TRIUMPH BOARD UHD Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
INTERACTIVE FLAT
PANEL UHD Series
65"/ 75"/ 86"
2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UHD Series and is the answer not in the manual?

Questions and answers

Related Manuals for TRIUMPH BOARD UHD Series

Summary of Contents for TRIUMPH BOARD UHD Series

  • Page 1 User Manual INTERACTIVE FLAT PANEL UHD Series 65″/ 75″/ 86″ 2019...

  • Page 2: Table Of Contents

    Contents …………………………….……………………...………3 1. Product Description ………………………………………………………4 2. Technical Specifications ………………………………………………………...………….7 3. Safety Warning Placement…………………………………………………………………………………...…7 Power Supply……………………………………………….…………………………………7 Screen………………………………………………………………………………………….7 Range of Visibility……………………………………………………………………...…….7 Temperature………………………………………………………………………………...…7 Humidity……………………………………………………………………………………….7 Ventilation………………………………………………………………………………….….8 Headphones…………………………………………………………………………....8 Standby……………………………………………………………………………………...…8 Battery………………………………………………………………………………………..8 Caution…………………………………………………………………………………….….8 Notes on Cleaning……………………………………………………………………….…...8 Notes on Maintenance……………………………………………………………………..8 Power Switch Status Indicator……………………………………………………….……8 ……………………………………………….…….9 4. Preparing for Installation Unpacking …………………………………………………………………………….………9 Accessories……………………………………………………………………………….

  • Page 3: Product Description

    20 users being able to write and draw using fingers or a stylus. TRIUMPH BOARD OPS PC for INTERACTIVE FLAT PANEL (optional for IFP UHD Series) TRIUMPH BOARD OPS PC for IFP is a powerful, fully integrated personal computer for the TRIUMPH BOARD Interactive Flat Panel Series with the Android system.

  • Page 4: Technical Specifications

    2. Technical Specifications TRIUMPH BOARD 65″ INTERACTIVE FLAT PANEL EAN: 8592580115363 Screen Type: Open Cell DLED Backlight 3840 × 2160 Resolution: Brightness: 450 cd/m2 Contrast: 1200:1 (4000:1 Dynamic) Response time: 6 ms Refresh Frequency: 60 Hz 1428,48 (H) x 803,52 (V) (56.22″ H x 31.62″ V)
  • Page 5 Inputs and Outputs HDMI IN: HDMI OUT: DisplayPort: VGA: PC AUDIO: Y Pb Pr: LAN: AV IN: AV OUT: EARPHONE: SPDIF: USB 2.0: PC/Android USB: TOUCH USB: RS232 IN: Sound System Power Amplification: 2 x 15 W (2.0) Power 100 – 240 V AC 50/60 Hz Power Requirements: Overall Power Consumption: <...
  • Page 6 Microsoft Windows 10 Professional (OEM) 64-bit MultiLang Net / Gross Weight: 0,9 / 1 kg (2 / 2.2 lb.) TRIUMPH BOARD OPS PC PRO for IFP (optional for IFP UHD Series) EAN: 8592580115578 Processor: Intel i7-8665U 4M up to 4.8GHz ®...

  • Page 7: Safety Warning

    3. Safety Warning Before using the device, please read the instructions carefully. Placement • Do not place the device on surfaces that are unstable, easy to tilt or which can fall. • Do not place the device in places with direct sunlight, or near sources of heat, such as electric heaters or bright light sources.

  • Page 8: Ventilation

    Ventilation • ’ Please place the device in ventilated places and ensure the device s good heat dissipation. • Please ensure ventilation spaces 10 cm (4 inches) on the sides and back, and 30 cm (12 inch) on the top of the device. Headphones •...

  • Page 9: Preparing For Installation

    4. Preparing for Installation Unpacking Accessories Quick Start Guide (on the 8GB USB), User Manual, (on the 8GB USB), styluses, cleaning pads, remote control, Wi-Fi USB adapter, power cables (UK, US, EU), touch USB cable, USB Flash Drive and VC Camera Bracket. Quick Start Guide 2x Stylus Cleaning Pads...

  • Page 10: Installation Of Wall Mount

    Installation of Wall Mount Precautions • For installation of the wall-mount bracket, at least two professional workers are needed; you should not attempt to install it alone, otherwise injury may result. • During installation, assistance from professional workers is needed to designate the installation, and measurements should be taken to make sure the wall can bear a certain amount of external force.

