Service Manual
Interactive Flat Panel Series
55"
EAN: 8592580113215 / 8592580114038

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Interactive Flat Panel Series and is the answer not in the manual?

Questions and answers

Related Manuals for TRIUMPH BOARD Interactive Flat Panel Series

Summary of Contents for TRIUMPH BOARD Interactive Flat Panel Series

  • Page 1 Service Manual Interactive Flat Panel Series 55″ EAN: 8592580113215 / 8592580114038...

  • Page 2: Table Of Contents

    6.1 Abnormal display ..........................40 6.2 No image ............................... 41 © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product. Reproduction or distribution of any content of this document without permission is strictly forbidden.

  • Page 3: Safety Precautions

    ➢ Power off the IFP prior to cleaning, and DO NOT use any corrosive liquid to wipe the machine surface; (TRIUMPH BOARD CLEANING PADS are recommended) ➢ When using the plug, pay attention not to forcedly push the plug into the port. When connecting the machine, ensure that the port is free from chips, that the plug matches the port and that the direction of the plug corresponds to that of the port;...

  • Page 4: Product Bom

    9 EAN: 8592580114816 soldering) board © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product. Reproduction or distribution of any content of this document without permission is strictly forbidden.
  • Page 5 Grey plastic torsion (7 keys) plastic torsion © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product. Reproduction or distribution of any content of this document without permission is strictly forbidden.
  • Page 6 55E89K-C2 White aluminum face frame assembly (TRIUMPH BOARD Metal face 1 71Y1-55E89K-A3180001 logo) frame assembly 2 71Y2-55E89K-A6140001 55E89K-C2 rear shell of gray sheet metal (TRIUMPH BOARD) Metal rear shell Screen assembly 55” TFT KTC K550WD9-LL350A2 LED backlight screen (RGB) 1 7422-550LGK-3I5A9351 (12V+51pin+UHD+10bit/60Hz) (structure:9*18, electrical: 6*27/500mA) |...

  • Page 7: Product Specification

    Input power PM12V/5V; controllable mode © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product. Reproduction or distribution of any content of this document without permission is strictly forbidden.
  • Page 8 LED indicator The LED light is lit in green during normal operation, and in red during standby OSD language English (other languages can be added as required) © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product.

  • Page 9: Block Diagram Of Ifp

    ➢ PC module: Built-in PC module; © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product. Reproduction or distribution of any content of this document without permission is strictly forbidden.

  • Page 10: Ifp Internal Wiring Diagram

    OPS adapter board: OPS port to HDMI port, USB port and power port. 3.3 IFP internal wiring Diagram © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product.

  • Page 11: K-Pl-Fh1 Power Board（55")

    3,4, 12,13 12V DC output © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product. Reproduction or distribution of any content of this document without permission is strictly forbidden.
  • Page 12 LED+ power supply © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product. Reproduction or distribution of any content of this document without permission is strictly forbidden.

  • Page 13: Mainboard Parameters

    720×480 16:09 60Hz © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product. Reproduction or distribution of any content of this document without permission is strictly forbidden.
  • Page 14 5V normal power supply Ground © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product. Reproduction or distribution of any content of this document without permission is strictly forbidden.
  • Page 15 RXOC+ GROUND RXO2- © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product. Reproduction or distribution of any content of this document without permission is strictly forbidden.
  • Page 16 J455 (51pin/2.0mm) (60HZ): V-by-One connector ➢ © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product. Reproduction or distribution of any content of this document without permission is strictly forbidden.
  • Page 17 Name Description Ground © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product. Reproduction or distribution of any content of this document without permission is strictly forbidden.
  • Page 18 Name Description Ground © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product. Reproduction or distribution of any content of this document without permission is strictly forbidden.

  • Page 19: Ops Adapter Board

    USB2.0 DC 12V © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product. Reproduction or distribution of any content of this document without permission is strictly forbidden.

