Page 1 MX269017A Vector Modulation Analysis Software Operation Manual Operation 20th Edition ● For safety and warning information, please read this manual before attempting to use the equipment. ● Additional safety and warning information is provided within the MS2690A/MS2691A/MS2692A Signal Analyzer Operation Manual (Mainframe Operation) or MS2830A Signal Analyzer Operation Manual (Mainframe Operation).
Page 2 Ensure that you clearly understand the meanings of the symbols BEFORE using the equipment. Some or all of the following symbols may be used on all Anritsu equipment. In addition, there may be other labels attached to products that are not shown in the diagrams in this manual.
Page 3 In addition, this warranty is valid only for the original equipment purchaser. It is not transferable if the equipment is resold. Anritsu Corporation shall assume no liability for injury or financial loss of the customer due to the use of or a failure to be able to use this equipment.
Page 4 Notes On Export Management This product and its manuals may require an Export License/Approval by the Government of the product's country of origin for re-export from your country. Before re-exporting the product or manuals, please contact us to confirm whether they are export-controlled items or not. When you dispose of export-controlled items, the products/manuals need to be broken/shredded so as not to be unlawfully used for military purpose.
Page 5 Anritsu electronic equipment). By reading this EULA and using this software, you are agreeing to be bound by the terms of its contents and Anritsu Corporation (hereafter Anritsu) hereby grants you the right to use this Software with the Anritsu-specified equipment (hereafter Equipment) for the purposes set out in this EULA.
Page 6 Commerce Denied Persons List or Entity otherwise, due to your violation of the terms List. By using this Software, you warrant of this EULA, Anritsu shall have the right to that you are not located in any such country seek proportional damages from you.
Page 7 Cautions against computer virus infection ● Copying files and data Only files that have been provided directly from Anritsu or generated using Anritsu equipment should be copied to the instrument. All other required files should be transferred by means of USB or CompactFlash media after undergoing a thorough virus check.
Page 8 CE Conformity Marking Anritsu affixes the CE conformity marking on the following product(s) in accordance with the Council Directive 93/68/EEC to indicate that they conform to the EMC and LVD directive of the European Union (EU). CE marking 1. Product Model...
Page 9 C-Tick Conformity Marking Anritsu affixes the C-Tick mark on the following product(s) in accordance with the regulation to indicate that they conform to the EMC framework of Australia/New Zealand. C-Tick marking 1. Product Model Software: MX269017A Vector Modulation Analysis Software 2.
Page 11: About This Manual
About This Manual  Composition of Operation Manuals The operation manuals for the MX269017A Vector Modulation Analysis Software are comprised as shown in the figure below. MS2690A/MS2691A/MS2692A MS2830A Signal Analyzer Operation Signal Analyzer Operation Manual Manual (Main Frame Operation) (Main Frame Operation)
Page 12  Signal Analyzer Operation Manual (Mainframe Operation)  Signal Analyzer Operation Manual (Mainframe Remote Control) These manuals describe basic operating methods, maintenance procedures, common functions, and common remote control of the signal analyzer mainframe.  Forward Link Measurement Software Operation Manual (Operation) <This document>...
Page 13: Table Of Contents
Table of Contents About This Manual........Chapter 1 Overview ........Product Overview ............1-2 Product Configuration ..........1-3 Specifications ............. 1-4 Chapter 2 Before Use ......... Part Names ..............2-2 Signal Path Setup ............2-11 Application Startup and Selection ......2-12 Initialization and Calibration ........
Page 14 Chapter 4 Digitize Function ....... Saving IQ Data............4-2 Replay Function ............4-7 Chapter 5 Performance Test ..... Overview of Performance Test ........5-2 Performance Test Items ..........5-7 Chapter 6 Other Functions ......Selecting Other Functions ......... 6-2 Setting Title ..............6-2 Erasing Warmup Message ........
Page 15: Chapter 1 Overview
Chapter 1 Overview This chapter provides an overview of the MX269017A Vector Modulation Analysis Software and describes the product configuration. Product Overview ............1-2 Product Configuration ..........1-3 1.2.1 Standard configuration ........1-3 1.2.2 Applicable parts ..........1-3 Specifications ............. 1-4...
Page 16: Product Overview
"this application") is a software option for performing modulation analysis of modulated signals. The MX269017A provides the following measurement features. • Modulation accuracy measurement • Carrier frequency measurement • Transmitter power measurement “MS2830A-006/106” or “MS2830A-005/105/007/009 and MS2830A-006/106” is required to use the MX269017A on MS2830A.
Page 17: Product Configuration
Product Configuration 1.2 Product Configuration 1.2.1 Standard configuration Table 1.2.1-1 lists the standard configuration of the MX269017A. Table 1.2.1-1 Standard configuration Model Item Product Name Q’ty Remarks Name/Symbol Vector Modulation Analysis Application MX269017A Software Application software, Accessory ― Installation CD-ROM operation manual CD-ROM 1.2.2 Applicable parts...
Page 18: Specifications
Chapter 1 Overview 1.3 Specifications Table 1.3-1 shows the specifications for the MX269017A. When MS2830A is used, this software’s specification is specified by the condition below, unless otherwise noted. Attenuator Mode: Mechanical Atten Only Table 1.3-1 Specifications Item Specification Common Specifications...
Page 19 Specifications Table 1.3-1 Specifications (Cont’d) Item Specification Common Specifications (Cont’d) Unit: symbol/sec Model Options 005/105 MS2830A 006/106 007/177 078/178 /007/009 Other than 004/078 MS269x the following 077/177 /178 options Modulation Lower Upper limit method limit BPSK Symbol rate setting range 140M QPSK /4DQPSK...
Page 20 Chapter 1 Overview Table 1.3-1 Specifications (Cont’d) Item Specification Modulation/Frequency Measurement Carrier frequency accuracy After CAL execution at 18 to 28°C，For a signal of EVM = 1% (BPSK, QPSK, 8PSK, 16QAM, 64QAM, 256QAM,  (accuracy of reference frequency  carrier frequency + 10 Hz) 2FSK, 4FSK) MS269x Series: After CAL execution at 18 to 28°C, For a signal of EVM = 1%...
Page 21 Specifications Table 1.3-1 Specifications (Cont’d) Item Specification Modulation/Frequency Measurement (Cont’d) After CAL execution at 18 to 28°C, according to the 10 MHz common reference*, when: Filter Type: Gaussian, BT=0.5, Symbol Rate 100 ksps, slot length 160 Symbol rate error symbol, The signal measured is within the measurement level range and less (2FSK, 4FSK) than or equal to Input Level, and...
Page 22 Chapter 1 Overview 1-8.
Page 23 Chapter 2 Preparation This chapter describes the preparations required for using the MS2690A/MS2691A/MS2692A application you are using. Refer to the Signal Analyzer Operation Manual (Mainframe Operation) MS2830A Signal Analyzer Operation Manual (Mainframe Operation) for common features not included in this manual. Part Names ..............
Page 24: Part Names
Chapter 2 Preparation 2.1 Part Names This section describes the panel keys for operating the instrument and connectors used to connect external devices. For general points of caution, MS2690A/MS2691A/MS2692A Signal Analyzer Operation refer to the Manual (Mainframe Operation) MS2830A Signal Analyzer Operation Manual (Mainframe Operation) 2.1.1 Front panel This section describes the front-panel keys and connectors.
Page 25 Part Names Power Switch Press to switch between the standby state (AC power supplied) and power-on state. The Power lamp lights orange at Standby and green at Power On. Press the power switch for about 2 seconds. Hard disk access lamp Lights when accessing the internal hard disk.
