13: Table Of Contents

    J10/ J11 : Serial Port-1/ Port-2 Connector (2 x 5 shrouded header) PIN No. S ignal Description Data Carrier Detect (DCD) Receive Data (RXD) Transmit Data (TXD) Data Terminal Ready (DTR) Ground (GND) Data Set Ready (DSR) Request to Send (RTS) Clear to Send (CTS) 3307114 User’ s Manual...

  • Page 14: Ground

    PIN No. S ignal Description PIN No. S ignal Description USBD0- USBD0+ USBGND0 USBD1- USBD1+ USBGND1 J17/ J21 : Chassis/ CPU Fan Power Connector PIN No. S ignal Description Ground +12V Pull-up 5V (Reserved for sense signal) 3307114 User’ s Manual...

  • Page 15: Data

    Reserved for PERR# SERR# REQ#4 GNT#4 Reserved for REQ#3 Reserved for GNT#3 60 PCI Clock1 PCI Clock2 PCIRST# LOCK# IRQ#A IRQ#B IRQ#C IRQ#D J20 : External Keyboard Connector PIN No. S ignal Description Keyboard Clock Keyboard Data Ground 3307114 User’ s Manual...

  • Page 16: Ground

    Hardware Configuration J22 : Standard P8 power connector PIN No. S ignal Description +12V J23 : VGA DSUB-15 Connector PIN No. S ignal Description Ground Ground Ground Ground Ground MONID1 HSYNC VSYNC MONID2 3307114 User’ s Manual...

  • Page 17: Ground

    1.3 CPU Jumper Setting Table (SW1) SW1 DIP switch settings for CPU core/bus ratio SW-1 SW-2 SW-3 SW-4 CORE/BUS RATIO 1.5x 2.0x 2.0x 2.5x 3.0x 3.5x 4.0x 4.5x 5.0x 5.5xê 6.0x 6.5x 7.0x 7.5x 8.0x Reserved 3307114 User’ s Manual...

  • Page 18: Ground

    Configuring System Bus 3307114 will automatically detect system bus based on the type of CPU used. CPU speed of Intel PIII can be detected automatically, Celeron needs jumper switch setting to operate correctly.
  • Page 19 System Installation 3-2 Main Memory 3307114 provides three DIMMs (168-pin Dual In-line Memory Module) to support 3.3V SDRAM (Synchronized DRAM) as onboard main memory. The maximum memory size can be up to 1GB. Auto detecting memory clock according to BIOS CMOS settings.

  • Page 20: Ground

    System Installation 3-3 M-systems Flash Disk 3307114 reserves one 32-pin DIP sockets for installing M-systems Flash disk from 2MB to 288MB. This operation structure is running with pure ISA-bus without PnP (Plug and Play) function. Before installing, make sure that I/O address jumper setting is set on right position to prevent unworkable system due to I/O resource conflict.

  • Page 21: Chipset Component Driver

    3-4-1 Chipset Component Driver The chipset on 3307114 is a new chipset that a few old operating systems might not be able to recognize. To overcome this compatibility issue, for Windows Operating Systems such as Windows-95/ 98/ 98SE/ 2000, please install VIA 4-in- 1 driver before any of other Drivers are installed.

  • Page 22: Ground

    Display Control Panel and update graphics driver. (4) Windows-2000: Please bring up the Device Manager and update graphics drivers. (5) Redhat Linux V6.2: Please refer to the related documentation in for graphic drivers installation. 3307114 User’s Manual...
  • Page 23 3-4-4 Onboard 68-pin PCI connector 3307114 provides one onboard 68-pin PCI connector that allows you to apply additional PCI devices, such as SCSI or Ethernet. If you have a compatible PCI device, simply plug it onto the connector and secure it with two retention bars.

  • Page 24: Ground

    Move the JP4 back to 1-2 position (Normal Operation) and start the system. System will then produce a “CMOS Check Sum Error” message and hold up. Users may then follow the displayed message to load in BIOS default setting. 3307114 User’s Manual...

  • Page 25: Entering Setup

    CHAPTER 4 BIOS Setup Information 3307114 is equipped with the AMI BIOS stored in Flash ROM. This BIOS has a built-in Setup program that allows users to modify the basic system configuration easily. This type of information is stored in CMOS RAM so that it is retained during power-off periods.

