Net World Sports Forza Manual
Socketed netball post
Hide thumbs
Also See for Forza:
- Manual (10 pages) ,
- Assembly instructions manual (9 pages) ,
- Assembly instructions (5 pages)
Related Manuals for Net World Sports Forza
Summary of Contents for Net World Sports Forza
- Page 1 SOCKETED NETBALL POST @NetWorldSports www.networldsports.co.uk / / +44 (0) 1691 683 807 / / cs@networldsports.co.uk www.networldsports.com / / 1-866-861-9095 / / cs@networldsports.com...
-
Page 2: Parts List
PARTS LIST PA45297 PA45230 PA45298 PA45292 Socketed Post (x2) Rail connector (x1) Ground socket (x1) Hoop (x1) PA45288 PA45235 PA45273 PA38101 Rubber end cap (x1) Ground socket cap (x1) M8x16 hex head bolt (x4) M10x20 bolt (x2) PA45172 PA38115 PA38122 PA38133 M10x80 hex head bolt (x2) M10 lock nut (x6) - Page 3 *IMPORTANT* 1. Read through the instructions thoroughly before assembling. 2. Installation, movement and use of equipment should be carried out under the supervision of a competent person using due diligence and risk assessment. 3. Take extreme care when installing, moving and lifting components. 4, Check all parts are present with no defects prior to the assembly.
- Page 4 Step 2. Fit hoop and End cap. Slide 2 M10x20 (PA38101) bolts into the channel at 1 end of the assembled post, locate the hoop (PA45292) over the bolts and choose the required position. Once the Hoop is in position secure in place with M10 washers and M10 lock nut.
- Page 5 Step 1. Establish the position of each ground socket. To do this we recommend assembling the posts first and placing this into position where the post will be used. We recommend marking the 2 socket positions with spray paint where the post meets the ground.
- Page 6 Step 4. Fit post. Once ground socket is installed slide the post into the socket. Post locator...
