Updated fi rmware and installation guides are posted on our web site on a regular FIRMWARE VERSION Date: xx-xx basis. We recommend that you update this module to the latest fi rmware and EVO-ALL download the latest installation guide(s) prior to the installation of this product. INTERFACE MODULE PATENTS PENDING US: 2007-228827-A1 Made in Canada www.fortinbypass.com...
Page 2
This guide may change without notice. See www.fortin.ca for latest version. 2 /14 Page Ce guide peut faire l’objet de changement sans préavis. Voir www.fortin.ca pour la récente version. PARTS REQUIRED (NOT INCLUDED) | PIÈCES REQUISES (NON INCLUSES) FLASH LINK...
Page 3
This Guide may change without notice. www.ifar.ca for latest version. Page 3 / 4 3 / 15 Page Ce Guide peut faire l’objet de changement sans préavis. www.ifar.ca pour la récente version. DESCRIPTION | DESCRIPTION VEHICLES EQUIPPED WITH AN OEM ALARM I VÉHICULE ÉQUIPPÉ D’UNE ALARME D’ORIGINE Certains véhicules doivent être DÉVERROUILLÉS avant le démarrage Some vehicles must be UNLOCKED to disarm the OEM alarm à...
Page 4
This Guide may change without notice. www.ifar.ca for latest version. Page 3 / 4 4 / 15 Page Ce Guide peut faire l’objet de changement sans préavis. www.ifar.ca pour la récente version. VEHICLE FIT GUIDE | GUIDE DES VÉHICULES Functional if equipped | Fonctionnelle si le See Legend below véhicule en est équipé.
Page 5
This Guide may change without notice. www.ifar.ca for latest version. Page 3 / 4 5 / 15 Page Ce Guide peut faire l’objet de changement sans préavis. www.ifar.ca pour la récente version. CONNECTION 1 GO NEXT PAGE ADDENDUM - SUGGESTED WIRING CONFIGURATION NISSAN / INFINITI SCHÉMA DE BRANCHEMENT SUGGÉRÉ...
Page 6
6 / 15 Page Ce Guide peut faire l’objet de changement sans préavis. www.ifar.ca pour la récente version. CONNECTION 1 PUSH TO START - AUTOMATIC TRANSMISSION | TRANSMISSION AUTOMATIQUE GO PROGRAM.: 1 EVO-ALL STAND ALONE Optional RF-KIT OR Optionnel Hood Pin Optional...
Page 7
This Guide may change without notice. www.ifar.ca for latest version. Page 3 / 4 7 / 15 Page Ce Guide peut faire l’objet de changement sans préavis. www.ifar.ca pour la récente version. CONNECTION 2 GO NEXT PAGE Brake switch OBD-II Connector Connecteur OBD-II Commutateur de frein...
Page 8
8 / 15 Page Ce Guide peut faire l’objet de changement sans préavis. www.ifar.ca pour la récente version. CONNECTION 2 PUSH TO START - AUTOMATIC TRANSMISSION | TRANSMISSION AUTOMATIQUE GO PROGRAM.: 2 EVO-ALL STAND ALONE Optional RF-KIT OR Optionnel Hood Pin Optional...
Page 9
This Guide may change without notice. www.ifar.ca for latest version. Page 3 / 4 9 / 15 Page Ce Guide peut faire l’objet de changement sans préavis. www.ifar.ca pour la récente version. PROGRAM. 1 PUSH TO START 1/3 Insert the key in to the key port.
Page 10
This Guide may change without notice. www.ifar.ca for latest version. Page 3 / 4 10 / 15 Page Ce Guide peut faire l’objet de changement sans préavis. www.ifar.ca pour la récente version. PROGRAM. 1 PUSH TO START 2/3 Press and release the Push-to-Start Appuyez et relâchez 1 fois sur le ACCESSORY ON IGNITION ON...
Page 11
This Guide may change without notice. www.ifar.ca for latest version. Page 3 / 4 11 / 15 Page Ce Guide peut faire l’objet de changement sans préavis. www.ifar.ca pour la récente version. PROGRAM. 1 PUSH TO START 3/3 REMOTE STARTER FUNCTIONNALITY | FONCTIONNALITÉS DU DÉMARREUR À DISTANCE START All doors must The vehicle will...
Page 12
This Guide may change without notice. www.ifar.ca for latest version. Page 3 / 4 12 / 15 Page Ce Guide peut faire l’objet de changement sans préavis. www.ifar.ca pour la récente version. PROGRAM. 2 PUSH TO START 1/3 Remove the valet key from the back of the OEM remote. Remove the battery from the OEM remote.
Page 13
Internet Reconnect the 4-Pin (Data-Link) connector and after all the remaining connector. Rebranchez le connecteur 4-pins (Data-Link) et après tous les connecteurs du EVO-ALL. REMOTE STARTER / ALARM VERIFICATION PROCEDURE | PROCEDURE DE VÉRIFICATION The module is now programmed.
Page 14
This Guide may change without notice. www.ifar.ca for latest version. Page 3 / 4 14 / 15 Page Ce Guide peut faire l’objet de changement sans préavis. www.ifar.ca pour la récente version. PROGRAM. 2 PUSH TO START 3/3 REMOTE STARTER FUNCTIONNALITY | FONCTIONNALITÉS DU DÉMARREUR À DISTANCE All doors must Press the OEM remote’s All doors must...
Page 15
The installation in every case is the sole responsibility of the installer performing the work and FORTIN ELECTRONIC SYSTEMS assumes no liability or responsibility whatsoever resulting from any type of installation, whether performed properly, improperly or any other way.