  • Page 26: Ground

    Save all the CMOS changes and exit 4.2 Main Menu Once you enter 3307114 AMI BIOS CMOS Setup Utility, you should start with the Main Menu. The Main Menu allows you to select from eleven setup functions and two exit choices. Use arrow keys to switch among items and press <Enter> key to accept or bring up the sub-menu.
  • Page 27 BIOS Setup Information Standard CMOS Setup for changing time, date, hard disk type, etc. NOTE : It is str ongly recommended to reload Optimal Setting if CMOS is lost or BIOS is updated. 3307114 User’ s Manual...

  • Page 28: Ground

    Not Installed 32Bit Type Size Cyln Head WPcom Sec Mode Mode Mode Mode Pri Master Auto Pri Slave Auto Sec Master Auto Sec Slave Auto Boot Sector Virus Protection Disabled Month: Jan – Dec ESC : Exit 3307114 User’ s Manual...
  • Page 29 This setup reference table includes all the Optimal, Failsafe, and Other options setting in each BIOS setup item. It is very easy to cross reference. If you want to go details, you can directly refer to item description in sub-section. 3307114 User’ s Manual...

  • Page 30: Ground

    Enabled, Disabled CC00, 16K Shadow Cached Cached Enabled, Disabled D000, 16K Shadow Disabled Disabled Cached, Enabled D400, 16K Shadow Disabled Disabled Cached, Enabled D800, 16K Shadow Disabled Disabled Cached, Enabled DC00, 16K Shadow Disabled Disabled Cached, Enabled 3307114 User’ s Manual...
  • Page 31 IRQ7 Monitor Ignore Ignore IRQ9 Ignore Ignore Monitor IRQ10 Ignore Ignore Monitor IRQ11 Ignore Ignore Monitor IRQ13 Ignore Ignore Monitor IRQ14 Monitor Ignore Ignore IRQ15 Ignore Ignore Monitor System Thermal Disabled Disabled Enabled Thermal Activite Temperature 3307114 User’ s Manual...

  • Page 32: Ground

    PCI/ PnP ISA/ EISA IRQ11 PCI/ PnP PCI/ PnP ISA/ EISA IRQ12 PCI/ PnP PCI/ PnP ISA/ EISA IRQ14 PCI/ PnP PCI/ PnP ISA/ EISA IRQ15 PCI/ PnP PCI/ PnP ISA/ EISA OnBoard IDE Both Auto 3307114 User’ s Manual...
  • Page 33 BIOS setup and system has no keyboard attached. Pr imar y Display Chooses Absent, VGA/EGA, CGA40x25, CGA80x25, or Mono to meet your monitor type. If you select Absent, the “CMOS Display Type Wrong” message will be ignored regardless the mismatched display card. 3307114 User’ s Manual...

  • Page 34: Ground

    In general, C000 64k will be allocated for VGA BIOS and set to Cached to get higher display performance by shadowing and caching feature. If user chooses Enabled setting, only BIOS shadow function is active. 4.6 Advanced Chipset Setup Menu 3307114 User’ s Manual 4-10...
  • Page 35 This option allows the end users tospecify the location of a memory hole for memory space requirement from ISA-bus cards. USB Contr oller This option will enable on-chip USB function to support USB peripheral devices. 3307114 User’ s Manual 4-11...

  • Page 36: Ground

    Full-On power state before the computer is placed in Standby mode. When this length of time expires, the computer enters Standby Timeout state. In Standby mode, some power use is curtailed. Suspend Time out (Minute) 3307114 User’ s Manual 4-12...
  • Page 37 The overall system performance will be reduced to half. This option is a trad-off of system performance and stability and configurable by user. The default setting is Ignore. You can choose Monitor setting to enable this thermal function. 3307114 User’ s Manual 4-13...

  • Page 38: Ground

    This item will be used to wake up system from remote ringing control under Soft Off condition. If you choose “Disabled” setting, the system will be not resumed by modem ring. Resume On RTC Alar m This option controls an unattended or automatic system power up 3307114 User’ s Manual 4-14...
  • Page 39 BIOS Setup Information l RTC Alarm Date l RTC Alarm Hour l RTC Alarm Minute l RTC Alarm Second 3307114 User’ s Manual 4-15...

