MODEL #
CM3493PT-5PK
Questions?
GIVE US A CALL: 1-888-980-5122
MON – FRI 8:30AM – 5:30PM (PST)
TOOLS REQUIRED
Philips
Screwdriver
(Not Included)
2 - Pelpoe
Recommended
ASSEMBLY RATING
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America CM3493PT-5PK
Summary of Contents for Furniture of America CM3493PT-5PK
- Page 1 MODEL # CM3493PT-5PK Questions? GIVE US A CALL: 1-888-980-5122 MON – FRI 8:30AM – 5:30PM (PST) TOOLS REQUIRED Philips Screwdriver (Not Included) 2 - Pelpoe Recommended ASSEMBLY RATING EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / 13...
- Page 5 COUNTER HEIGHT TABLE CM3493PT-5PK #1 1pc #2 1pc #3 1pc #4 1pc #5 1pc #6 1pc Table Top Side Panel L Side Panel R Center Panel Base Door #7 2pcs #8 2pcs #9 2pcs #10 2pcs #11 2pcs #12 2pcs...
- Page 6 ASSEMBLY INSTRUCTIONS Insert dowels (#G) to the side panel (#2), then align side panel (#2) to the top (#1). Secure by using bolts (#A) with washers (#D,E). Part #1 x1pc Part #2 x1pc Hardware #A x2pcs Hardware #D x2pcs Hardware #F x2pcs Hardware #G x2pcs...
- Page 7 ASSEMBLY INSTRUCTIONS Align base (#5) to the panels, then secure by using bolts (#B) with washers (#D,E) onto barrel nuts (#H). Part #5 x1pc Hardware #B x6pcs Hardware #D x6pcs Hardware #E x6pcs Hardware #H x6pcs Hardware #N x1pc Part #6 x1pc Hardware #A x4pcs...
- Page 8 ASSEMBLY INSTRUCTIONS Part #7 x2pcs Hardware #A x2pcs Hardware #D x2pcs Hardware #F x2pcs Hardware #G x4pcs Hardware #N x1pc Secure side stretchers (#7) to side panels by using bolts (#A) with washers (#D,F), then insert dowels (#G) onto side panels (#7). Part #8 x2pcs Hardware...
- Page 9 ASSEMBLY INSTRUCTIONS Hardware #K x2pcs Attach levelers (#K) to the legs. ONE SIDE OF TABLE Part #9 x2pcs Part #10 x2pcs Part #11 x2pcs Hardware #A x8pcs Hardware #D x8pcs Hardware #F x8pcs Hardware #L x8pcs Hardware #N x1pc Align wine racks (#9,10) to the rack panels (#11), then secure by using bolts (#A) with washers (#D,F).
- Page 10 ASSEMBLY INSTRUCTIONS OTHER SIDE OF TABLE Part #12 x2pcs Hardware #L x8pcs Insert shelf pins (#L) to the desired height of the shelves (#12). 10 / 13...
- Page 11 COUNTER HEIGHT STOOL CM3493PT-5PK #1 1pc #2 2pcs #3 2pcs #4 4pcs Side Stretcher Seat With Frame #A 4pcs #B 4pcs #C 4pcs M6 x 45MM Bolt M6 x 13MM M6 x 19MM Spring Washer Flat Washer #D 8pcs #E 1pc...
- Page 12 ASSEMBLY INSTRUCTIONS Align leg (#2) to seat (#1), then secure by using bolts (#A) with washers (#B,C). Insert stretchers (#4) to the leg (#2). Part #1 x1pc Part #2 x1pc Part #4 x2pcs Hardware #A x1pc Hardware #B x1pc Hardware #C x1pc Hardware #E x1pc...
- Page 13 ASSEMBLY INSTRUCTIONS Align leg (#2) to the seat and stretchers, then secure leg (#2) to seat by using bolts (#A) with washers (#B,C). Secure stretchers by using screws (#D). Part #2 x1pc Hardware #A x1pc Hardware #B x1pc Hardware #C x1pc Hardware #D x8pcs Hardware...
