- Page 1 minipool Phantom PR1 - SP1 Installation manual...
- Page 2 The installation of this minipool is simple and immediate, however we advise you to read this manual carefully before installing it. The Treesse team is always available for any information or request for assistance that may be required during installation.
-
Page 3: Table Of Contents
Contents Safety instructions __________________________________________4 EXPLANATION OF PICTOGRAMS _________________________________________________________________ 4 Preliminary operations ______________________________________5 PREPARATIONS AND CHOICE OF POSITION _________________________________________ 5 CHECKING MINIPOOL INTEGRITY __________________________________________________ 5 OUTDOOR INSTALLATION __________________________________________________________________ 5 INDOOR INSTALLATION ____________________________________________________________________ 5 Transport and position ______________________________________6 MOVING _________________________________________________________________________ 6 POSITIONING _____________________________________________________________________ 7 TEMPORARY POSITIONING _________________________________________________________________ 7 POSITIONING IN THE PLANNED LOCATION __________________________________________________ 7 Installation _________________________________________________8... -
Page 4: Safety Instructions
Unauthorised actions, tampering or Treesse invites you to protect the environ- modifications that do not follow the ment by disposing of the material in special information provided in this manual can cause separate collection bins. -
Page 5: Preliminary Operations
Preliminary operations Phantom minipool PREPARATIONS AND CHOICE More information OF POSITION OUTDOOR INSTALLATION The pre-installation sheet supplied at the time of purchase provides all the information neces- Preparations: in cold areas, to avoid possible damage sary for a correct preparation of the installation due to freezing, it is recommended to provide valves environments. -
Page 6: Transport And Position
Transport and position Phantom minipool MOVING To move the minipool to the place of installation a suit- able lifting device (e.g., pallet jack) is required. As an alternative, provide for the availability of eight people. If the installation is indoor, before moving the minipool make sure that it can easily pass through the doors and hallways to reach the desired place of installation. -
Page 7: Positioning
Transport and position Phantom minipool POSITIONING TEMPORARY POSITIONING The installation of the minipool should be done immediately upon receipt. In any case, once unpacked, if it is necessary to temporarily place it on a surface awaiting the installation, it will be necessary to place level concrete slabs having a minimum thickness of 5 cm under the entire bottom of the minipool. -
Page 8: Installation
Installation Phantom minipool DESCRIPTION OF MAIN COMPONENTS Control Panel Compensation tank Phantom PR1/SP1 Paper filter Electric pump 1 Electric pump 2 (optional in SP1) Electronic control units Blower (optional in PR1 not available in SP1) Heater Ozone Compensation tank inspection... -
Page 9: Connections Required
Installation Phantom minipool CONNECTIONS REQUIRED To be used, the minipool requires only two connections: Room for the electrical con- plumbing connections nections (incoming and outgoing water) electrical connection (power supply) electrical and plumbing connection to an exchanger (optional - if present) - see following page. - Page 10 Installation Phantom minipool CONNECTION TO AN OPTIONAL EXTERNAL EXCHANGER (NOT SUPPLIED) Room for the Inlet connection: electrical con- 1”1/4 female nections Outlet connection: 1”1/4 female The exchanger means the device that heats water (in this manual , it is represented by a boiler connected to the solar Exchanger (not...
-
Page 11: Plumbing Connections
Installation Phantom minipool PLUMBING CONNECTIONS More information WATER HARDNESS All water connection operations must be per- formed after making sure that the minipool's Water hardness (TH) is determined by the total content water supply valve is CLOSED. of calcium and magnesium present in the water, coming The connection must be made by an experi- from their soluble salts. - Page 12 Installation Phantom minipool EXAMPLE OF PRE-INSTALLATION PLUMBING FOR A MINIPOOL Connection to the minipool using the 1/2 inch female hose pro- Connect the drain of the floor minipool. The vided. plumber is responsible for the choice and type If the minipool is installed outdoors provide an adequate thermal of materials to be used and the verification of insulation of the pipes.
-
Page 13: Electrical Connections
ELECTRICAL CONNECTIONS The Treesse minipools are built in compliance with European laws (EN 60 335-2-60) and are tested during production to ensure the safety of the installer and user. The connection must be made by an experienced, qualified electrician. -
Page 14: Safety Zone
Installation Phantom minipool SAFETY ZONE Local regulations prohibit any electrical installation (plug sockets, switches, lamps, etc.) in the area surround- ing the minipool for a distance of at least 60 cm and a height of 230 cm. TESTING AFTER INSTALLATION √... -
Page 15: First Run Pr1
Once the pool is powered, the display will show the word all operation. "treesse" and after a few seconds the display will show In this case, you will have to disconnect the power and the current ambient temperature, and the various symbols restore it after about 30 seconds using the product's main on the keypad will be illuminated with white light. -
Page 16: First Run
Phantom PR1 First run minipool FIRST RUN Main page With the bathtub full, recirculation active and ozone ac- tive, start in sequence all the functions of the bathtub in the presence of the owner to verify proper operation: BLOWER The minipool can be equipped with a blower motor that drives the nozzles on the bottom;... - Page 17 Phantom PR1 First run minipool The function can always be activated, even if the water Main page level is low. “OK” If pressed for more than three seconds, you access a submenu page where other system functions are available (empty, keypad lock, SILENCE mode).
