RS Automation AnyTouch V7 Plus Series Operating Instructions Manual

Make sure that the delivered unit conforms to your requirement, and also check for any missing or damaged parts.
Before using this V715+, be sure to read this OPERATING INSTRUCTIONS thoroughly to ensure proper operation.
[Accessories] V715+ OPERATING INSTRUCTIONS: 1 copy, Fixtures: 6 pcs, Clamp for USB cable: 1 pce
[Models]
15 inch display
Device type
X : TFT color LCD (XGA, 32,768 colors)
Notes on Safe Usage
In this "V715+ OPERATING INSTRUCTIONS", you will find various notes categorized under the following two levels with
the signal words "Danger" and "Caution."
Indicates an imminently hazardous situation which, if not avoided, will result in death or serious
injury.
Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate
injury and could cause property damage.
Even some items indicated
Never use the output function of AnyTouch for operations that may threaten human life or to damage the system,
such as switches to be used in case of emergency. Please design the system so that it can cope with malfunction
of a touch switch. A malfunction of the touch switch will result in machine accident or damage.
Turn off the power supply when you set up the unit, connect cables or perform maintenance and inspection.
Otherwise, electrical shock or damage may occur.
Never touch any terminals while the power is on. Otherwise, electric shock may occur.
You must put a cover on the terminals on the unit when you turn the power on and operate the unit. Without the
terminal cover in place, an electric shock may occur.
The liquid crystal in the LCD panel is a hazardous substance. If the LCD panel is damaged, never swallow the
leaked liquid crystal. If the liquid crystal spills on your skin or clothing, use soap and wash off thoroughly.
Never disassemble, recharge, deform by pressure, short-circuit, nor reverse the polarity of the battery, and never
dispose of the battery in fire. Failure to follow these conditions will lead to explosion or ignition.
Never use a battery that is deformed, leaks, or shows any other signs of abnormality. Failure to follow these
conditions will lead to explosion or ignition.
A power lamp blinks when a screen becomes dark, owing to the life or a malfunction of the backlight.
At this time, switches on a screen are effective. Never touch the screen when the screen becomes dark (hard to
see) and a power lamp blinks. A malfunction will result in machine accident or damage.
Check the appearance of the unit when it is unpacked. Do not use the unit if any damage or deformation is found.
Failure to do so may lead to fire, damage or malfunction.
For use in a facility or for a system related to nuclear energy, aerospace, medical, traffic equipment, or mobile
installations, please consult your local distributor.
Operate (or store) AnyTouch under the conditions indicated in this manual and related manuals. Failure to do so
could cause fire, malfunction, physical damage or deterioration.
Understand the following environmental limits for use and storage of AnyTouch. Otherwise, fire or damage to the
unit may occur.
- Avoid locations where there is a possibility that water, corrosive gas, flammable gas, solvents, grinding fluids or
cutting oil can come into contact with the unit.
- Avoid high temperature, high humidity, and outside weather conditions, such as wind, rain or direct sunlight.
- Avoid locations where excessive dust, salt, and metallic particles are present.
- Avoid installing the unit in a location where vibration or physical shock may be transmitted.
V7 Plus Series
V715+ OPERATING INSTRUCTIONS
Power supply type
may also result in a serious accident.
(None) : 100-240V AC
D : 24V DC (Comply with CE/UL/cUL)
1