Page 26 Chapter 2 Preparation Local key Press to return to local operation from remote control via GPIB, Ethernet, or USB (B), and enable panel settings. Remote lamp Lights when in remote-control state. Preset key Resets parameters to initial settings. Function keys Selects or configures function menu displayed on the right of the screen.
Page 27 Part Names Main function keys 1 Press to set or execute main functions. Executable functions vary with the current application. When nothing happens with the press, it indicates that the application in use does not support the key. Press to set frequency parameters. Press to set level parameters.
Page 28 Chapter 2 Preparation Rotary knob/Cursor key/Enter key/Cancel key The rotary knob and cursor keys select display items or change settings. Press to set the entered or selected data. Press to cancel input or selected data. Shift key Operates keys with functions in blue characters on panel. Press the Shift key so the key lamp is green and then press the target key.
Page 29 Part Names RF Output connector (when Option 020 installed) Outputs RF signal, when the Vector Signal Generator option is installed. This is an N type output connector. This is not available when the Option 044/045 is installed. (Only for MS2830A) USB connector (type A) Connect the accessory USB keyboard, mouse or USB memory.
Page 30: Rear Panel
Chapter 2 Preparation 2.1.2 Rear panel This section describes the rear-panel connectors. 1 2 6 3 Figure 2.1.2-1 MS269x series rear panel Figure 2.1.2-2 MS2830A rear panel...
Page 31 Part Names Ref Input connector (reference frequency signal input connector) Inputs external reference frequency signal. It is for inputting reference frequency signals with higher accuracy than the instrument’s internal reference signal, or for synchronizing the frequency of the MS2690A/MS2691A/MS2692A or MS2830A to that of other equipment. The following frequencies are supported: MS269x series: 10 MHz/13 MHz MS2830A: 5 MHz/10 MHz/13 MHz...
Page 32 Chapter 2 Preparation Ethernet connector Connects PC or Ethernet network. USB connector (type A) Used to connect a USB keyboard or mouse or the USB memory supplied. Monitor Out connector Monitor Out Connects external display. AC inlet Supplies power. SA Trigger Input connector (MS2830A only) This is a BNC connector for inputting external trigger signal (TTL) for SPA and SA applications.
Page 33: Signal Path Setup
Signal Path Setup 2.2 Signal Path Setup As shown in Figure 2.2-1, connect the instrument and the DUT using an RF cable, so that the signal to be tested is input to the RF Input connector. To prevent an excessive level signal from being input, do not input the signal before setting the input level using this application.
Page 34: Application Startup And Selection
Chapter 2 Preparation 2.3 Application Startup and Selection To use this application, it is necessary to load (start up) and select the application. 2.3.1 Launching application The application startup procedure is described below. Note: The XXX indicates the application name currently in use. <Procedure>...
Page 35: Initialization And Calibration
Initialization and Calibration 2.4 Initialization and Calibration This section describes the parameter settings and the preparations required before starting measurement. 2.4.1 Initialization After selecting this application, first perform initialization. Initialization returns the settable parameters to their default value in order to clear the measurement status and measurement results.
Page 36 Chapter 2 Preparation 2-14.
Page 37: Chapter 3 Measurement
Chapter 3 Measurement This chapter describes the measurement function, the parameter contents and the setting methods for the MX269017A. Basic Operation ............3-2 3.1.1 Screen layout ............ 3-2 3.1.2 Main function menu .......... 3-4 3.1.3 Performing measurement ......... 3-5 Setting Frequency ............3-6 Setting Level ..............
Page 38: Basic Operation
Chapter 3 Measurement 3.1 Basic Operation Note: This application includes operations that are done using a mouse. 3.1.1 Screen layout This section describes the screen layout of the MX269017A. Figure 3.1.1-1 Screen Layout Measurement parameter Displays the specified parameter. Status message Displays signal status.
Page 39 Basic Operation Trace 1/ Trace 5 Trace 2/ Trace 6 Trace 3/ Trace 7 Trace 4/ Trace 8 Figure 3.1.1-2 Trace Window (4-Split Screen) Figure 3.1.1-3 Trace Window (one-trace screen)
Page 40: Main Function Menu
Chapter 3 Measurement 3.1.2 Main function menu This section describes the main function menu on the main screen. Figure 3.1.2-1 Main function menu Table 3.1.2-1 Main function menu Menu Display Function Sets frequency Frequency 3.2 Setting Frequency Sets level. Amplitude 3.3 Setting Level This sets common items.
Page 41: Performing Measurement
Basic Operation 3.1.3 Performing measurement There are two measurement modes: single and continuous. Measurement is performed once in the single measurement mode, and continuously in the continuous measurement mode. Single Measurement The selected measurement items are measured only for the measurement count (Storage Count) before measurement is stopped.
Page 42: Setting Frequency
Chapter 3 Measurement 3.2 Setting Frequency Press (Frequency) in the main function menu to display the Frequency function menu. Pressing displays the Frequency function menu and opens the Carrier Frequency dialog box. Carrier Frequency ■Summary Sets a carrier frequency. ■Setting range 100 kHz to upper limit depending on main unit Note that this may be limited according to parameters that are dependent on each other.
Page 43 Setting Frequency Table 3.2-2 Preselector Passthrough Low Frequency (MS2830A) Frequency Band Mode Preselector Passthrough Frequency Normal > 4.0 GHz ≥ 3.5 GHz Spurious This cannot be selected when Span is more than 50 MHz. (Normal is internally selected.) Micro Wave Preselector Bypass ■Summary Disables/enables the preselector bypass.
Page 44: Setting Level
Chapter 3 Measurement 3.3 Setting Level Press (Amplitude) in the main function menu to display the Amplitude function menu. Pressing displays the Amplitude function menu and opens the Input Level dialog box. Input Level ■Summary Sets the input level from the target DUT. ■Setting range When Pre Amp is On: (–80.00 + Offset Value) to (10.00 + Offset Value) dBm...
Page 45: Setting Common Items
Setting Common Items 3.4 Setting Common Items Press (Common Setting) on the main function menu to display the Common Setting Dialog. For the common item settings, set the parameters required for modulation wave measurement. For details about the settings while Replay function is being executed, refer to the following: 4.2.5 “Characteristics of Replayable IQ Data Files”...
Page 46 Chapter 3 Measurement Save/Recall button Saves/recalls the common setting parameters. 3.4.2 Parameter Save/Recall Preset Dialog Parameter button Recalls the preset parameters. 3.4.3 Preset Dialog Parameter Default button Changes the values specified for the common setting parameters to the defaults. 3.4.4 Default Parameter setting buttons Displays the dialog boxes for setting up the parameters.
Page 47 Setting Common Items Table 3.4.1-1 Description of Parameters Parameter Name General Information Displays the name of the parameter file whose Parameter File parameters have been recalled. Modulation Type Displays the modulation scheme. Symbol Rate Displays the symbol rate. Measurement Filter Shows the filter setting of the reception signal.
Page 48: Parameter Save/Recall
Chapter 3 Measurement 3.4.2 Parameter Save/Recall How to save parameters to or recall parameters from a file is described below. Parameter Save To display Save Parameter File dialog, do one of the followings:  Press the Save button in the Common Setting Dialog. ...
Page 49 Setting Common Items Recalling Parameter To display Recall Parameter File dialog, do one of the followings:  Press the Recall button in the Common Setting Dialog.  Select Recall Parameter File from the File menu. Figure 3.4.2-2 Common Setting Dialog (Recall Parameter) Specify the file to be recalled and then press Open to recall the common setting parameters from the file.
Page 50: Preset Dialog Parameter
Chapter 3 Measurement 3.4.3 Preset Dialog Parameter Recall the parameters corresponding to the various standards. Click the Preset Dialog Parameter button and select from the parameter sets (Predefined setting values) displayed. For the standards and parameter values, refer to Appendix C. Appendix C List of Predefined Setting Values 3.4.4 Default Change the values of the common setting parameters to the defaults.