  • Page 20: Disassembly Steps

    Take down Φ3×6mm Plating black zinc mechanical screw with meson head (Φ7mm) * 8PCS, release the speaker bracket and rear shell，and then pull out the cable of speaker; © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product.
  • Page 21 3） Take down Φ3×6mm Plating black zinc mechanical screw with meson head (Φ7mm) * 4PCS, release the rear shell and the power strip shield; © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product.
  • Page 22 6）Take down M3*11mm Cross recessed countersunk head screw black plated zinc alloy tooth machine * 6 PCS, release the rear shell and the face frame; © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product.
  • Page 23 7）Take down M6*18 B headband cushion (the thickness of the cushion 1.4) plating black zinc mechanical screw*4 PCS, release the handle and the face frame; © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product.
  • Page 24 ➢ Step 2: Remove boards © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product. Reproduction or distribution of any content of this document without permission is strictly forbidden.
  • Page 25 Mainboard: Mainboard cable © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product. Reproduction or distribution of any content of this document without permission is strictly forbidden.
  • Page 26 ➢ Power relay board © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product. Reproduction or distribution of any content of this document without permission is strictly forbidden.
  • Page 27 5) OPS adapter board cable 6) Rear adapter board © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product. Reproduction or distribution of any content of this document without permission is strictly forbidden.
  • Page 28 7) RS232 port adapter board 8) IR board © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product. Reproduction or distribution of any content of this document without permission is strictly forbidden.
  • Page 29 11) Light Sensor board 12) Front adapter board © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product. Reproduction or distribution of any content of this document without permission is strictly forbidden.
  • Page 30 Step 1: Take down M3*11mm Cross recessed countersunk head screw black plated zinc alloy tooth machine *6PCS, release the rear shell and the face frame; © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product.
  • Page 31 Step 1: Take down M4*25mm Cross hand screwing nickel mechanical screw*4PCS, release the rear shell and the Corner decoration cover； © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product.
  • Page 32 * for additional instructions for touch frame replacement please contact support@triumphboard.com © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product.

  • Page 33: Software Debugging Instructions

    Step 3: Press the “Source” key on the remote control; when Source options appear on the screen, press the numerical keys “2”, “5”, “8”, “0” to enter the Factory Menu; © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product.
  • Page 34 Step 4: In the Factory Menu, select “Other Options” -- “Upgrade Main”; click OK and select “Confirm”; then click OK again to start upgrade. © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product.
  • Page 35 Notes: Do not power off during upgrade. Do not un-plug USB disk during upgrade. Applicable only for EAN 8592580112638 © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product.

  • Page 36: Upgrade Via Side Buttons

    “o” to “-” to power on the product; © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product.
  • Page 37 Notes: Do not power off during upgrade. Do not un-plug USB disk during upgrade. Applicable only for EAN 8592580112638 © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product.
  • Page 38 86" IFP EAN: 8592580114069 1. Open Apps menu © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product. Reproduction or distribution of any content of this document without permission is strictly forbidden.
  • Page 39 Do not power off during upgrade. Do not un plug Wi-Fi Dongle or LAN cable from IFP during upgrade © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product.

  • Page 40: Troubleshooting For Ifp Uhd Series

    Replace display screen © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product. Reproduction or distribution of any content of this document without permission is strictly forbidden.

  • Page 41: No Image

    © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product. Reproduction or distribution of any content of this document without permission is strictly forbidden.
  • Page 42 Replace TV main board Replace touch frame © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product. Reproduction or distribution of any content of this document without permission is strictly forbidden.
  • Page 43 Replace TV main board © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product. Reproduction or distribution of any content of this document without permission is strictly forbidden.
  • Page 44 Replace TV main board Replace Speakers © Copyright 2018 TRIUMPH BOARD This document contains confidential information which can be used by the recipient only for servicing the above product. Reproduction or distribution of any content of this document without permission is strictly forbidden.