  • Page 40: Ground

    PCI specification 2.1 or later and PCI bus frequency in system, user can select different timer to meet their PCI bus environment. Pr imar y Gr aphics Adapter This option allows user to specify a primary VGA display from two options : Onboard VGA or PCI VGA card. 3307114 User’ s Manual 4-16...
  • Page 41 IRQs passed to devices that are configurable by the system BIOS. The available IRQ pool is determined by reading the ESCD NVRAM. If more IRQs must be removed from the pool, the end user can use these PCI/PnP Setup to 3307114 User’ s Manual 4-17...

  • Page 42: Ground

    There are four optional items Parallel Port Mode, EPP Version, Parallel Port IRQ, and Parallel Port DMA Channel used to control onboard parallel port interface while user select I/O base address manually. The following lists are available options of onboard parallel port : 3307114 User’ s Manual 4-18...
  • Page 43 Disabled à onboard parallel port function is ineffective and N/A 378h à locate IRQ7 for this default I/O address 278h à assign this I/O address to LPT1 3BCh à assign this I/O address to LPT1 3307114 User’ s Manual 4-19...

  • Page 44: Ground

    BIOS detects the terminal error, the value at port 80H will be the last test performed. In this case, the terminal error cannot be displayed on the screen. The following POST checkpoint codes are valid for all AMIBIOS products with a core BIOS date of 07/15/95 version 6.27 (Enhanced). 3307114 User’ s Manual 4-20...
  • Page 45 — The bootblock recovery checkpoint hex codes are listed in order of execution : Code Descr iption The onboard floppy controller if available is initialized. Next, beginning the base 512KB memory test. Initializing the interrupt vector table next. 3307114 User’ s Manual 4-21...

  • Page 46: Ground

    To initialize CMOS if the initialize CMOS RAM in every boot is set or the <End> key is pressed. Going to disable DMA and Interrupt controllers. The video display has been disabled. Port B has been initialized. Next, initializing the chipset. 3307114 User’ s Manual 4-22...
  • Page 47 The memory wraparound test has completed. The memory size calculation has been done. Writing patterns to test memory next. The memory pattern has been written to extended memory. Writing patterns to the base 640 KB memory test. 3307114 User’ s Manual 4-23...
  • Page 48 A keyboard reset error or stuck key was found. Issuing the keyboard Controller interface test command next. The keyboard controller interface test completed. Writing the command byte and initializing the circular buffer next. Command byte written, Global data init done. To check for lock-key. 3307114 User’ s Manual 4-24...
  • Page 49 Keyboard typematic rate set. To program memory wait states. Memory wait state programming is over. Clearing the screen and enabling parity and the NMI next. NMI and parity enabled. Performing any initialization required before passing control to the adaptor ROM at E000 next. 3307114 User’ s Manual 4-25...
  • Page 50 Please contact your technical window to get this utility if necessary. NOTE : Remark or delete any installed Memory Management Utility (such as HIMEM.SYS, EMM386.EXE, QEMM.EXE, … , etc.) in the CONFIG.SYS files before running Flash programming utility. 3307114 User’ s Manual 4-26...
  • Page 51 Chapter 5 ATX Power Setting This part of the Quick Installation Guide provides you a few useful tips to quickly get your 3307114 running without failure. As jumper configuration has been addressed in the earlier paragraphs, this section will basically focus on the ATX power setting.
  • Page 52 Figure. 4 ATX setting on 3307114 The last thing to do before your 3307114 system can be ATX powered is to connect 20-pin power cable of the ATX POWER to the backplane. By switching your ATX power on, the system goes into power standby. Clicking your 3307114 ATX power button should successfully turn the system on.
  • Page 53 We will do our best to support your products, projects and business. Address: Global American, Inc. 17 Hampshire Drive Hudson, NH 03051 Telephone: Toll Free U.S. Only (800) 833-8999 (603) 886-3900 FAX: (603) 886-4545 Website: http://www.globalamericaninc.com Support: Technical Support at Global American...