Page 51: Measuring Object
Setting Common Items 3.4.5 Measuring Object Select the format of the signal to be measured. If the signal to be measured has a frame structure, which part of the signal to analyze can be specified by setting the frame structure parameters. ■Setting options Frame Formatted Select this tab if the measured signal has a frame structure.
Page 52: Modulation
Chapter 3 Measurement 3.4.6 Modulation Press the Modulation button in the Common Setting dialog box to display the modulation parameter setting dialog box. Figure 3.4.6-1 Modulation Parameter Setting Dialog Modulation Type ■Summary Select the modulation mode for the measured signal. ■Setting options BPSK Measures the signal as a BPSK-modulated...
Page 53 Setting Common Items 8PSK Measures the signal as an 8PSK-modulated signal. 16QAM Measures the signal as a 16QAM-modulated signal. 64QAM Measures the signal as a 64QAM-modulated signal. 256QAM Measures the signal as a 256QAM-modulated signal. (Available only for Non-Formatted) 2FSK Measures the signal as a 2-value FSK-modulated signal.
Page 54 Chapter 3 Measurement Mapping Edit ■Summary Mapping Edit is used to change the bit value in the symbol data column corresponding to that in the allocation column from the default setting. The setting is changed by recalling the file that specifies the bit value in the symbol data column corresponding to that in the allocation column.
Page 55 Setting Common Items Span Up ■Summary Defines the span width for the symbol rate when Modulation Type is other than 2FSK, 4FSK, H-CPM, O-QPSK. ■Setting range When selected: Wide span width When not selected: Narrow span width Span ■Summary This value is used in the measuring instrument. This value is calculated based on the Modulation Type and Symbol Rate.
Page 56 Chapter 3 Measurement Table 3.4.6-3 When Modulation Type is 2FSK/4FSK/H-CPM Span [Hz] Symbol Rate (SR) [sps] 0.1 k ≤ SR ≤ 0.25 k 0.25 k < SR ≤ 0.625 k 2.5 k 0.625 k < SR ≤ 1.25 k 1.25 k < SR ≤ 2.5 k 10 k 2.5 k <...
Page 57 Setting Common Items If the Span is more than 50 MHz, then the setting range of the carrier frequency shall be limited as follows: Table 3.4.6-5 Frequency range if the Span is more than 50 MHz Model Name Option Frequency Range MS2690A MS2691A 100 MHz...
Page 58: Filter
Chapter 3 Measurement 3.4.7 Filter Press the Filter button in the Common Setting dialog box to display the filter parameter setting dialog box. Figure 3.4.7-1 Filter Parameter Setting Dialog 3-22...
Page 59 Setting Common Items Measurement Filter ■Summary Sets the reception filter. The Filter Parameter Setting dialog shows the basic filter on the left and the 2nd filter on the right. Displayed characteristics are combined characteristics of 2 filters. ■Setting options Table 3.4.7-1 Setting Options of Measurement Filter Modulation Type Other than Filter Type...
Page 60 Chapter 3 Measurement Reference Filter ■Summary Sets the filter used for the reference signal. The Filter Parameter Setting dialog shows the filter on the left and the 2nd filter on the right. Displayed characteristics are combined characteristics of 2 filters. For details on Gaussian and Gaussian2 filter, refer to Appendix G “Filter Function”.
Page 61 Setting Common Items Roll Off / BT ■Summary This sets the filter roll off ratio (Root Nyquist/Nyquist/ARIB STD-T98) or bandwidth time product. This is applied when Measurement Filter or Reference Filter setting is set to Root Nyquist, Nyquist, ARIB STD-T98, Gaussian or Inverse Gaussian. ■Setting range 0.10 to 1.00 (Filter) 0.100 to 1.000 (2nd Filter)
Page 62 Chapter 3 Measurement Reference Edit ■Summary This selects the definition file for the user filter used as the Reference Filter. If no file is specified, the setting is the same as Nyquist. Measurement Filter Measurement filter is used to filter the received signal just before demodulation.
Page 63 Setting Common Items On Filter Settings and Measurement The signal received by the measuring instrument passes through the measurement filter. Next, the signal is demodulated and the bit string of the transmission signal is generated. A symbol data string is generated through symbol mapping from the generated bit string.
Page 64: Data
Chapter 3 Measurement 3.4.8 Data Set the interval for measurement. Press the Data button in the Common Setting dialog box to display the data parameter setting dialog box. Figure 3.4.8-1 Data Parameter Setting Dialog Measurement Interval ■Summary Sets the measurement interval in symbols. Measurement is performed for the symbol interval specified for Measurement Interval.
Page 65: Frame
Setting Common Items 3.4.9 Frame The frame parameters can be set when Frame Formatted has been selected for Measuring Object. Press the Frame button in the Common Setting dialog box to display the Frame parameter setting dialog box. Figure 3.4.9-1 Frame Parameter Setting Dialog Slots per Frame ■Summary Sets the number of slots in one frame.
Page 66: Slot
Chapter 3 Measurement 3.4.10 Slot The slot parameters can be set when Frame Formatted has been selected for Measuring Object. Press the Slot button in the Common Setting dialog box to display the slot parameter setting dialog box. Figure 3.4.10-1 Slot Parameter Setting Dialog Slot Length ■Summary Sets the number of symbols in one slot.
Page 67 Setting Common Items Measurement Interval ■Summary Sets the measurement interval in symbols. The symbol interval set in Measurement Interval is displayed as the measurement result. ■Setting range 10 to (Slot Length – Measurement Offset) ■Setting example When one slot includes 120 symbols and the measured interval is the 110-symbol interval starting at the third symbol.
Page 68: Search
Chapter 3 Measurement 3.4.11 Search Set the Search parameter that determines the symbol positions in the slot. The search parameters can be set when Frame Formatted has been selected for Measuring Object. Press the Search button in the Common Setting dialog box to display the search parameter setting dialog box.
Page 69 Setting Common Items Burst Search ■Summary Sets whether to detect burst signals. This setting is switched on or off by selecting a radio button. Set Burst Search to ON when a burst signal that makes up a ramp between slots is measured. Burst Search executes burst search using (Input Level ...
Page 70 Chapter 3 Measurement Sync Word Length ■Summary Sets the length of the sync word in Symbols. The length varies according to the Modulation Type setting and the character number of the input sync word (HEX). ■Setting range The value for the sync word length needs to satisfy the setting ranges of both Table 3.4.11-1 and Table 3.4.11-2.
Page 71 Setting Common Items Sync Word (HEX) ■Summary Sets the sync word. Specify the sync word as a left-aligned hexadecimal value, assuming the first bit in the sync word to be the MSB. ■Setting range Number of characters: (Sync Word Length) × (bits per symbol)/4, and round it up to the whole number.
Page 72: Detail Settings
Chapter 3 Measurement 3.4.12 Detail Settings To show Details Settings setting dialog, press Detail Settings in the Common Setting Dialog. Figure 3.4.12-1 Detail Settings parameter setting dialog (When Non-Formatted is selected and Modulation Type is other than 2FSK/4FSK/O-QPSK) The parameters (Adaptive, Convergence, and Filter Length) for Equalizer can be set when Non-Formatted has been selected and Modulation Type is other than 2FSK or 4FSK or O-QPSK.
Page 73 Setting Common Items Figure 3.4.12-2 Detail Settings parameter setting dialog (When Modulation Type is 2FSK/4FSK) Deviation Calculation The parameters for Deviation calculation can be set when Modulation Type is 2FSK or 4FSK. ■Summary This sets the timing to calculate Deviation when Modulation Type is 2FSK or 4FSK.
