  • Page 1 EcoFlow Solar Tracker User Manual...
  • Page 2 Users take full responsibility for all usage and operations. Familiarize yourself with the related regulations in your area. You are solely responsible for being aware of all relevant regulations and using EcoFlow products in a way that is compliant.

  • Page 3: Table Of Contents

    --1.2.1 Solar Tracker Instrallation --1.2.2 Using foldable solar panels --1.2.3 Using rigid solar panels 1.3 Disassembly 1.4 Transportation 1.5 Using The Solar Tracker --1.5.1 Positioning the Solar Tracker --1.5.2 Turning on and off --1.5.3 Emergency stop button --1.5.4 Operation Modes 2.

  • Page 4: Assembly Instructions

    1. Assembly Instructions 1.1 What's in the box CONTROL MODULE LIGHT SENSOR MOTORIZED LEVER ARM L-FEMALE L-MALE B-LEFT B-RIGHT A1-MIDDLE A1-LEFT A1-RIGHT A3-LEFT A3-RIGHT SOLAR CHARGING CABLE FOR SOLAR SOLAR CHARGING CABLE FOR PANEL (0.92ft) ECOFLOW UNITS (9.84ft)

  • Page 5: Installation

    1.2 Installation 1.2.1 Solar Tracker Instrallation L-FEMALE L-MALE L-MALE L-FEMALE...
  • Page 6 CONTROL MODULE CONTROL MODULE...
  • Page 7 MOTORIZED LEVER ARM MOTORIZED LEVER ARM...
  • Page 8 B-LEFT B-RIGHT B-LEFT B-RIGHT...

  • Page 9: Using Foldable Solar Panels

    1.2.2 Using foldable solar panels *If you plan to use foldable solar panels, please continue with step 5 to 7 to finish installation. A1-LEFT A1-RIGHT A3-LEFT A3-RIGHT A1-LEFT A1-RIGHT A3-LEFT A3-RIGHT...
  • Page 10 Attach the foldable solar panel. 0.92ft Solar Charging Port 9.84ft MC4 Connectors NOTE Long press the power button. The indicator light will turn on. The solar tracker will begin rotating according to the lighting conditions.

  • Page 11: Using Rigid Solar Panels

    1.2.3 Using rigid solar panels *If you plan to use the rigid solar panels, please continue with step 8 to 11 to detach the folding bars and finish installation.
  • Page 13 0.92ft Solar Charging Port 9.84ft MC4 Connectors NOTE Long press the power button; The indicator light will turn on. The solar tracker will begin rotating according to the lighting conditions.

  • Page 14: Disassembly

    1.3 Disassembly A1-LEFT A1-RIGHT A3-LEFT A3-RIGHT NOTE Please fold A3-LEFT and A3-RIGHT first, and then fold A1-LEFT and A1-RIGHT. Detach the control module from the base stand. Fold the legs of the base.

  • Page 15: Transportation

    1.4 Transportation...

  • Page 16: Using The Solar Tracker

    Positioning the Solar Tracker The Solar Tracker can rotate 345° therefore it has a 15° blind spot. That means if you're in the northern hemisphere, you should position the front of the solar tracker to the east with a slight northern tilt.

  • Page 17: Turning On And Off

    The stand will rotate back to its starting position, and then shut down automatically. NOTE Please note that the Solar Tracker won't be powered off if the solar panel is still connected and getting solar power. 1.5.3 Emergency stop button The emergency stop button is the red button located on the top of the control module.

  • Page 18: Specifications

    -10°C~40°C (optimal: 25°C) *The built-in battery can be recharged from solar power. If the Solar Tracker is not in use for a long time, you can recharge the unit from the USB-C port (5 to 20V, 1A) port at the back of the Control Module.

  • Page 19: Light Indicators

    Working: Slow flashing (flash for 1s every 0.5s) Sleep: Always on NOTE Please note that the Solar Tracker won't be powered off if the solar panel is still connected and getting solar power. The light indicator will keep short flashing (flash for 1s every 0.1s).
