- Page 1 STEEL TOP 128 3 WAY 90° 134 GROUND TWINE & STEEL UPRIGHTS 10ftx10ftx10ft 10ftx10ft STEEL CENTRE 176 4 way PARTS BARS 2965mm CORNER CABLE TIES 3143mm (L) SOCKET 90° Joint GOLF NET IMPACT PANEL BAR (M) x1 PCK...
- Page 2 Lay out all the steelwork and connectors, checking that they match the parts list. Assemble the top of the frame by attaching 4 x 128 3-Way 90° Corners to the 2 x 176 4 way 90° joints and 7 x Steel Bars 2965mm. Use the top of the frame to mark the correct position of the 6 x 134 Ground Sockets.
- Page 3 Attach the 4 x Steel Uprights 3143mm to the top of the frame. Insert the Steel Uprights 3143mm to the 134 Ground Sockets. Tighten the grub screws to secure frame. Tie the net onto the assembled cage frame with the Twine and Cable Ties provided.
- Page 4 Fix the Impact Panel to the roof of the cage approximately 1ft from the back, using the Ties provided. The panel can then be left to hang free or attached to the side netting. Tools Required: STEP LADDERS ALLEN KEY Always Inspect goal post and net for defects before use and repair damaged parts.
