Installation
Xtreme Mix
and ProMix Easy
Data Download Kit
Part No. 246322
For use with Xtreme Mix units located in a non-hazardous location.
Includes data download software CD (15B734) and RS-232 cable (15A926).
Part No. 246397
For use with Xtreme Mix units located in a hazardous location.
Includes data download software CD (15B734) and RS-232 cable with barrier (15B816).
Part No. 248404
For use with ProMix Easy and Xtreme Mix 185 units located in a non-hazardous location.
Includes data download software CD (15E074) and RS-232 cable (15A926).
Part No. 248403
For use with ProMix Easy and Xtreme Mix 185 units located in a hazardous location.
Includes data download software CD (15E074) and RS-232 cable with barrier (15B816).
WARNING
To reduce the risk of fire and explosion, which could cause serious injury and property damage, the PC
must be in a non-hazardous location.
If connecting RS-232 cable to a unit used in a hazardous location, a safety barrier must be installed
between the PC and unit. Use Kit 246397/248403 and see F
Except as noted, instructions in this manual apply to both ProMix Easy and Xtreme Mix units,
which are referred to as "the unit".
Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441
Copyright 2002, Graco Inc. is registered to I.S. EN ISO 9001
, Xtreme Mix
185,
. 2 for installation requirements.
IG
309623F

Advertisement

loading
Need help?

Need help?

Do you have a question about the Xtreme Mix and is the answer not in the manual?

Questions and answers

Summary of Contents for Graco Xtreme Mix

  • Page 1 PC and unit. Use Kit 246397/248403 and see F . 2 for installation requirements. Except as noted, instructions in this manual apply to both ProMix Easy and Xtreme Mix units, which are referred to as “the unit”. Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441...
  • Page 2 309623F...
  • Page 3: Installing Software

    2. Turn on air to start the unit. refer to Software Troublshooting on page 7. 7. Click Setup > Save Setup. 8. Save the file as teraterm.ini. Xtreme Mix in directory: C:\Program Files\Graco\Graco XtremeMX log 1.02. or ProMix Easy in directory: C:\Program Files\Graco\Graco ProMixEZ log 1.01.
  • Page 4 RS-232 cable to the PC, purchase a USB-to-serial port adapter (available at most retail electronics stores). Graco has tested the Edgeport/1 converter from B&B electronics but other adapters may be used. After installing the converter and the software you must confirm the COM port.
  • Page 5 4. On the list of devices displayed in Device Manager, 5. Ports (COM & LPT) expands and displays the name click on the plus (+) sign in front of “Ports (COM & of the newly installed adapter including the COM LPT).
  • Page 6 Log Program 1. Start XtremeMX Log or ProMixEZ Log program from your Start menu. The XtremeMX Log or ProMixEZ Log program starts 2. Tera Term: COM window opens. communication between the PC and the unit and 3. You are prompted to enter the log file name. Type in retrieves log and alarm files.
  • Page 7: Software Troubleshooting

    ProMixEZRunLog.txt in the directory specified in #3 above. (Type Ctrl-X several times to cancel the transfer) Setup Program Software Troubleshooting If the Graco program does not start, check the following: Use Setup program to: • Is the power on? •...
  • Page 8 Setup examples for Xtreme Mix Welcome to the Graco Control Application Menu Build date: Sep 11 2002 08:36:59 (debug build) a. Software Update and Version Information Choices: b. View Log Files c. Set Date and Time d. Enter Calibration Information e.
  • Page 9 Welcome to the Graco Control Application Menu Note: Choose the pump size Build date: Sep 11 2002 08:36:59 (debug build) value from the chart below. a. Software Update and Version Information b. View Log Files c. Set Date and Time d.
  • Page 10 Setup examples for ProMix Easy and Xtreme Mix 185 Welcome to the Graco Control Application Menu Selection b: View Log Files Build date: Mar 08 2004 11:18:39 (debug build) a. Software Update and Version Information Choices: b. View Log Files c.
  • Page 11 Selection c: Enter Pump Size Enter Selection [a-g]: c Enter new pump size (cc/cycle). Current = 54 Note: Pump values shown here ? 54 for selections c, d, and e are for Pump size (cc/cycle) = 54. Ultra Mix pump, see table on page 9 for other pumps Enter Selection [a-g]: d Selection d: Enter Pump...
  • Page 12: Graco Phone Numbers

    . 10 Graco Phone Numbers TO PLACE AN ORDER, contact your Graco distributor or call to identify the nearest distributor. Phone: 612-623-6921 or Toll Free: 1-800-328-0211, Fax: 612-378-3505 All written and visual data contained in this document reflects the latest product information available at the time of publication.