Page 74 Chapter 3 Measurement Figure 3.4.12-3 Detail Settings Parameter Setting Dialog Box (When Modulation Type is H-CPM) H-CPM Decode Method When H-CPM is selected as Modulation Type, the parameter for calculating ideal signal is available. ■Summary Sets decode method for calculating ideal signal when Modulation Type is H-CPM.
Page 75 Setting Common Items Figure 3.4.12-4 Detail Settings Parameter Setting Dialog Box (When Modulation Type is O-QPSK) Origin Offset Cancel When Modulation Type is set to O-QPSK, the parameters related to Origin Offset calibration can be set. ■Summary Sets the operation mode of Origin Offset Cancel. ■Options Calibrates Origin Offset.
Page 76: Set Parameters
Chapter 3 Measurement 3.4.13 Set Parameters Here you confirm the parameters set so far. To confirm the parameter change, press Set Parameters in the Common Setting Dialog. The Common Setting Dialog closes when Set Parameters is pressed. While the Common Setting dialog box is displayed, the setting of each parameter is not applied.
Page 77: Setting Measurement Items
Setting Measurement Items 3.5 Setting Measurement Items Pressing (Measure) on the main function menu or displays the Measure function menu. 3.5.1 Modulation Analysis Pressing (Modulation Analysis) on the Measure function menu displays the Modulation Analysis function menu. Figure 3.5.1-1 Modulation Analysis function menu Table 3.5.1-1 Modulation Analysis Function Menu Menu Display Function...
Page 78 Chapter 3 Measurement 3.5.1.1 Trace Pressing (Trace) on the Modulation Analysis function menu or displays the Trace function menu. Page 1 Page 2 Figure 3.5.1.1-1 Trace function menu Table 3.5.1.1-1 Trace function menu Menu Display Function Select Trace Sets the trace area to be manipulated. Sets the measurement result to be displayed in the Trace Mode trace area.
Page 79 Setting Measurement Items Select Trace ■Summary Sets the trace area to be manipulated. The trace area to be manipulated is enclosed in a green frame. ■Setting options Trace 1 to Trace 8 Trace Mode ■Summary Sets the measurement result to be displayed in the trace area to be manipulated.
Page 80 Chapter 3 Measurement Storage: Mode ■Summary Sets whether to update the data at every measurement or display the average value. ■Setting options Updates the data every time it measures. Average Displays average every time it measures. Average & Max Displays average and maximum value every time it measures.
Page 81 Setting Measurement Items Result Select ■Summary Switches measurement items to be displayed as numeric results when selecting Zoom Out. Other than 2FSK/4FSK/O-QPSK: Selects EVM or MER as measurement items to be displayed. 2FSK/4FSK: Selects FSK or Fidelity.* Selects either Linear or IQ to display the Constellation screen and Eye Diagram screen.
Page 82 Chapter 3 Measurement Specific Word Setting ■Summary Sets the position to analyze the specific word. ■Slot Number Sets the slot number to analyze the specific word. (0 to 19) ■Top Position Specifies the head position of the specific word in the slot to analyze.
Page 83 Setting Measurement Items 3.5.1.2 Re-measurement mode Pressing (Re-measurement mode) at the Modulation Analysis function menu sets the Re-measurement mode On and Off. When the Re-measurement mode is On, when the next measurement exceeds the threshold value, re-measurement is performed automatically once only.
Page 84: Power Vs Time Measurement (Power Vs Time)
Chapter 3 Measurement 3.5.2 Power vs Time Measurement (Power vs Time) This section describes how to set the Power vs Time measurement. 3.5.2.1 Setting Averaging Display Method (Storage Mode) This section describes how to set the averaging display method. ■Procedure Press Measure on the main function menu to display the Measure function menu.
Page 85 Setting Measurement Items 3.5.2.2 Setting Average Storage Count (Storage Count) This section describes how to set the average storage count. Note: This setting is only enabled when On is selected at Storage Mode. 3.5.2.1 Setting Averaging Display Method (Storage Mode) ■Procedure Press Measure on the main function menu to display the Measure function menu.
Page 86 Chapter 3 Measurement 3.5.2.3 Setting Averaging Calculation Method (Average Type) This section describes how to set the type of averaging calculation method. ■Procedure Press Measure on the main function menu to display the Measure function menu. Press Power vs Time to display the Power vs Time function menu. Press Trace to display the Trace function menu.
Page 87 Setting Measurement Items 3.5.2.4 Setting Measurement Results Type (Trace Mode) This section describes how to set the type of results displayed on the screen. ■Procedure Press Measure on the main function menu to display the Measure function menu. Press Power vs Time to display the Power vs Time function menu. Press Trace to display the Trace function menu.
Page 88 Chapter 3 Measurement 3.5.2.5 Setting Graph Vertical Axis Units (Unit) This section describes how to set the units of the graph vertical axis. ■Procedure Press Measure on the main function menu to display the Measure function menu. Press Power vs Time to display the Power vs Time function menu. Press Trace to display the Trace function menu.
Page 89 Setting Measurement Items 3.5.2.6 Setting Measurement Displayed on Graph (Display Item) This section describes how to set the type of measurement results displayed on the graph. ■Procedure Press Measure on the main function menu to display the Measure function menu. Press Power vs Time to display the Power vs Time function menu.
Page 90 Chapter 3 Measurement 3.5.2.7 Setting Slot (Slot) This section describes how to set a slot number for graph while Rise and Fall or Slot is selected in the Trace Mode. ■Procedure Press Measure on the main function menu to display the Measure function menu.
Page 91 Setting Measurement Items 3.5.2.8 Setting Upper Limit Line Segment Separator (Mask Setup-Upper Limit-Time Point/Segment) This section describes how to set the Upper Limit Line Segment separator. Note: Mask user settings are not initialized by Preset. ■Procedure Press Measure on the main function menu to display the Measure function menu.
Page 92 Chapter 3 Measurement Table 3.5.2.8-3 Relation of Symbol Rate Setting and k Symbol Rate 100 sps  Symbol Rate < 1 ksps 10 ms 1 ksps  Symbol Rate < 10 ksps 1 ms 10 ksps  Symbol Rate < 100 ksps 100 s 100 ksps ...
Page 93 Setting Measurement Items 3.5.2.9 Setting Upper Limit Line Upper Limit and Evaluation Standard (Mask Setup-Upper Limit-Limit Setup) This section describes how to set the upper limit and evaluation standard for the Upper Limit Line. Note: Mask user settings are not initialized by Preset. ■Procedure Press Measure on the main function menu to display the Measure function menu.
Page 94 Chapter 3 Measurement Table 3.5.2.9-3 Fail Logic Setting Options Settings Description Performs Pass/Fail evaluation using ABS Limit [dBm] setting Performs Pass/Fail judgment using REL Limit [dB] setting Judges as Pass if the evaluation is Pass either in ABS Limit ABS or REL (dBm) or in REL Limit (dB).
Page 95 Setting Measurement Items 3.5.2.10 Setting Lower Limit Line Segment Separator (Mask Setup-Lower Limit-Time Point/Segment) This section describes how to set the Lower Limit Line Segment separator. Note: Mask user settings are not initialized by Preset. ■Procedure Press Measure on the main function menu to display the Measure function menu.
Page 96 Chapter 3 Measurement 3.5.2.11 Setting Lower Limit Line Lower Limit and Evaluation Standard (Mask Setup-Lower Limit-Limit Setup) This section describes how to set the lower limit and evaluation standard for the Lower Limit Line. Note: Mask user settings are not initialized by Preset. ■Procedure Press Measure on the main function menu to display the Measure function menu.