  • Page 11: Control Panel

    Control Panel Item Description of Function 1. Indicator Light Indicates if the IFP is turned ON or OFF (green ON, red Remote control receiver OFF) Light sensing receiver Receiver for remote control signal Receiver for light sensor 2. Power Turns Interactive Flat Panel ON/OFF, Standby mode by holding the button for 1s 3.

  • Page 12: Remote Control

    5. Remote Control Precautions: • Aim the remote control at the remote receiver when using the remote control. Any object placed between the remote control and the remote receiver may interfere with operation. • Protect the remote control from vibration. Do not expose the remote control to direct sunlight as heat may deform it.

  • Page 13: Instructions For Use

    Remote Control Use Instructions Install Batteries 1) Open back cover of battery compartment on the back of remote control. 2) Install AAA type batteries according to the corresponding electrode, make sure the battery positive and negative poles are correctly placed (“+” to “+”, “-“ to “-“), please do not mix old and new batteries. 3) After batteries are installed, close the back cover of battery compartment, and snap the clip fastener shut against the bottom of the remote.
  • Page 14 Ports Description of Function Connect USB devices such as portable hard drives, USB drives, USB keyboard and mouse, etc. Port serves as both a USB Android media port and a USB OPS port, it is automatically switchable with the signal source. External computer touch signal input.

  • Page 15: Connection And Set Up

    7. Connection and Set Up CAUTION For your own safety and the safety of the device, please do not connect any power cord before the external device has been prepared. External Computer and Touch Connection Connecting of VGA cable and USB touch cable: 1.

  • Page 16: Hdmi Connection

    Connecting of HDMI cable and USB touch cable: HDMI /HDMI1 / HDMI2 1. Use HDMI line to connect to HDMI output port of external computer 2. Use a USB cable to connect to the external computer USB port. 3. After connection is completed, plug in power cord, and switch POWER to ON. 4.

  • Page 17: Rs232 Connection

    RS232 Serial port connection Serial port line After using the serial port line to connect central control equipment and the device, certain functions of the device can be controlled via the central control device, such as: device ON/OFF, and adjustment of sound volume, etc.

  • Page 18: Android System

    8. Android System Call up Control menu Place two fingers on the screen (about 20-50mm apart) and keep in position more than two seconds under any source to call up two touch system tool menus. Main control menu Control submenu Home (Return to Android Home Page) Screenshot System Settings...

  • Page 19: Basic Operations

    9. Basic Operations Start-up / shutdown Use 100-240V AC as the power supply. The Power button on the panel and the remote control can be used to switch between power ON and OFF state. Auto standby shutdown In the Android main interface, whether there is signal input or not, the device will not auto shutdown. In the non-Android main interface, if there is no signal input within 15 min, the device will automatically set off.

  • Page 20: Language Selection

    Language selection System Settings > Language & Input Method > Language and select the desired language. Select System Time System Settings > Date & Time > Set Date & Time. The system will automatically synchronize the time from the network; in case the device is not connected to network, date and time has to be set manually. Screenshot Press the “Screenshot”...

  • Page 21: Wireless Hotspot

    Wireless Hotspot Wireless hotspot works only when following conditions are met: • USB 3.0 Wi-Fi USB adapter is connected to IFP. • IFP is connected via wired LAN network. Select System Settings > Hotspot Turn on hotspot feature (activation may take a few seconds) Enter the hotspot name in the textbox.

  • Page 22: Troubleshooting

    11. Troubleshooting Board fails to work normally 1. Check whether there are other objects between remote control and television remote control receiving window, blocking signal transmission and thus, leading to failure of remote control. Remote control failure 2. Check whether the battery terminal in the remote control is correctly connected.
  • Page 23 Video Malfunctions No picture and no sound 1. Check whether the device is in active mode. 2. Check whether the signal wire is plugged in securely, using the corres- ponding INPUT. 3. If in internal computer mode, check whether internal computer is running. With horizontal or vertical 1.

  • Page 24: Maintenance

    12. Maintenance Proper maintenance can prevent many early malfunctions. Regular, careful cleaning can keep the device like brand new. Please unplug power plug before cleaning and maintenance, to prevent electric shock. Clean screen For cleaning of the IFP, we recommend using the TRIUMPH Cleaning Pad (EAN:8592580083365).

  • Page 25: Repair Service And Contacts

    Technical support Please fill in your RMA or Product question on our website https://www.triumphboard.com/support/technical-support/ If you have any questions, please email us at contact@triumphboard.com TRIUMPH BOARD a.s. Neklanova 122/15 128 00 Prague 2 Czech Republic Phone: +420 224 910 221 E-mail: info@triumphboard.com www.triumphboard.com...
