Balanced Body Reformer with Tower How To Install

How to install your Reformer with Tower
BEFORE BEGINNING ASSEMBLY
These instructions include a
parts list. Please use this list
to make sure you have all the
parts necessary for installation.
If you are missing a part,
please contact our customer
service department at
1-800-PILATES
(1-800-745-2837).
REQUIRED TOOLS
» 3/16" Allen Wrench (Included. GEN9280)
PARTS FOR TOWER
Vertical tubes with eyebolts
installed
Horizontal tube with eyebolts,
safety strap, and corner
connectors
Push–Through Bar
T-pin
Yellow trap springs
Blue trap springs
Roll down bar
Yellow long springs
Purple long springs
Single cotton loops (pair)
1. Loosen the setscrews in the circular tube receivers with
Figure A: Loosen set-screws here.
2. Lower the vertical (longer) tubes into receivers. Be sure
2 TRP0012
1 TRP0006
1 TRP0047
2 GEN9892
2 SPR9002
2 SPR9004
1 710-010
2 SPR9006
2 SPR9461
1 101-005
Figure B
included Allen wrench (see Fig. A).
that the loop of the bottom eyebolt on each vertical tube is
pointing toward the Reformer and the flat recessed holes
for the Push-Through Bar (PTB) on the side of the tubes are
facing inward/towards each other. (see Fig. B). Don't tighten
setscrews yet.
