  • Page 1 Table of Contents Quick Hitches QH05 Category l Hitch, QH15 Category l Hitch, & QH20 Category ll Hitch QH20 Series QH15 Series QH05 Series 22131 320-003M Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious - follow without exception.
  • Page 2 Land Pride assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained herein. Land Pride reserves the right to revise and improve its products as it sees fit. This publication describes the state of this product at the time of its publication, and may not reflect the product in the future.
  • Page 3 Parts Manual for this equipment. for Land Pride products. Download the appropriate App on your Refer to Parts Manual QR smart phone, open the App, point your Locator on this page for phone on the QR code and take a picture.
  • Page 4 ▲ Replace parts on this machine with ▲ Work in a clean dry area. rating equal to or greater than the genuine Land Pride parts only. Do gross weight of the towed ▲ Lower attached implement to the not alter this machine in a way machinery.
  • Page 5 Table of Contents Important Safety Information These are common practices that may or may not be applicable to the products described in this manual. Prepare for Emergencies Wear Avoid High Protective Equipment Pressure Fluids Hazard ▲ Be prepared if a fire starts. ▲...

  • Page 6: Safety Labels

    Spray soapy water onto the cleaned area. all damaged or missing labels. Order new labels from your Peel backing from label and press label firmly onto the nearest Land Pride dealer. To find your nearest dealer, surface. visit our dealer locator at www.landpride.com.

  • Page 7: Using This Manual

    The QH05 & QH15 Cat. l and QH20 Cat. ll Quick Hitches For quick reference and prompt service, record model are designed and built by Land Pride to provide quick and number and serial number in the spaces provided above easy 3-point hitch attachment and detachment of and again on warranty page 23.

  • Page 8: Tractor Requirements

    Table of Contents Section 1: Assembly & Set-Up Section 1: Assembly & Set-Up Tractor Requirements WARNING Ballast weights may need to be added to your tractor to maintain steering control. Refer to your tractor Operator’s Manual to determine proper ballast requirements. IMPORTANT: Some Cat.

  • Page 9: Section 1: Assembly & Set-Up

    Table of Contents Section 1: Assembly & Set-Up 23998 37123 Tractor Hook-Up to QH05 Quick Hitch Figure 1-1 23998 37199 Tractor Hook-Up to QH15 & QH20 Quick Hitches Figure 1-2 Tractor Hook-Up 3. Sit Quick Hitch upright on the ground close to the lower 3-point lift arm hitch holes with auto-lock hooks (#7) facing away from the tractor.
  • Page 10 Replace driveline shafts and shields if thy are too near the implement. short. See your nearest Land Pride dealer for new shafts and shields. Hook-up Without Floating Top Links Refer to Figure 1-3: 6.
  • Page 11 Table of Contents Section 1: Assembly & Set-Up Implement Hook-Up to QH15 Go to page 8 for “Implement Hook-Up to QH05” and Clevis Pins page 11 for “Implement Hook-Up to QH20”. Hairpin DANGER Cotters A crushing hazard exist between Quick Hitch and implement. Do not allow anyone to stand between the Quick Hitch and implement during hook-up operations.
  • Page 12 IMPORTANT: When hooking-up a driveline, make Additional bushings may be purchased from your local sure it is not too short to comply with shaft Land Pride dealer so that more than one implement is overlapping guidelines. Refer to your implement readily available for quick hook-up.
  • Page 13 Replace driveline shafts and shields if they are too Release Handles have areas where pinching can occur. Keep short. See your nearest Land Pride dealer for new hands, fingers, and other body parts away from the pivoting shafts and shields.
  • Page 14 Table of Contents Section 1: Assembly & Set-Up 13. Store driveline off the ground. See implement Hook-up With Floating Top Links Operator’s Manual for instructions on how to store Complete steps 1 to 6 under “Hook-up Without driveline. Floating Top Links” on page 11 except shorten top 14.
  • Page 15 Table of Contents Section 1: Assembly & Set-Up 23998 37123 Unhooking QH05 Quick Hitch Figure 1-10 23998 37199 Unhooking QH15 & QH20 Quick Hitches Figure 1-11 Unhooking Quick Hitch 3. Keep Quick Hitch from rotating on lower 3-point hitch pins (#5) while removing upper center hairpin cotter (#2) and hitch pin (#3).

