- Page 1 Eyeball Network Camera Quick Start Guide ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD. V1.0.2...
-
Page 2: Foreword
Quick Start Guide Foreword General This manual introduces the functions and operations of the camera. Safety Instructions The following categorized signal words with defined meaning might appear in the manual. Signal Words Meaning Indicates a medium or low potential hazard which, if not avoided, could result in slight or moderate injury. - Page 3 Quick Start Guide All trademarks, registered trademarks and the company names in the manual are the properties of their respective owners. Please visit our website, contact the supplier or customer service if there is any problem occurred when using the device. If there is any uncertainty or controversy, please refer to our final explanation.
-
Page 4: Important Safeguards And Warnings
Quick Start Guide Important Safeguards and Warnings Electrical Safety All installation and operation shall conform to your local electrical safety codes. The power source shall conform to the Safety Extra Low Voltage (SELV) standard, and supply power with rated voltage which conforms to Limited Power Source requirement according to IEC60950-1. - Page 5 Quick Start Guide It is recommended to use the device together with lightning arrester to improve lightning protection effect. It is recommended to ground the device to enhance reliability. Do not touch the image sensor (CMOS) directly. Dust and dirt could be removed with air blower, ...
-
Page 6: Table Of Contents
Quick Start Guide Table of Contents Foreword ................................I Important Safeguards and Warnings ......................III 1 Cable ................................1 2 Network Configuration ..........................2 Initializing Device ..................................2 Modifying Device IP Address ..............................3 Logging in to Web Interface..............................4 3 Installation .............................. -
Page 7: Cable
Quick Start Guide Cable Cable type might vary with different devices, and the actual product shall prevail. Waterproof all the cable joints with insulating tape and waterproof tape to avoid short circuit and water damage. For the detailed operation, see the FAQ Manual. Figure 1-1 Cable list For more information about cable ports, see Table 1-1. -
Page 8: Network Configuration
Quick Start Guide Network Configuration Device initialization and IP address setting can be finished with the "ConfigTool" or on web interface. For more information, see the Web Operation Manual. Device initialization is available on select models, and it is required for the first use or after the ... -
Page 9: Modifying Device Ip Address
Quick Start Guide Select the devices that need initialization, and then click Initialize. Step 6 The password setting interface is displayed. See Figure 2-2. Figure 2-2 Password setting Step 7 Set and confirm the password of the devices, then enter a valid email address, and then click Next. -
Page 10: Logging In To Web Interface
Quick Start Guide The Modify IP Address interface is displayed. See Figure 2-3. Figure 2-3 Modify IP Address Step 3 Select Static mode, and then enter start IP, subnet mask, and gateway. IP addresses of multiple devices will be set to the same if you select the Same IP check ... - Page 11 Quick Start Guide Figure 2-4 Main interface...
-
Page 12: Installation
Quick Start Guide Installation Packing List The tool required for the installation such as electric drill is not provided in the package. The operation manual and related tool are contained in the disk or the QR code, and the actual ... -
Page 13: Installing Device
Quick Start Guide Installing Device 3.3.1 Installation Method 3.3.2 Attaching Device Make sure that the mounting surface is strong enough to hold at least three times of the weight of the device and bracket. - Page 14 Quick Start Guide Cable going through the mounting surface...
-
Page 15: Installing Waterproof Connector (Optional)
Quick Start Guide Cable going through the side cable tray 3.3.3 Installing Waterproof Connector (Optional) This part is needed only when there is a waterproof connector in the package and the device is used outdoors. -
Page 16: Adjusting Lens Angle
Quick Start Guide 3.3.4 Adjusting Lens Angle... - Page 17 Quick Start Guide...
