MODEL #
CM3492PC-2PK
Questions?
GIVE US A CALL: 1-888-980-5122
MON – FRI 8:30AM – 5:30PM (PST)
TOOLS REQUIRED
Philips
Screwdriver
(Not Included)
2 - Pelpoe
Recommended
ASSEMBLY RATING
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America CM3492PC-2PK
Summary of Contents for Furniture of America CM3492PC-2PK
- Page 1 MODEL # CM3492PC-2PK Questions? GIVE US A CALL: 1-888-980-5122 MON – FRI 8:30AM – 5:30PM (PST) TOOLS REQUIRED Philips Screwdriver (Not Included) 2 - Pelpoe Recommended ASSEMBLY RATING EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / 9...
- Page 5 COUNTER HEIGHT CHAIR CM3492PC-2PK #1 1pc #2 1pc #3 1pc #4 1pc Side Chair Back Cushion Seat Seat Frame Stretcher #5 1pc #6 1pc #7 1pc #8 1pc Side Front Front Leg Front Leg Stretcher Stretcher #A 2pcs #B 4pcs...
- Page 6 ASSEMBLY INSTRUCTIONS Part #1 x1pc Part #3 x1pc Hardware #A x2pcs Hardware #D x2pcs Hardware #E x2pcs Hardware #H x1pc Align seat frame (#3) to the chair back (#1), then secure by using bolts (#A) with washers (#D,E). Hardware #C x4pcs Hardware #D x4pcs Hardware...
- Page 7 ASSEMBLY INSTRUCTIONS Align stretchers (#4,5) to the legs of the chair back. Part #4 x1pc Part #5 x1pc Align stretcher (#5) to the legs (#7,8), then align legs (#7,8) to the seat frame. Secure by using bolts (#B) with washers (#D,E). Part #6 x1pc Part...
- Page 8 ASSEMBLY INSTRUCTIONS Secure stretchers onto legs by using screws (#G). Hardware #G x6pcs Part #2 x1pc Hardware #F x4pcs Align seat frame to the seat cushion (#2), then secure by using screws (#F). There will be no pre-drilled holes for the seat cushion (#2). 8 / 9...
- Page 9 ASSEMBLY INSTRUCTIONS 9 / 9...
