- Page 1 Martin M-Touch Safety and Installation Guide...
-
Page 2: Table Of Contents
Table of Contents Dimensions 3 Introduction 4 Technical Support 5 Safety Information 6 Electromagnetic Compatibility Included Items Software Setup and Powering Up Connection without a USB hub Connection with a USB hub Connections 10 Side Maintenance 11 Specifications Control and Programming 12 Playback Physical Connections 12... -
Page 3: Dimensions
Dimensions All dimensions are in millimeters... -
Page 4: Introduction
Introduction Thank you for purchasing the Martin™ M-Touch Lighting Control System. The system offers a powerful control surface when it is connected to a computer running Martin M-PC software. Please read this "Safety and Installation Guide" carefully. Visit the Martin™ website www.martin.com for further documentation including the software user manual and access to our online community. -
Page 5: Technical Support
Technical Support Martin™ operates a complete network of support services around the world. Experts in programming and operating Martin™ control systems can be found in every time zone and on every continent. Contact by email The best way to get questions answered or to report a problem is to email us at controllersupport@martin.dk Contact by phone In an emergency, call the dedicated 24-hour controller support hotline... -
Page 6: Safety Information
Safety Information This product is for professional use only. It is not for household use. It presents risks of lethal or severe injury due to electric shock. Read this document before powering or installing the console, follow the safety precautions listed below and observe all warnings in this document and printed on the product. -
Page 7: Included Items
USB cable Safety and Installation Manual Software The Martin M-Touch requires a Windows PC running Martin M-PC software. The software is available from the support website controllersupport.martin.com Please check periodically for new releases that may add new functionality or improvements. -
Page 8: Setup And Powering Up
USB. If you use a USB hub to connect the Martin M-Touch to a PC, it must be powered type. If you use an unpowered USB hub, the Martin M-Touch will fail to connect to the PC. -
Page 9: Connection Without A Usb Hub
Connection without a USB hub Connection with a USB hub... -
Page 10: Connections
Connections Side A USB-B 2.0 connector is placed on the right-hand side of the Martin M-Touch for connection to a host PC. The M-Touch can draw a maximum of 500 mA. If you use a USB hub, make sure that it is powered. -
Page 11: Maintenance
Maintenance The Martin M-Touch is a rugged, roadworthy device. Occasional cleaning is the only service required of the user. For any other service-related concerns, please contact your Martin™ dealer or visit www.martin.com. Any service not described in this document must be carried out by a qualified Martin technician. -
Page 12: Specifications
1x DMX universe output: 5-pin locking XLR 1x USB 2.0 input Electrical Mains Power: 5 VDC over USB Maximum current: 500 mA Included Items USB Cable 1.5 m Ordering Information Martin M-Touch P/N 90737040 Rack mount bracket P/N 91611690 P/N 35000383-A M-Touch Safety and Install Manual...
