- Page 1 POE1648C v.1.0 PoE 54V/5A/4x17Ah PoE buffer power supply for up to 16 IP cameras. EN** Edition: 2 from 22.11.2016 Supersedes the edition: 1 from 12.02.2016...
- Page 2 POE1648C PSU features: DC 54V uninterruptible power supply to 16 cameras IP designed for 10Mbit/s and 100Mbit/s network battery housing: 4x17Ah/12V LED optical indication Wide range of AC supply voltage: 176÷264V protections: High efficiency: 85% ...
- Page 3 POE1648C 1. Technical description. 1.1. General description. The PSU is designed for supply of up to 16 webcams requiring stabilized voltage of 48V DC (+/-15%). The PSU supplies voltage of 54V DC and total current capacity of I=16x0,3A+0,5A Battery charging*. In case of mains power loss, the unit will instantly switch to battery operation.
- Page 4 POE1648C Fig. 2. Components arrangement. Fig. 3. The view of the PSU. Component No. Description [Fig. 3] The module of the switch mode PSU L-N power-supply connector 230V AC, PE protection connector LED light indicating correct operation of the switch mode PSU ADJ potentiometer –...
- Page 5 POE1648C Electrical parameters (Table 3). 176÷264V AC Mains supply Current consumption 1,5A@230V AC type PSU’s power 270W max. Efficiency 44V ÷ 54V DC – buffer operation Output voltage 37V ÷ 54V DC – battery operation 48÷56V DC The adjustment range of the output voltage <30°C...
- Page 6 POE1648C Diagram 1. Maximum permissible output current depending on ambient temperature. Installation. 2.1. Requirements. The buffer PSU should be mounted by a qualified installer, holding relevant permits and licenses (applicable and required for a given country) for 230V/AC and low-voltage installations. The unit should be mounted in confined spaces, in accordance with the 2nd environmental class, with normal relative humidity (RH=90% maximum, no condensation) and temperature range from -10°C up to +40°C.
- Page 7 POE1648C Fig. 4. Connection of cameras and network devices to the LAN and POE terminals. 5. Check the power supply output voltage: - output voltage of the unloaded power supply without a battery should amount to U=54V DC. 6. Connect the batteries in series according to the color markings:...
- Page 8 POE1648C WEEE LABEL Waste electrical and electronic equipment must not be disposed of with normal household waste. According to the European Union WEEE Directive, waste electrical and electronic equipment should be disposed of separately from normal household waste. CAUTION! The power supply unit is adapted for cooperation with the sealed lead-acid batteries (SLA). After the operation period they must not be thrown but recycled according to the applicable law.