-
Page 18: Partial Minipool Empty Test
Phantom PR1 First run minipool More precisely: How to set the SILENCE function: A Press the "OK" key 6 for at least three seconds. • If an automatic function is active when the SILENCE function is engaged, it is deactivated immediately B this provides access to a submenu page. -
Page 19: Alarms Pr1
Phantom PR1 Alarms minipool PHANTOM PR1 If any alarms appear during initial startup, read the instructions provided in the following table. If the solution is not possible, immediately contact the Manufacturer to request technical support. In the meantime, do not try to repair or use the minipool but rather disconnect it from the electricity and water supplies. - Page 20 Phantom PR1 Alarms minipool ALARMS Screen DESCRIPTION OF THE PROBLEM NOTIFICATIONS displayed POSSIBLE SOLUTIONS Problem description: the notification is activated if the water level in- side the compensation tank is below the minimum for more than three seconds. The display will show the message "LL" alternating with the...
- Page 21 Notes Notes Phantom PR1 minipool...
-
Page 22: First Run Sp1
Phantom SP1 First run minipool PHANTOM SP1 MINIPOOL FILLING Filling is carried out by following the figures on the side (follow the instructions for your keypad). Filling takes place from the bottom of the bathtub, and once it has finished the tank is filled. After reaching the correct level, the system automatically stops the filling and makes available the functions of whirlpool, recirculation, ozone and heater. -
Page 23: First Run
Phantom SP1 First run First run minipool FIRST RUN chromatherapy activation key WHITE: chromatherapy NOT active BLUE: fixed colour FLASHING: colours in sequence bathtub fill/empty key WHITE: NOT active BLUE: filling in progress FLASHING: emptying in progress whirlpool activation (brief press) WHITE: NOT active BLUE: whirlpool in progress key to start/stop... - Page 24 Phantom SP1 First run minipool CHROMATHERAPY Chromatherapy is started by pressing the “Light” key Activates a sequence of 16 colours that vary in an automatic sequence.* During the sequence, pressing the "Light" key again stops on the current colour (e.g., Red): the sequence is interrupted and remains fixed on the chosen colour.
-
Page 25: Partial Minipool Empty Test
Phantom SP1 First run minipool PARTIAL MINIPOOL EMPTY TEST hidden key To avoid accidental emptying of the bathtub, a combination of two keys is required to perform this operation: pressing the hidden key for three seconds (located below the display, even if it is not visible it is still active), then press the emptying in progress is indicated by the flashing blue key The emptying of the minipool can be activated at any time. -
Page 26: Alarms Sp1
Phantom SP1 Alarms minipool PHANTOM SP1 If any alarms appear during initial startup, read the instructions provided in the following table. If the solution is not possible, immediately contact the Manufacturer to request technical support. In the meantime, do not try to repair or use the minipool but rather disconnect it from the electricity and water supplies. - Page 27 Phantom SP1 Alarms minipool ALARMS Screen DESCRIPTION OF THE PROBLEM NOTIFICATIONS displayed POSSIBLE SOLUTIONS Problem description: in case of no communication with the chromatherapy controller, the system disables the function and the display shows the "Co" message alternating with the temperature. Water control unit alarm The other functions remain available.
-
Page 28: Troubleshooting
Phantom SP1 Troubleshooting minipool PROBLEM POSSIBLE CAUSE SOLUTION Some component is probably not Check the tightness or replace the Water leaks fully tightened or the seals are worn. seals. Most likely the pH of the water supply U s e a n t i - a l g a e p ro d u c t s a n d is incorrect and so algae grows. -
Page 29: Decorative Panels
Decorative panels Phantom minipool Mount the wood or laminate resin panels as shown in the figures below. -
Page 30: Covering
Under these conditions or when not used, advise the owner to use a fixed or mobile cover to protect the min- ipool (we recommend the optional Treesse covers). In addition to preserving the surfaces, the cover will keep the water hot and protected against falling leaves and other outdoor debris. - Page 31 Notes Notes Phantom minipool...
- Page 32 www.gruppotreesse.it GRUPPO TRE S s.p.a. 01036 Nepi (VT) - Italy S.S. Cassia km. 36.400 Settevene industrial area tel. (+39) 0761 527242 fax (+39) 0761 527223 info@gruppotres.it...
