- Page 1 Technical Service Manual ts drill 4 – 6 m Date: 7/31/2019 Machine type: ts drill 4 – 6 m Address: Kverneland Group Soest GmbH Coesterweg 42 59494 Soest Germany Receiver: Technical Service Details: Technical machine information and adjustments Serial number:...
-
Page 2: Table Of Contents
Content Machine overview Technical specifications Frame 4 m Frame 4.8 - 6 m Machine overview Seeding coulter tines New patented tine outlet Seeding depth adjustment/metering switch on and off V-shape harrow tines (Ø 10mm) + Press wheels Pneumatic Seed Distribution System Metering device Seeding rotors Radar sensor... -
Page 3: Machine Overview
Machine overview... -
Page 4: Technical Specifications
Technical specifications Height (m) without lifting height of tractor to 5.00 m working width 2,35 more then 5.00 m working width 3,10 Width (m) Machine in work position without track marker 4.00 / 4.80 / 5.00 / 5.60 / 6.00 Transport width Depth (m) Depending on the equipment, approx. - Page 5 Technical specifications Seed hopper Fill height (m) without hopper extension 2,35 with hopper extension 2,55 Hopper volume (l) without hopper extension 1350 with hopper extension 1700 Maximum hopper capacity, approx. (kg of wheat) without hopper extension 1050 with hopper extension 1275 Noise level (dBa) Fan at 1,000 rpm...
- Page 6 Technical specifications Tractor Power requirement 110 to 180 HP Tractor PTO shaft (rpm) 540/850/1000 Design 1 3/8“, 6-part Wheels Tyre pressure centre section wheels 1.4 bar. Tyre pressure side section wheels 2.4 bar. – 32 tines - 12,5cm Number of tines –...
-
Page 7: Frame 4 M
Frame 4 m 3 section frame Seed depth adjustment • Coupling • 2 Floatation tyres 11.5/80-15.3 (10 PR) • Cat. II and III (from Optima trailed frame) • Top-link with additional slotted hole • Tool-less adjustment of the seed depth •... -
Page 8: Frame 4.8 - 6 M
Frame 4.8 - 6 m 3 section frame with floating wings • Coupling • Cat. II and III • Toplink with additional slot hole • Wing support wheels 20.5x8.0-10 (6 PR) • Depth adjustment of the wing support wheels without any tools •... -
Page 9: Machine Overview
Machine overview Large safe loading Seeds platform and access steps Fed drive Metering system Track marker Right side Press section wheels Centre Covering section Seeding harrows Left side tines section Levelling Loosing/sowing Covering Pressing Clod Board [+] Tine with seed coulters Seed-covering harrow Press wheels [+]... -
Page 10: Seeding Coulter Tines
Auto reset seeding tines • Strong tine with micro vibration for precise seeding depth and low pulling force • 50kg Auto-reset breakaway force • The Kverneland leaf-spring auto reset tine allows to Reversible tine overcome even the largest obstacles (option) •... -
Page 11: New Patented Tine Outlet
New patented tine outlet A new patented seed outlet which has no screws in the seed outlet tube. This ensures perfect seed placement... -
Page 12: Seeding Depth Adjustment/Metering Switch On And Off
Seeding depth adjustment/metering switch on and off 1. Seeding depth for central wheels is adjusted by spacers. •1 2. Frames > 4.00m are equipped with additional depth control wheels on the wing sections. 3. The metering devise is switched on and off by two sensors on chassis. -
Page 13: V-Shape Harrow Tines (Ø 10Mm) + Press Wheels
V-shape harrow tines (Ø 10mm) + Press wheels Press wheels Ø 380 ( proven and tested on u-drill) • Integrated „Depth-Guidance- and Press Wheel“ – large Ø380mm for a smooth ride. • New flexible rubber design with self cleaning effect for the Press-Wheel - no scraper required. -
Page 14: Pneumatic Seed Distribution System
Pneumatic Seed Distribution System The seeds are Seed rate All kind of The metering unit The air blows distributed can be seeds can conveys the seeds the seeds equally to all adjusted be seeded to the injector trough the from 1 to from grass seeding where it is mixed... -
