- Page 1 Eyeball Network Camera Quick Start Guide ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD. V1.0.3...
-
Page 2: Foreword
Quick Start Guide Foreword General This manual introduces the functions, configuration, general operation, and system maintenance of network camera. Safety Instructions The following categorized signal words with defined meaning might appear in the manual. Signal Words Meaning Indicates a medium or low potential hazard which, if not avoided, could result in slight or moderate injury. - Page 3 Quick Start Guide the electronic version and the paper version. ● All the designs and software are subject to change without prior written notice. Product updates might result in some differences appearing between the actual product and the manual. Please contact customer service for the latest program and supplementary documentation.
-
Page 4: Important Safeguards And Warnings
Quick Start Guide Important Safeguards and Warnings Electrical Safety ● All installation and operation shall conform to your local electrical safety codes. ● The power supply must conform to the requirements of ES1 in IEC 62368-1 standard and be no higher than PS2. - Page 5 Quick Start Guide mild detergent. To avoid possible damage on device body coating which could cause performance decrease, do not use volatile solvent such as alcohol, benzene, diluent to clean the device body, nor can strong, abrasive detergent be used. ●...
-
Page 6: Table Of Contents
Quick Start Guide Table of Contents Foreword ........................................I Important Safeguards and Warnings ............................III 1 Introduction ......................................1 1.1 Cable ........................................ 1 1.2 Connecting Alarm Input/Output ............................2 2 Network Configuration ..................................4 2.1 Initializing Device ..................................4 2.2 Changing Device IP Address ..............................6 2.3 Logging in to Web Page ................................. -
Page 7: Introduction
Quick Start Guide 1 Introduction 1.1 Cable Waterproof all the cable joints with insulating tape and waterproof tape to avoid short circuit and water damage. For the detailed operation, see FAQ manual. Figure 1-1 Structure components Table 1-1 Structure components Port name Description Speaker... -
Page 8: Connecting Alarm Input/Output
Quick Start Guide Port Port Name Description When connecting to alarm device, only the ALARM_OUT_GND ALARM_OUT port and ALARM_OUT_GND port with the same number can be used together. ALARM_IN Receives the switch signal of external alarm source. ALARM_IN_GND Connect different alarm input devices to the same ALARM_IN_GND port. - Page 9 Quick Start Guide Figure 1-2 Alarm input Step 2 Connect alarm output device to the alarm output end of the I/O port. The alarm output is open-drain output, which works in the following modes. ● Mode A: Level application. Alarm outputs high and low level, and the alarm outlet is OD, which requires external pull-up resistance (10K Ohm typical) to work.
-
Page 10: Network Configuration
Quick Start Guide 2 Network Configuration Device initialization and IP setting can be finished with the ConfigTool or on web page. For more information, see web operation manual. ● Device initialization is available on select models, and it is required at first-time use and after device is being reset. - Page 11 Quick Start Guide ● Enter username and the password when you want to change IP, configure the system, update the device, restart the device, and more. Step 5 Click OK. Step 6 Select one or several devices in uninitialized status, and then click Initialize. Step 7 Select the devices to be initialized, and then click Initialize.
-
Page 12: Changing Device Ip Address
Quick Start Guide Figure 2-3 Device initialization Step 9 Select Easy4ip or select Auto-check for updates as needed. If neither, leave them unselected. Step 10 Click OK to initialize the device. Click the success icon ( ) or the failure icon ( ) for the details. -
Page 13: Logging In To Web Page
Quick Start Guide Figure 2-4 Modify IP address Select Static mode, and then enter start IP, subnet mask, and gateway. Step 3 ● IP addresses of multiple devices will be set to the same if you select the Same IP check box. -
Page 14: Installation
Quick Start Guide 3 Installation 3.1 Packing List ● The tool required for the installation such as electric drill is not provided in the package. ● The operation manual and related tool information are contained in the disk or the QR code. Figure 3-1 Packing list 3.2 Dimensions Figure 3-2 Dimensions (mm [inch]) -
Page 15: Installing Camera
Quick Start Guide 3.3 Installing Camera 3.3.1 Installation Method Figure 3-3 Installation method 3.3.2 Installing SD Card (Optional) ● SD card slot is available on select models. ● Disconnect the power before installing or removing the SD card. ● Press the reset button for 10 seconds to reset the device. -
Page 16: Attaching Camera
Quick Start Guide Figure 3-4 Install SD card 3.3.3 Attaching Camera Make sure that the mounting surface is strong enough to hold at least three times the weight of the device and bracket. - Page 17 Quick Start Guide Figure 3-5 Cable going through the side cable tray Figure 3-6 Cable going through the mounting surface...
-
Page 18: Installing Waterproof Connector (Optional)
Quick Start Guide 3.3.4 Installing Waterproof Connector (Optional) This part is needed only when there is waterproof connector in the package and the device is used outdoors. Figure 3-7 Install waterproof connector 3.3.5 Adjusting Lens Angle Figure 3-8 Adjust lens angle... - Page 19 Quick Start Guide...