Page 97 Setting Measurement Items Table 3.5.2.11-3 Fail Logic Setting Options Settings Description Performs Pass/Fail evaluation using ABS Limit [dBm] setting Conducts Pass/Fail judgment using the REL Limit [dB] setting. Judges as Pass if the evaluation is Pass either in ABS Limit ABS or REL (dBm) or in REL Limit (dB).
Page 98 Chapter 3 Measurement 3.5.2.12 Load Mask Setting-Standard Mask Table Change the mask setting by loading the mask for Preset. For the list of Preset with details, refer to Appendix F. Appendix F Mask for Power vs Time ■Procedure Press Measure on the main function menu to display the Measure function menu.
Page 99 Setting Measurement Items 3.5.2.13 Mask Evaluation This section shows an example of the limit line setting. How to set the upper limit lines as in Figure 3.5.2.13-1 is explained below. The setting values corresponding to Figure 3.5.2.13-1 are in Table 3.5.2.13-1. In this case, the lines actually used for judgment are shown in thick lines.
Page 100 Chapter 3 Measurement 3.5.2.14 Setting filter bandwidth (BW) The filter bandwidth used for Power vs Time measurement can be set. The bandwidth is defined by a 3-dB attenuation point. ■Procedure Press Measure on the main function menu to display the Measure function menu.
Page 101: Power Meter Measurement
Setting Measurement Items 3.5.3 Power Meter Measurement Start the application (Power Meter Function first. Select (Power Meter) in the Measure function menu to invoke the Power Meter function. Settings of Carrier Frequency, Offset, and Offset Value are automatically reflected on the corresponding parameters. When these parameters are being recalled, you cannot execute Recall Current Application in Section 3.6.2 “Recalling parameters”...
Page 102: Setting Markers
Chapter 3 Measurement 3.6 Setting Markers 3.6.1 Modulation Analysis Pressing (Marker) on the main function menu or displays the page 1 one of the Marker function menu. The marker setting and whether to display the marker change depending on the Trace Mode setting for the trace to be manipulated. 3.8 Trace Mode 3.6.2 Power vs Time This section describes how to set the parameters related to markers...
Page 103 Setting Markers 3.6.2.2 Setting Graph Marker Position (Point) This section describes how to set the positions of Marker 1 and Marker 2 in graph display. ■Procedure [Changing Marker 1 position] Press Marker on the main function menu to display the Marker function menu.
Page 104 Chapter 3 Measurement 3.6.2.3 Displaying the Modulation Analysis Area (Marker to Modana Area) The area that is currently under the modulation analysis is indicated by Marker 1 and Marker 2 in the graph.(Modana: Modulation Analysis) Marker 1 and Marker 2 indicate the points below. Marker 1: Measurement Offset [Symbol] Marker 2: Measurement Offset + Measurement Interval [Symbol] ■Procedure...
Page 105: Setting Trigger
Setting Trigger 3.7 Setting Trigger Pressing (Trigger) on the main function menu or displays the Trigger function menu. Trigger Switch ■Summary This sets the trigger synchronization On/Off. ■Setting options On, Off Trigger Source ■Summary This sets the trigger source. ■Setting options Video The Capture starts in synchronization with the rise or fall of the waveform.
Page 106 Chapter 3 Measurement Video Trigger Level ■Summary Sets the level threshold for detecting the slot. ■Setting options (–150 + Level Offset Value) to (+50 + Level Offset Value) dBm ■Resolution 1 dBm Wide IF Video Trigger Level ■Summary This sets the level threshold value for slot detection. ■Setting range (–60 + Level Offset Value) to (+50 + Level Offset Value) dBm ■Resolution...
Page 107: Trace Mode
Trace Mode 3.8 Trace Mode The Trace Mode setting specifies the type of the measurement result displayed on the Trace screen. 3.8.1 Modulation Analysis When the measurement item (Measure) is set to Modulation Analysis, selectable Trace Mode types are as in Table 3.8.1-1. Table 3.8.1-1 Trace Mode Type Trace Mode Function...
Page 108 Chapter 3 Measurement Table 3.8.1-2 Modulation Type and Result Display Modulation Type BPSK QPSK 16QAM 2FSK Trace Mode O-QPSK 64QAM 4FSK PI/4DQPSK 256QAM* H-CPM 8PSK 2ASK Constellation    EVM vs Symbol    Magnitude Error vs Symbol ...
Page 109 Trace Mode 3.8.1.1 Constellation Displays the Constellation analysis result in the trace area. The result of each such analysis is displayed, regardless of the storage mode. Figure 3.8.1.1-1 Constellation Result (Interpolation On) Graph display result ■Summary Displays the waveform in the analysis interval on the IQ axis. The IQ waveform is normalized and displayed with the vector of the outermost symbol position.
Page 110 Chapter 3 Measurement Scale: Interpolation ■Summary Sets the data interpolation between the symbols displayed on the graph and the display complementation. On the interpolation display, data is interpolated by using the number of splits between symbols specified in Points/Symbol and a graph is displayed with each data connected with straight lines.
Page 111 Trace Mode Marker Link ■Summary Selects whether to turn On or Off the synchronization of markers in separate traces. ■Setting options On, Off Result Select ■Summary Sets Constellation and Eye Diagram to display in frequency or in IQ. This can be set only when 2FSK or 4FSK is selected for Modulation.
Page 112 Chapter 3 Measurement 3.8.1.2 EVM vs Symbol Displays EVM vs Symbol analysis result in the Trace. The result of each such analysis is displayed, regardless of the storage mode. Figure 3.8.1.2-1 EVM vs Symbol Result Graph result display ■Summary Displays EVM of each symbol in the analysis interval as a percentage.
Page 113 Trace Mode Marker Number (EVM vs Symbol) ■Summary Sets the target of the marker on the EVM vs Symbol result display. ■Setting range (Measurement Offset) to (Measurement Interval – 1) 3.4.8 Data 3.4.10 Slot Marker Link ■Summary Selects whether to turn On or Off the synchronization of markers in separate traces.
Page 114 Chapter 3 Measurement 3.8.1.3 Magnitude Error vs Symbol Displays Magnitude Error vs Symbol analysis result in the Trace. The result of each such analysis is displayed, regardless of the storage mode. Figure 3.8.1.3-1 Magnitude Error vs Symbol Result Graph display result ■Summary Displays the amplitude error of each symbol in the analysis interval as a percentage.
Page 115 Trace Mode Marker ■Summary Selects marker function between On and Off. ■Setting options On, Off Marker Number (Magnitude Error vs Symbol) ■Summary Sets the marker target in the Magnitude Error vs Symbol result display. ■Setting range (Measurement Offset) to (Measurement Interval-1) 3.4.8 Data 3.4.10 Slot Marker Link...
Page 116 Chapter 3 Measurement 3.8.1.4 Phase Error vs Symbol Displays Phase Error vs Symbol analysis result in the Trace. The result of each such analysis is displayed, regardless of the storage mode. Figure 3.8.1.4-1 Phase Error vs Symbol Result Graph display result ■Summary Displays the phase error of each symbol in the analysis interval in degrees.
Page 117 Trace Mode Marker Number (Phase Error vs Symbol) ■Summary Sets the marker target in the Phase Error vs Symbol result display. ■Setting range (Measurement Offset) to (Measurement Interval – 1) 3.4.8 Data 3.4.10 Slot Marker Link ■Summary Selects whether to turn On or Off the synchronization of markers in separate traces.
