V812+ OPERATING INSTRUCTIONS

General Specifications

Item
CE marking
Compatible
Specification
UL/cUL
Rated Voltage
Permissible Range of Voltage
Permissible Momentary Power Failure Within 20 ms
Power Consumption (Maximum
Rating)
Rush Current
Withstand Voltage
Insulation Resistance
Surrounding Air Temperature
Storage Surrounding Air Temperature -10°C to +60°C
Surrounding Air Humidity
Storage Surrounding Air Humidity
Altitude
Atmosphere
Vibration Resistance
Shock Resistance
Noise Resistance
Static Electricity Discharge
Resistance
*2
Pollution Degree
Grounding
Structure
Cooling System
Weight
Dimensions W × H × D
Panel Cut-out Dimensions
Material
*1 Use the unit with the wet-bulb temperature 39°C or less. Otherwise, it may cause a malfunction.
*2 This index indicates the degree to which conductive material is generated in the environment where the
equipment is used.
In pollution degree 2, only non-conductive pollution occurs but temporary conductivity may be produced due to
condensation.
*3 It is recommended to use the mounting panel whose thickness is 3.0 mm or more to keep the unit compliant with
IP65.
Model AC Power Supply
100 - 240 VAC
100 - 240 VAC ±10%
70 VA or less
100 VAC: 20 A or less (10 ms or less)
200 VAC: 40 A or less (10 ms or less)
AC external terminals to FG:
1500 VAC per minute
500 VDC, 10MΩ or above
0°C to +50°C
85% RH or less (without dew condensation, wet-bulb temperature 39°C or less
85% RH or less (without dew condensation, wet-bulb temperature 39°C or less
2000 m or lower
No corrosive gas, no excessive dust, and no conductive dust
Vibration frequency: 10 to 150 Hz, Acceleration: 9.8 m/s
Half-amplitude: 0.075 mm, 3 directions of X, Y and Z: one hour
Pulse shape: Sine half wave
Peak acceleration: 147 m/s
1500 Vp-p (pulse width 1 µs, rising time: 1 ns)
Compliant with IEC61000-4-2, Contact: 6 kV, Air: 8 kV
For use in Pollution Degree 2
Less than 100Ω, FG/SG separated
Protection structure
Form
Mounting procedure
Sheet metal thickness : 1.5 to 5 mm
Cooling naturally
Approx. 2.9 kg
326.4 × 259.6 × 69.0 mm
313.0 × 246.2
+0.5 +0.5
-0 -0
PC/ABS
EN61000-6-2, EN61000-6-4
-
UL508, UL1604
24 VDC
24 VDC ± 10%
24 VDC: Within 1 ms
30 W or less
20 A or less (2 ms or less)
DC external terminals to FG:
500 VAC per minute
2
(15 G), 3 directions of X, Y and Z: 6 times
: front panel complies with IP65
rear case complies with IP20
: in a body
: inserted in a mounting panel
*3
mm
4
DC Power Supply
2
(1.0 G),
*1
)
*1
)
