CM3491SC-2PK
Questions?
GIVE US A CALL: 1-888-980-5122
MON – FRI 8:30AM – 5:30PM (PST)
TOOLS REQUIRED
Philips
Screwdriver
(Not Included)
2 - Pelpoe
Recommended
ASSEMBLY RATING
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Table of Contents
Related Manuals for Furniture of America Haleigh CM3491SC-2PK
Summary of Contents for Furniture of America Haleigh CM3491SC-2PK
- Page 1 MODEL # CM3491SC-2PK Questions? GIVE US A CALL: 1-888-980-5122 MON – FRI 8:30AM – 5:30PM (PST) TOOLS REQUIRED Philips Screwdriver (Not Included) 2 - Pelpoe Recommended ASSEMBLY RATING EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / 8...
- Page 5 SIDE CHAIR CM3491SC-2PK #1 1pc #2 1pc #3 1pc #4 2pcs Cushion Seat Seat Frame Front Leg Chair Back #A 2pcs #B 4pcs #C 4pcs #D 10pcs M6 x 35MM M6 x 60MM M6 x 80MM M6 x 13MM Bolt Bolt Bolt Spring Washer...
- Page 6 ASSEMBLY INSTRUCTIONS Align seat frame (#3) to the chair back (#1), then secure by using bolts (#A) with washers (#D,E). Part #1 x1pc Part #3 x1pc Hardware #A x2pcs Hardware #D x2pcs Hardware #E x2pcs Hardware #G x1pc Hardware #C x4pcs #G #C Hardware #D x4pcs...
- Page 7 ASSEMBLY INSTRUCTIONS Align legs (#4) to the seat frame, then secure by using bolts (#B) with washers (#D,E). Part #4 x2pcs Hardware #B x4pcs Hardware #D x4pcs Hardware #E x4pcs Hardware #G x1pc Part #2 x1pc Hardware #F x4pcs Align seat frame to the seat cushion (#2), then secure by using screws (#F).
- Page 8 ASSEMBLY INSTRUCTIONS 8 / 8...