Page 118 Chapter 3 Measurement 3.8.1.5 Frequency vs Symbol Displays Frequency vs Symbol analysis result in the trace area. The result of each such analysis is displayed, regardless of the storage mode. Figure 3.8.1.5-1 Frequency vs Symbol Result Graph display result ■Summary Displays the frequency deviation of each 1/8th of the symbol interval in the analysis interval in Hz units.
Page 119 Trace Mode Marker Number (Frequency vs Symbol) ■Summary Sets the marker target in the Frequency vs Symbol result display. ■Setting range (Measurement Offset) to (Measurement Interval – 1) 3.4.8 Data 3.4.10 Slot Marker Link ■Summary Selects whether to turn On or Off the synchronization of markers in separate traces.
Page 120 Chapter 3 Measurement 3.8.1.6 Trellis Displays the analysis result of the phase transition in the trace area. The result of each such analysis is displayed, regardless of the storage mode. Figure 3.8.1.6-1 Trellis Result Graph display result ■Summary Displays the phase transition for each 1/8th of the symbol in the analysis interval, in degrees.
Page 121 Trace Mode 3.8.1.7 Eye Diagram Displays the amplitude analysis result of the I phase and Q phase, in the trace area. The result of each such analysis is displayed, regardless of the storage mode. Figure 3.8.1.7-1 Eye Diagram Result Graph display result ■Summary Displays the normalized amplitude of the I phase and Q phase for each 1/8th of the symbol in the analysis interval.
Page 122 Chapter 3 Measurement Result Select ■Summary Sets Constellation and Eye Diagram to display in frequency or in IQ. This can be set only when 2FSK or 4FSK is selected for Modulation. ■Setting options Liner Displays Eye Diagram in frequency. Displays Eye Diagram in IQ. 3-86...
Page 123 Trace Mode 3.8.1.8 Numeric Displays the numeric result of modulation analysis in the trace area. According to the storage mode specified, the results in a single measurement are displayed for Off, the averages of the results in the specified number of measurements for Average, and the averages and the maximums of the results in the specified number of measurements for Average &...
Page 124 Chapter 3 Measurement Figure 3.8.1.8-3 Numeric Result (When Modulation Type is 2ASK) 3-88...
Page 125 Trace Mode Table 3.8.1.8-1 Measured Items Modulation Type 16QAM 2FSK Measured Items QPSK PI/4DPQSK BPSK 64QAM 4FSK 2ASK O-QPSK 8PSK 256QAM H-CPM Tx Power       Filtered Power       Frequency Error ...
Page 126 Chapter 3 Measurement *4: Only 2FSK, 4FSK and H-CPM *5: Only BER = On *6: Only 2ASK Scale ■Summary Toggles between [dBm] and [W] for the unit of measurement result. Select the Unit menu by pressing (Unit) at Scale menu, select Unit-Power menu by pressing (Power), and select either (dBm) or...
Page 127 Trace Mode Magnitude Error (rms) ■Summary Displays rms value of Magnitude Error. Magnitude Error (peak) ■Summary Displays the Magnitude Error Peak value and the number of the symbol for which the peak value was detected. FSK Error (rms) ■Summary Displays rms value of FSK Error. FSK Error (peak) ■Summary Displays the FSK Error Peak value and the number of the symbol...
Page 128 Chapter 3 Measurement Deviation ■Summary Displays the average value, peak value, and peak-to-peak value of the frequency deviation. Deviation rms (%) ■Summary Displays rms value of Deviation in %. Deviation at Ts/2 ■Summary Displays the average value, the maximum + frequency peak value, the minimum + frequency peak value, the maximum –...
Page 129 Trace Mode MER (peak) ■Summary Displays the MER peak value and the number of the symbol for which the peak value was detected. Offset EVM (rms) ■Summary Displays rms value of Offset EVM. Offset EVM (peak) ■Summary Displays the Offset EVM peak value and the number of the symbol for which the peak value was detected.
Page 130 Chapter 3 Measurement 3.8.1.9 I and Q vs Symbol Displays the amplitude analysis results of the I phase and the Q phase, in the trace area. The result of each such analysis is displayed, regardless of the storage mode. Figure 3.8.1.9-1 I and Q vs Symbol Result Graph display result ■Summary Displays the normalized amplitude of the I phase and Q phase for...
Page 131 Trace Mode Marker Number (I and Q vs Symbol) ■Summary Sets the marker target in the I and Q vs Symbol result display. ■Setting range (Measurement Offset) to (Measurement Interval – 1) 3.4.8 Data 3.4.10 Slot Marker Link ■Summary Selects whether to turn On or Off the synchronization of markers in separate traces.
Page 132 Chapter 3 Measurement 3.8.1.10 Magnitude vs Symbol Displays Magnitude vs Symbol analysis result in the Trace. The result of each such analysis is displayed, regardless of the storage mode. Figure 3.8.1.10-1 Magnitude vs Symbol Result Graph display result ■Summary Displays the amplitude for each 1/8th of the symbol in the analysis interval in volts.
Page 133 Trace Mode Marker Number (Magnitude vs Symbol) ■Summary Sets the marker target in the Magnitude vs Symbol result display. ■Setting range (Measurement Offset) to (Measurement Interval – 1) 3.4.8 Data 3.4.10 Slot Marker Link ■Summary Selects whether to turn On or Off the synchronization of markers in separate traces.
Page 134 Chapter 3 Measurement 3.8.1.11 Phase vs Symbol Displays the analysis result of Phase vs Symbol in the trace area. The result of each such analysis is displayed, regardless of the storage mode. Figure 3.8.1.11-1 Phase vs Symbol Result Graph display result ■Summary Displays the phase for each 1/8th of the symbol in the analysis interval, in degrees.
Page 135 Trace Mode 3.4.8 Data 3.4.10 Slot Marker Link ■Summary Selects whether to turn On or Off the synchronization of markers in separate traces. ■Setting options On, Off 3-99...
Page 136 Chapter 3 Measurement 3.8.1.12 Signal Monitor Displays the spectrum in the trace area. The result of each such analysis is displayed, regardless of the storage mode. Figure 3.8.1.12-1 Signal Monitor Result Graph display result ■Summary Displays the spectrum in the analysis interval. The range of the graph's horizontal axis is fixed to (Span/2) [Hz].
Page 137 Trace Mode 3.8.1.13 Symbol Table Displays the analysis result of Symbol Table in the trace area. The result of each such analysis is displayed, regardless of the storage mode setting. Figure 3.8.1.13-1 Symbol Table Result Graph display result ■Summary Displays the demodulation result for each symbol. Scale ■Summary Switches the measurement unit of numeric result between Binary...
Page 138 Chapter 3 Measurement 3.8.1.14 Equalizer Amplitude This function displays the Equalizer Amplitude analysis results at Trace. The analysis results are displayed each time irrespective of the Storage mode setting. The analysis results are displayed when either On or Hold is selected at the Adaptive setting of Equalizer.
Page 139 Trace Mode 3.8.1.15 Equalizer Phase This displays the Equalizer Phase analysis results at Trace. The analysis results are displayed each time irrespective of the Storage mode setting. The analysis results are displayed when either On or Hold is selected at the Adaptive setting of Equalizer.
Page 140 Chapter 3 Measurement 3.8.1.16 Equalizer Group Delay This displays the Equalizer Group Delay analysis results at Trace. The analysis results are displayed each time irrespective of the Storage mode setting. The analysis results are displayed when either On or Hold is selected at the Adaptive setting of Equalizer.
Page 141 Trace Mode 3.8.1.17 Equalizer Impulse Response This displays the Equalizer Impulse Response analysis results at Trace. The analysis results are displayed each time irrespective of the Storage mode setting. The analysis results are displayed when either On or Hold is selected at the Adaptive setting of Equalizer.
