F4 Phantom
64mm EDF Kit

Specifications

Wingspan:
21.9in (556mm)
Length:32.7
in (830mm)
Flying Weight:
520g

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F4 Phantom 64mm EDF Kit and is the answer not in the manual?

Questions and answers

Related Manuals for EliteModels F4 Phantom 64mm EDF Kit

Summary of Contents for EliteModels F4 Phantom 64mm EDF Kit

  • Page 1 F4 Phantom 64mm EDF Kit Specifications Wingspan: 21.9in (556mm) Length:32.7 in (830mm) Flying Weight: 520g...
  • Page 2 Dear Customer, Congratulations on your purchase of F4 Phantom 64mm EDF Kit from Value Hobby. We thank you for your generous support, and hope you enjoy your new airplane. At Value Hobby, we hope to offer competitive prices, good performance, and products that you can setup and use with ease.
  • Page 3 Before Starting Assembly Unpack your airplane and examine the components. Check for damage of any kind. If you see any damage, please contact Value Hobby immediately. Airframe Parts 1. Fuselage 2. Right and left wing 3. Elevator 4. 64mm EDF 5.
  • Page 4 11. Sticker 12. Foam plates 13. Control horn rod set 14. Landing gears RECOMMENDED EQUIPMENT Product Quantity Flysky FS-T4B 2.4GHz 4CH Transmitter and Receiver (TX+RX Set) FLY-RC-2486 GForce 30C 1300mAh 3S 11.1V LiPO (T-Connector) RFI-LP-1870 Emax ES08MA II Analog Metal Gear Micro Servo (Set of 4) VHB-SV-6148 Hobbywing Skywalker 40A ESC (T-Connector)
  • Page 5 Illustration of Assembly： (4) Secure two servos on the two wing halves. (1) Open the box and put out all the spare parts. (5) Secure two servos in the slot of the tail. (2) Glue the nose side shown by the chart. (6) Apply glue to the sides of each main wing panel.
  • Page 6 (7) Hold the fuselage gently and push each main wing to appropriate place. (9) Glue the combined side of the vertical tail wing and push it gently into the slot at rear of fuselage. (8) Hold each main wing gently for one minute and let them connect to the fuselage firmly.
  • Page 7 (10) Connect the servos on main wings to the Y- connector. Make sure that the signal wire is oriented properly. (12) Make sure the center of gravity is in the place just like the picture shows. (13) The ESC and brushless motor can be easily (11) Install 64mm EDF in the fuselage.
