E400
RF751W
WIRING / CONNECTION GUIDE
Cut loop for automatic
transmission mode.
Programming LED
External LED (2-pin)
Shock Sensor (3-pin)
(2pin) Valet/Programming
Power
Power
Power
Parklights
Ign/Acc/Start
Tachometer
Foot-Brake
Door Pin Pos
Trunk/Hatch (open)
(-) while running
Lock
Arm
Starter
Parklight
Aux.1
Aux.2
Not Use
Red
Black White
Black
Blue
Blue
(4-pin) Antenna
(4-pin) Antenna
(4-pin) RS-232 Data-Link
Button
Red #22
(utility)
Red #14
Red #14
Brown #18
White#14
8
Purple
White
Orange
White/Black
Dk. Blue
White/Red
Yellow/Red
Yellow/Black
Brown/White
Lt. Green
Lt. Green/Black
Lt.Blue
24
Ignition
Starter
Ignition Switch
AUTOMATIC & MANUAL TRANSMISSION
REMOTE STARTER & ALARM
QUICK INSTALLATION GUIDE
OUTPUT
1
Yellow #14
Orange #14
Pink #14
Black #18
1
Grey
~
Brown
Dk. Green
Trunk/Hatch Pin
Pink
Yellow
White/Green
Yellow/Green
Pink/Black
Orange/Black
Red/Black
Red
Purple/White
Neutral Safety Switch for manual transmission vehicle
87
Optional Relay
87a
Starter-Kill / Anti-Grind Relay
86
85
See programming guide, Function #10
30
GUIDE # 32471
INPUT
Starter
Accessory
Ignition
Ground
Hood Pin
E-Brake
Door Pin Neg.
Starter Kill
Unlock
Disarm
Ignition
Accessory
Horn
Siren
Aux.IN
To Vehicle
To Vehicle
PAGE 1
Advertisement
Table of Contents
Related Manuals for Fortin E400 RF751W
Summary of Contents for Fortin E400 RF751W
- Page 1 E400 AUTOMATIC & MANUAL TRANSMISSION REMOTE STARTER & ALARM QUICK INSTALLATION GUIDE RF751W GUIDE # 32471 WIRING / CONNECTION GUIDE OUTPUT INPUT Power Red #22 (utility) Power Starter Yellow #14 Red #14 Accessory Power Red #14 Orange #14 Parklights Ignition Pink #14 Brown #18 Ign/Acc/Start...
- Page 2 PROGRAMMING REMOTE TRANSMITTER(S) The system can learn up to a maximum of 4 transmitters. Any transmitters can be stored in more than 1 memory slot. When a 5 transmitter is learned the 1 remote is erased (FIFO). STEP 1 STEP 2 STEP 3 STEP 4 STEP 5...
- Page 3 READY MODE STEP 1 STEP 2 STEP 3 STEP 4 STEP 5 STEP 6 THE ENGINE’S Push the START TACHOMETER SIGNAL MUST button (3sec.). Make sure BE DETECTED BY The Parking lights that all doors THE REMOTE STARTER TO will flash once and are closed OPERATE IN A MANUAL then remain on.
- Page 4 To download the installation guide, user guide, or the latest quick installation guide, visit: Technical support: TEL: 514-255-4357 / 1-877-336-7797 Copyright © 2014-2017, FORTIN AUTO RADIO INC ALL RIGHTS RESERVED MADE IN CANADA REV.:20170825 PAGE 8...
- Page 5 FUNCTION PROGRAMMING STEP 1 STEP 2 STEP 3 STEP 4 STEP 5 STEP 6 MODE 1 - LOCK Disarm MODE 2 - UNLOCK MODE 3 - START (3 SECONDS) system MODE 4 - TRUNK (3 SECONDS) (The MODE 5 - TRUNK LOCK antenna...
- Page 6 FUNCTION MODE 3 MODE 1 DEFAULT MODE 4 MODE 2 MODE 5 MODE 6 Unlock before remote- Unlock and relock after Relock 10 sec.after Disarm before shut Lock/Unlock control start & Lock after Lock after remote-start. shut-down. shut-down. down. remote-start. Lock after foot-brake Ignition Lock/Unlock Unlock after key is...
- Page 7 FUNCTION MODE 3 MODE 1 DEFAULT MODE 4 MODE 2 MODE 5 MODE 6 Enable Ignore door trigger (dome light) Domelight Delay Disable — — — — when arming or Remote-starting Enable (20 seconds) Enable (10 seconds) Enable Delay between Ignition Delay between Ignition No delay between —...
- Page 8 FUNCTION MODE 3 MODE 1 DEFAULT MODE 4 MODE 2 MODE 6 MODE 5 Special application - Function 2 (all option) not available. Special application Enable at ground out, No special application White wire (5 relays): White wire (5 relays): Programmable —...
