CH AP TER 2 | G e t t i n g t o K n o w
The E Z Connect™ W ireless Cable Modem G ateway is the perfect all in one solution, for the
home or business environment. This full-featured device has:
An approved DO CSIS 1.1 Cable modem
•
Advanced SP I F irewall G ateway
•
H igh-speed 5 4 Mbps 8 02.11g W ireless Access P oint
•
Comprehensive L E Ds for network status and troubleshooting
•
R eset B utton
•
4 – 10/ 100 Mbps Auto-Sensing L AN ports with Auto-MDI MDIX feature
•
1 – U SB 1.1 L AN P ort for P C connectivity (Note: Not supported by all cable operators)
•
N OT E : Cable modems provide up to 38 Mbps downstream and 10 Mbps upstream. H owever, you
should note that the actual rate provided by specific service providers may vary dramatically
from these upper limits.
L E D I n d ic a tors
The E Z Connect™ W ireless Cable Modem G ateway includes L E D indicators on the front panel
that simplify installation and network troubleshooting.
The W ireless Cable Modem G ateway includes L E D indicators on the front panel that simplify
installation and network troubleshooting.
L AB E L L E D COL OR
P ower G re e n
Diag Am b e r
Cable G re e n
Traffic G re e n
W ireless G re e n
L AN (1-4) Am b e r
L AN (1-4) G re e n
U SB G re e n
G a t e w a y
ON
P ower is supplied to the
G ateway
System F ailure. R eboot
G ateway
Successfully connected to
cable network
Cable Modem has finished
CMTS registration
G ood W ireless L ink
Connected at 10 Mbps
Connected at 100 Mbps
U SB port connected
t h e W i r e l e s s Ca b l e M o d e m
FL AS H I N G
N/ A
N/ A
Attempting to
connect to network
Attempting to
register with CMTS
Data transmitting
Data transmitting
Data transmitting
Data transmitting
OFF
P ower is not
supplied to the
G ateway
Normal O peration
N/ A
N/ A
No W ireless L ink
No E thernet link
detected
No E thernet link
detected
No U SB link detected