Page 142 Chapter 3 Measurement 3.8.1.18 FSK Error vs Symbol Displays FSK Error vs Symbol analysis result in the Trace. The result of each such analysis is displayed, regardless of the storage mode setting. Figure 3.8.1.18-1 FSK Error vs Symbol Result Graph display result ■Summary This displays the FSK Error for each symbol in the analysis segment in % units.
Page 143 Trace Mode Marker Number (FSK Error vs Symbol) ■Summary Sets the marker target in the FSK Error vs Symbol result display. ■Setting range (Measurement Offset) to (Measurement Interval – 1) 3.4.8 Data 3.4.10 Slot Marker Link ■Summary Selects whether to turn On or Off the synchronization of markers in separate traces.
Page 144 Chapter 3 Measurement 3.8.1.19 Fidelity vs Symbol Displays the analysis results of Modulation Fidelity vs Symbol in Trace. The results are displayed only when the modulation is set to 2FSK, 4FSK, or H-CPM. The result of each analysis is displayed, regardless of the storage mode setting.
Page 145 Trace Mode 3.8.1.20 Histogram Displays the appearance frequency of each symbol in Trace. The results are displayed only when the modulation is set to 2FSK, 4FSK, or H-CPM. Figure 3.8.1.20-1 Histogram Result Graph display result ■Summary Displays the frequency elements of each symbol. The horizontal axis represents normalized frequency and the vertical axis represents appearance frequency.
Page 146 Chapter 3 Measurement 3.8.1.21 Custom Numeric Displays the numeric result of modulation analysis in figures and bars in the trace area. The items to display can be selected from numeric result items arbitrarily. If the Storage Mode is set to Off, the analysis result of each measurement is displayed.
Page 147: Power Vs Time
Trace Mode 3.8.2 Power vs Time Displays the numeric result of power vs time in figures and bars in the trace area. The items to display can be selected from numeric result items arbitrarily. Table 3.8.2-1 Trace Mode Type Trace Mode Function Rise and Fall Displays Rise and Fall of Slot.
Page 148 Chapter 3 Measurement Slot ■Summary Displays the slot number. State ■Summary Displays On/Off state of the slot. Avg[dBm] ■Summary Displays the power after filtering of the slot. When the level offset is On, the level offset value is added. Judge ■Summary Displays the Template judgment result of the slot.
Page 149 Trace Mode Marker Display Results ■Summary Displays markers in the graph of Power vs Time. ■Summary Sets the position of each marker.(Marker1，Marker2) Symbol ■Summary Displays marker position information in symbols. Reference for position information is the starting point of the analysis interval.
Page 150 Chapter 3 Measurement 3.8.2.2 Slot Displays the analysis result of the slot in the trace area. Figure 3.8.2.2-1 Slot Result Numeric results See Section 3.8.2.1 “Rise and Fall”. Graph display result See Section 3.8.2.1 “Rise and Fall”. 3-114...
Page 151 Trace Mode 3.8.2.3 Frame Displays the analysis result of the frame in the trace area. Figure 3.8.2.3-1 Frame Result Numeric results See Section 3.8.2.1 “Rise and Fall”. Graph display result See Section 3.8.2.1 “Rise and Fall”. 3-115...
Page 152: Setting Capture
Chapter 3 Measurement 3.9 Setting Capture This section describes the settings of IQ data capture. Pressing (Capture) on the main function menu displays the Capture function menu. Note: The Capture function is unavailable for the Power vs Time measurement. Table 3.9-1 Capture Function Menu Menu display Function Selects Auto (default) or Manual for IQ data...
Page 153 Setting Capture 3.9.1 Setting capture time Sets the capture mode from Capture Time and the capture time length from Capture Time Length.  Auto This captures the required data at each measurement in accordance with the Common Setting Dialog settings. ...
Page 154: Setting Capture Interval
Chapter 3 Measurement 3.9.2 Setting capture interval Sets capture interval (frame number to capture) for one measurement. This setting is available only when Frame Formatted is selected for Measuring Object. It is set to “1 Frame” when No Formatted is selected. ■Summary Sets capture length of measurement data for analysis.
Page 155 Chapter 4 Digitize Function This chapter describes how to save IQ data to an external memory and replay the stored IQ data. The Digitize function is available only when Measure is set to Modulation Analysis. Saving IQ Data.............. 4-2 4.1.1 Format of data information file ......4-4 4.1.2 Format of data file ..........
Page 156: Chapter 4 Digitize Function
Chapter 4 Digitize Function 4.1 Saving IQ Data After pressing (Capture) on the Main function menu, press (Save Captured Data) to display the Save Captured Data function menu. Figure 4.1-1 Save Captured Data function menu Table 4.1-1 Save Captured Data function menu Menu Display Function Device...
Page 157 ”. The sequential number range is from 000 to 999. Files are saved to the following directory of the target drive specified using (Device). ¥Anritsu Corporation¥Signal Analyzer¥User Data¥Digitized Data¥Vector Modulation Analysis Up to 1000 files can be saved in a folder.
Page 158: Format Of Data Information File
Chapter 4 Digitize Function 4.1.1 Format of data information file The information on the saved IQ data is recorded in the data information file. Table 4.1.1-1 shows the details of the recorded parameters. Table 4.1.1-1 Format of data information file Item Descriptions Day/Month/Year of the captured data in...
Page 159 Saving IQ Data Table 4.1.1-1 Format of data information file (Cont’d) Item Descriptions Trigger source TriggerSource “External”: External trigger “SGMarker”: SG marker trigger Trigger level [dBm] Note that this value does not include the TriggerLevel reference level offset. It is in dBm units, even if the scale mode is Lin.
Page 160: Format Of Data File
Chapter 4 Digitize Function 4.1.2 Format of data file The data file is created in binary format. From the beginning of the file, I-phase data and Q-phase data are recorded by 4 bytes. The I-phase data and Q-phase data are recorded as a float type (IEEE real*4). Beginning of file I-phase data 1 (4Byte)
Page 161: Replay Function
Replay Function 4.2 Replay Function The Replay function enables the saved IQ data to be reanalyzed .After pressing (Capture) on the main function menu, press (Replay) to display the Replay function menu. Figure 4.2-1 Replay Function Menu Table 4.2-1 Replay Function Menu Menu Display Function Selects the drive in which the target file is...
Page 162: Starting Replay Function
Chapter 4 Digitize Function 4.2.1 Starting Replay Function Start the Replay function using the following procedure: <Procedure> Press (Capture) on the main function menu. Press (Replay) on the Capture function menu. Press (Device) on the Replay function menu and select the drive in which the target file is stored.
Page 163: Restriction During Replay Function Execution
Replay Function 4.2.3 Restriction During Replay Function Execution The functions shown in Table 4.2.3-1 are disabled when Replay is executed. Table 4.2.3-1 Functions Restricted During Replay Function Center Frequency Frequency Band Mode Input Level Pre Amp Storage Mode Storage Count Average Mode Trigger Switch Trigger Source...
Page 164: Tuning The Analysis Start Position During
Chapter 4 Digitize Function 4.2.4 Tuning the Analysis Start Position During Replay This section describes how to tune the analysis start position while the Replay function is being executed. <Procedure> Press (Capture) on the main function menu. Press (Analysis Offset Time) on the Capture function menu to display the Analysis Offset Time setting dialog box.
Page 165: Replayed
Table 4.2.5-1 IQ data file that can be replayed Name Value I, Q (32-bit Float Binary format) Format Only for IQ data saved with MX269017A. Sample numbers Dependent on the common setting value. Under certain condition, measurement may not be executed. Note the following.
Page 166: Stopping Replay
Chapter 4 Digitize Function 4.2.6 Stopping Replay Stop the Replay function using the following procedure: <Procedure> Press (Capture) on the main function menu. Press (Stop Replaying) to stop the Replay function. 4-12.
