The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user
to the presence of an insulated DANGEROUS VOLTAGE within the product's enclosure that may be of
sufficient magnitude to constitute an electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of impor-
tant operating and maintenance (servicing) instructions in the literature accompanying the appliance.
Mechanical Drawing & Dimensions (H x W x D):
24 23 22
Main Fuse
13-24
P N P N
N
1.625"(41.3mm)
RESET
1
OFF
0.75"
(19.1mm)
- 6 -
CAUTION: To reduce the risk of electric shock do not open enclosure.
There are no user serviceable parts inside.
Refer servicing to qualified service personnel.
1U EIA 19" Rack Mount Chassis
1.625" x 19.125" x 8.5" (41.3mm x 486mm x 216mm)
21 20 19 18 17 16
P N P P N P N P N P
N N

Top and Bottom

2 3 4 5 6 7 8
28VAC
OFF
24VAC
Fig. 3
(ON)
Power Switch With Built-In Circuit Breaker:
OFF position - Switch not illuminated. Outputs not powered.
RESET (ON) position - Switch illuminated. Outputs powered.
Circuit breaker tripped - Switch not illuminated.
Power LEDs on faceplate are not illuminated. Outputs not powered.
To reset circuit breaker set power switch to the ON (RESET) position
(Fig. 3, pg. 6).
Rear
15 14 13 12 11 10
Main Fuse
1-12
P N P N P N P P N P N
N
17.625" (447.7mm)
Front
9 10 11 12
28VAC 28VAC
OFF
OFF
24VAC 24VAC
19.125" (486mm)
9 8 7 6 5
P N P P N P N P N P
N
13 14 15 16 17 18 19
4 3 2 1
P N P N P N P
N
AC POWER
20 21 22 23 24
28VAC
OFF
24VAC
VertilLine24 Series Installation Guide
