Olympus CLV-180 Maintenance Manual page 11

Endoscope and light guide
Light-supply cable (MAJ-1411)
Expansion cable (MAJ-202/972)
Foot switch (MAJ-1391)
Emergency lamp indicator
Setting retention
Switch illumination system
(not including counter reset
switch)
On endoscope removal
Exterior
Temperature switch
Protection
Region
1. EU/ EFTA
2. Japan
3. USA
ISSUE1
One-touch connection
Connector on the rear-panel
(Light-supply cable for CV connection)
System connector on the rear-panel
(compatible with Endo GATE/Endo ALPHA)
Foot switch connector on the rear-panel
Indicates if the emergency lamp is disconnected or if the
emergency lamp is in use (when the main lamp will not illuminate).
・Lit up: Emergency lamp in use (the main lamp will not illuminate).
・Blinking: Emergency lamp is disconnected or has been removed.
(1)
(1)
(1)
(1)
(1)
Class 1 unit (3P power supply)
Sold MDD
? Class:II a (rule: 11-1)
Y
CE marking: CEO197
Pharmaceutical Law (Application of the Pharmaceutical law to assist Asian
N
market response)
FDC laws
Y
Settings prior to powering off the unit are retained.
・Manual / automatic brightness settings
・Airflow settings
・Light intensity level
・High-intensity mode setting
・Special observation function display
・Lamp life indicator (with the power ON, the indicator may
be reset when the examination lamp is extinguished by
continuously pressing the counter reset switch.)
All switches illuminated
(not including counter reset switch)
When the endoscope is removed, the light emanating from
the scope connector is dimmed by the dimmer plate
located in the endoscope socket.
Disinfect with ethanol for disinfection (70％ ethyl or
isopropyl alcohol) or with a mild detergent.
To ensure safety, when the internal temperature rises
above the specified value, the temperature switch turns off
and the electrical current supply to the lamp is terminated.
The unit detects that the temperature switch has shut off,
and sounds an alarm.
1-7
Specification CLV-180