  • Page 16: Section 2: Operating Instructions

    Handling” when we refer to your implements. If you are • Important Safety Information, pages 1 to 3 going to gain the benefit of owning a Land Pride Quick Hitch you will need to park your implements on a firm •...

  • Page 17: Section 3: Optional Equipment

    Implements with gauge wheel(s) usually require a floating top link to allow the gauge wheel(s) to float with the contour of the land. Land Pride offers optional Floating Top Link Kits designed to adapt the QH05, QH15, and QH20 Quick Hitches for those products: Determine which Quick Hitch you have and refer to the following installation instructions for that hitch.
  • Page 18 Table of Contents Section 3: Optional Equipment SEE NOTE IN BOX ABOVE IMPLEMENT TOP LINK (NOT ASSEMBLY INSTRUCTIONS INCLUDED WITH QUICK HITCH FLOATING TOP LINK KIT) IMPLEMENT TOP LINK (NOT INCLUDED WITH QUICK HITCH FLOATING TOP LINK KIT) 24878 18116 QH15 Floating Top Link Installation QH20 Floating Top Link Installation Figure 3-2...
  • Page 19 Table of Contents Section 3: Optional Equipment Floating Top Link Positioning Transporting Position Refer to Figure 3-5: Operating Position The floating top links should be straight as shown when Refer to Figure 3-4: implement’s gauge wheel(s) are raised off the ground. Park tractor and implement on level ground.

  • Page 20: Section 4: Maintenance & Lubrication

    TU, QT, or GL to the end of the aerosol part number. CAUTION Land Pride Aerosol Touch-up Paint Do not alter Land Pride equipment or replace parts with other Part No. Part Description brands. Doing so can cause equipment to perform improperly and may lead to breakage that can cause bodily injury.

  • Page 21: Section 5: Specifications & Capacities

    Table of Contents Section 5: Specifications & Capacities Section 5: Specifications & Capacities QH05, QH15, & QH20 Series List Specifications & Capacities Model Number QH05 QH15 QH20 Hitch Category 1, 3-point Category 1, 3-point Category 2, 3-point Overall width 32 1/4"...
  • Page 22 Table of Contents Section 5: Specifications & Capacities 37128 QH05 Quick Hitch Figure 5-1 26874 QH15 Quick Hitch Figure 5-2 24879 QH20 Quick Hitch Figure 5-3 QH15 Category l Hitch, & QH20 Category ll Hitch Quick Hitches 320-003M 12/04/15...

  • Page 23: Section 6: Features & Benefits

    Table of Contents Section 6: Features & Benefits Section 6: Features & Benefits QH05, QH15, & QH20 Series Features Benefits Model Number QH05 QH15 QH20 Enables adjustment if Adjustable top hook needed on implements that (QH15 Only) are not true Cat. l Standard lower link pin size 7/8"...

  • Page 24: Section 7: Torque Values Chart

    Table of Contents Section 7: Torque Values Chart Section 7: Torque Values Chart Torque Values Chart for Common Bolt Sizes Bolt Head Identification Bolt Head Identification 10.9 Bolt Size Bolt Size (inches) Grade 2 Grade 5 Grade 8 (Metric) Class 5.8 Class 8.8 Class 10.9 in-tpi...

  • Page 25: Section 8: Warranty

    This Warranty is limited to the repair or replacement of any defective part by Land Pride and the installation by the dealer of any such replacement part, and does not cover common wear items such as blades, belts, tines, etc. Land Pride reserves the right to inspect any equipment or parts which are claimed to have been defective in material or workmanship.
  • Page 26 Corporate Office: P.O. Box 5060 Salina, Kansas 67402-5060 USA www.landpride.com...