Page 15: Fan
• The fan is positioned at the back and integrated in the frame concept. • This makes it easier to connect the pto shaft and ensures smoother running. • Hydraulic drive 28 l/min series • Maximum return line pressure 10 bar •... -
Page 16: Metering Device
Calibration button rotor Membrane Sensor for flap • Electric driven Kverneland metering device • Seed rate from 1-400kg per ha Diffusor • Calibration flap with integrated gate – no seed dropping into the hose. • Penstock as standard. For control: amperage of motor •... -
Page 17: Seeding Rotors
Seeding rotors Example Rotor (dependent on seed quantity) Beans, Peas Grass Rape Barley, Wheat Maize... -
Page 18: Radar Sensor
Radar sensor Type: Radar Voltage: 12 V Adjustability: Switching distance: Wire: Red (+12 V), green (signal), black (ground) Calibration and Check: - Calibration : 1) Press „START“ 2) Drive exact 100 m in field (speed > 0,5 km/h) 3) Press „STOP“ ... -
Page 19: Electronics - Main Box
Electronics - Mainbox E - COM • • • for function control: • • •ECU/Terminal LED measure signal to ground - Sensor active 0V - Sensor open 12V • • • •Power Input LEDs •Motor LED • • • •Run LED, flashes if software is ok... - Page 20 Electronics - Mainbox E - BAS • for function control: measure signal to ground - Sensor active 0V • - Sensor open 12V • • • •ECU/Terminal LED • • • •Power Input LEDs •Motor LED • • • •Run LED, flashes if software is ok...
- Page 21 Electronics - Mainbox comparison Difference between E-Bas/E-Com Parts that are only on E-Com mainbox: • Cable ISO • Output 4/5 , 9-12 • 20A Fuse • DIAG • Can2 • Inputs • Because of difference don´t exchange Mainbox (E-Bas <> E-Com)!
- Page 22 Electronics - Mainbox Fuses Fuse Error • ECU power/ input power • no isobus cabel • Light • no error • Output 4 and 5 • not used • Main power ACT_PWR 1 • stand still • while driving metering device stops •...
- Page 23 Electronics - Distribution Box for Tramlines...
- Page 24 Electronics – Software update 1. Connect the cables E-com USB-CAN adapter Socket for diagnostic cable Cable to Adapter for terminal ISOBUS-diagnostic USB cable Mainbox Program: ISOMatch Top Service External cable to update the Internal cable to update mainboard („MB“), the mainboard and tractor control („TC“) and the seedunits...
- Page 25 Electronics – Software update 1. Connect the cables E-bas...
-
Page 26: Electronics - Software Update
Electronics – Software update 2. Start IsoMatch TopService Tool... - Page 27 Electronics – Software update 3. Software update Press “Select” and choose the correct Software; After selecting press “Update”...
-
Page 28: Electronics - Pin Menu
Electronics – Pin menu E-bas •3 Machine configuration •1 •Working width •Tines •Row distance •Speed filter •Hopper design •Half side switch off •2 Hopper design •4 •Working switch •Active high •Speed sensor •Active low •Metering device •Fan •Calibration button •Low level sensor •Not used... - Page 29 Electronics – Pin menu E-com •Model •Half side switch off •Checkmark just for simulation! •Working switch •Speed sensor •Fan •Metering device •Low level sensor •Calibration button •Active low •trackmarker •Active high...
-
Page 30: Hydraulics E-Com
Hydraulics E-COM... -
Page 31: Hydraulics E-Bas
Hydraulics E-BAS... -
Page 32: Overview Of Alarms E-Com
Overview of alarms E-COM General Alarms... - Page 33 Overview of alarms E-COM...
- Page 34 Overview of alarms E-COM...
- Page 35 Overview of alarms E-COM Alarms only occurring during seeding...
- Page 36 Overview of alarms E-COM...
- Page 37 Overview of alarms E-COM Calibration alarms...
- Page 38 Overview of alarms E-COM Messages...
-
Page 39: Comments - Personal Notes
Comments – Personal notes...
