Fortin E400 Quick Installation Manual

E400
AUTOMATIC & MANUAL TRANSMISSION
REMOTE STARTER & ALARM
WIRING / CONNECTION GUIDE WIRING / CONNECTION GUIDE
Cut loop for automatic
transmission mode.
Red Black White Black
Programming LED
External LED (2-pin)
Shock Sensor (3-pin)
(2pin) Valet/Programming
Button
PROGRAMMING REMOTE TRANSMITTER(S) PROGRAMMING REMOTE TRANSMITTER(S)
1 2
1
STEP STEP
Turn the Press and hold the
Ignition ON. valet switch until
the Parking lights
turn ON, the horn/
siren will chirp.
COPYRIGHT © 2015-2016, FORTIN AUTO RADIO INC ALL RIGHTS RESERVED MADE IN CANADA
Power
Power
Power
Parklights
Ign/Acc/Start
Tachometer
Foot-Brake
Door Pin Pos
Trunk/Hatch (open)
(-) while running
Lock
Arm
Starter
Parklight
Aux.1
Aux.2
Not Use
Blue Blue
(4-pin) Antenna
(4-pin) Antenna
(4-pin) RS-232 Data-Link
3 4
2 3
STEP
X1
Press and release the
valet-switch once.
The
parking lights will
fl ash to confi rm.
Red
(utility)
#22
Red
#14
Red
#14
Brown
#18
White
#14
Purple
White
Orange
White/Black
Dk. Blue
ONE
White/Red
Yellow/Red
Yellow/Black
Brown/White
Lt. Green
Lt. Green/Black
ONE
Lt.Blue
Ignition
Starter
Ignition Switch
The system can learn up to a maxi- The system can learn up to a maxi-
mum of 4 transmitters. mum of 4 transmitters.
Any transmitters can be stored in Any transmitters can be stored in
more than 1 memory slot. more than 1 memory slot.
When a 5th transmitter is learned When a 5th transmitter is learned
the 1st remote is erased (FIFO). the 1st remote is erased (FIFO).
4
STEP
X1
Press and re- On each Transmitter press
lease the brake the LOCK button once
pedal once. (maximum 4 transmitters),
the parking lights will fl ash
INSTALLATION GUIDE
1
Yellow
#14
Orange
#14
Pink
#14
Black
#18
8
1
Grey
~
Brown
Dk. Green
Pink
Yellow
White/Green
Yellow/Green
Pink/Black
Orange/Black
Red/Black
Red
Purple/White
24 Neutral Safety Switch for manual transmission vehicle
Starter-Kill / Anti-Grind Relay
See programming guide, Function #10
5
STEP STEP
Press and
release the
brake-pedal
once.
to confi rm.
QUICK
RF25BV/RF252W
GUIDE # 32501
OUTPUT
INPUT
Starter
Accessory
Ignition
Ground
Hood Pin
E-Brake
Door Pin Neg.
Trunk/Hatch Pin
Starter Kill
Unlock
Disarm
Ignition
Accessory
Horn
Siren
Aux.IN
To Vehicle
To Vehicle
Optional Relay
6 7
STEP
X1
Turn the Ignition
OFF to exit
programming.
REV.:20161011