Page 167: Chapter 5 Performance Test
Chapter 5 Performance Test This chapter describes the measuring instruments, setup methods, and performance test procedures required for testing the performance of the MS2690A/MS2691A/MS2692A in which the MX269017A is installed. Overview of Performance Test ........5-2 5.1.1 Performance test ..........5-2 5.1.2 Performance test items and instruments used .
Page 168: Overview Of Performance Test
If items that do not meet the required level are detected during performance testing, contact an Anritsu Service and Sales office. Contact information can be found on the last page of the printed version of this manual, and is available in a separate file on the CD version.
Page 169: Setting Of Signal Used For Performance Test
Overview of Performance Test 5.1.3 Setting of signal used for performance test Use the MX370102A TDMA IQproducer to create signals used for performance testing. Eight types of signals are used for performance testing. Specify the settings described in the following table for the TDMA IQproducer to create waveform files for each signal.
Page 170 Chapter 5 Performance Test Table 5.1.3-3 Setting Parameters for Testsignal002 Signal Item Value Parameter setting sheet No Format Modulation Type 64QAM Symbol Rate 4 ksps Over Sampling Data Filter Root Nyquist Roll Off 1634 Package TDMA_IQproducer Pattern Name TestSignal002 Table 5.1.3-4 Setting Parameters for Testsignal003 Signal Item Value Parameter setting sheet...
Page 171 Overview of Performance Test Table 5.1.3-5 Setting Parameters for Testsignal004 Signal Item Value Parameter setting sheet No Format Modulation Type 64QAM Symbol Rate 500 ksps Over Sampling Data Filter Root Nyquist Roll Off 1634 Package TDMA_IQproducer Pattern Name TestSignal004 Table 5.1.3-6 Setting Parameters for Testsignal005 Signal Item Value Parameter setting sheet...
Page 172 Chapter 5 Performance Test Table 5.1.3-8 Setting Parameters for Testsignal007 Signal Item Value Parameter setting sheet No Format Modulation Type 256QAM Symbol Rate 5 Msps Over Sampling Data PN15 Filter Root Nyquist Roll Off 1634 Package TDMA_IQproducer Pattern Name TestSignal007 Table 5.1.3-9 Setting Parameters for Testsignal008 Signal Item Value...
Page 173 Overview of Performance Test Table 5.1.3-10 Setting Parameters for Testsignal009 Signal Item Value Parameter setting sheet No Format Modulation Type 2ASK Modulation Index Manchester Code Symbol Rate 1.024 Msps Over Sampling Data Filter Gaussian2 Roll Off 1634 Package TDMA_IQproducer Pattern Name TestSignal009...
Page 174: Performance Test Items
Chapter 5 Performance Test 5.2 Performance Test Items Warm up the device to be tested and the measuring instruments for at least 30 minutes except if specified otherwise, in order to stabilize them sufficiently before running performance tests. Maximum measurement accuracy requires, in addition to the above, conducting performance tests under ambient temperatures and with little AC power supply voltage fluctuations, as well as the absence of noise, vibrations, dust, humidity...
Page 175 Select the Modulation Analysis screen. Input the output signal from the MG3700A to the power meter and adjust this output level so that the power reading is 15 dBm 0.1 Input the output signal from the MG3700A to the MX269017A. Press to perform measurement.
Page 176 Chapter 5 Performance Test 11. Set as follows for the MS2690A/MS2691A/MS2692A.  Common Setting Measuring Object :Non-Formatted Modulation :64QAM Symbol Rate :4 ksps Measurement Filter :Root Nyquist+None Reference Filter :Nyquist+None Roll Off :1.0 :200 symbol Measurement Interval 12. Set the frequency of the MG3700A and MS2690A/MS2691A/MS2692A to 30 GHz, and repeat Steps 4 through 7.
Page 177 Performance Test Items 21. Set as follows for the MS2690A/MS2691A/MS2692A.  Common Setting Measuring Object :Non-Formatted Modulation :64QAM Symbol Rate :500 ksps Measurement Filter :Root Nyquist+None Reference Filter :Nyquist+None Roll Off :1.0 :4096 symbol Measurement Interval 22. Set the frequency of the MG3700A and MS2690A/MS2691A/ MS2692A to 30 GHz, and repeat Steps 4 through 7.
Page 178 Chapter 5 Performance Test 31. Set as follows for the MS2690A/MS2691A/MS2692A.  Common Setting Measuring Object :Non-Formatted Modulation :64QAM Symbol Rate :5 Msps Measurement Filter :Root Nyquist+None Reference Filter :Nyquist+None Roll Off :1.0 :4096 symbol Measurement Interval 32. Set the frequency of the MG3700A and MS2690A/MS2691A/ MS2692A to 30 GHz, and repeat Steps 4 through 7.
Page 179 Performance Test Items 41. Set as follows for the MS2690A/MS2691A/MS2692A.  Common Setting Measuring Object :Non-Formatted Modulation :4FSK Symbol Rate :2.4 ksps Measurement Filter :ARIB STD-T98+None Reference Filter :ARIB STD-T98+None Roll Off :0.20 :240 symbol Measurement Interval 42. Set the frequency of the MG3700A and MS2690A/MS2691A/MS2692A to 30 GHz, and repeat Steps 4 through 7.
Page 180 Chapter 5 Performance Test (5) Test results Table 5.2.1-1 Carrier frequency accuracy Modulation Symbol Min. Deviation Max. Uncer- Pass Signal Name Frequency Method Rate Value (Hz) Value tainty /Fail 30 MHz TestSignal /4DQPSK 4 ksps 2 GHz 6 GHz* 30 MHz TestSignal 2 GHz 64QAM...
Page 181: Testing Methods - Residual Vector Error
Performance Test Items 5.2.2 Testing Methods – Residual Vector Error (1) Test target standards  Residual EVM (2) Measuring instrument for tests  Vector signal generator: MG3700A + MX370102A  Power meter  3-dB attenuator (3) Setup MG3700A MS2690A/MS2691A/MS2692A 3-dB attenuator 3-dB attenuator Power Sensor Power Meter...
Page 182 Select the Modulation Analysis screen. Input the output signal from the MG3700A to the power meter and adjust this output level so that the power reading is 15 dBm 0.1 Input the output signal from the MG3700A to the MX269017A. Press to perform measurement.
Page 183 Performance Test Items 10. Set the MG3700A as follows:  Frequency : 49.996 MHz  Base Band Pattern (Memory A) : TestSignal002 Freq Offset : 4 kHz 11. Set the MS2690A/MS2691A/MS2692A as follows:  Center Frequency : 50.0 MHz  Common Setting Measuring Object :Non-Formatted...
Page 184 Chapter 5 Performance Test 21. Set the frequency of the MG3700A to 5999.5 MHz (MS269xA) or 3499.5 MHz (MS2830A), and repeat Steps 4 through 7. 22. Set the MG3700A as follows:  Frequency : 49.5 MHz  Base Band Pattern(Memory A) : TestSignal004 23.
Page 185 Performance Test Items 30. Set the MS2690A/MS2691A/MS2692A as follows:  Center Frequency : 50.0 MHz  Common Setting Measuring Object : Non-Formatted Modulation : PI/4DQPSK Symbol Rate : 5 Msps Measurement Filter :Root Nyquist+None Reference Filter : Nyquist+None Roll Off : 1.0 Measurement Interval: 4096 symbol 31.
Page 186 Chapter 5 Performance Test 40. Set the MS2690A/MS2691A/MS2692A as follows:  Center Frequency : 50.0 MHz  Common Setting Measuring Object : Non-Formatted Modulation : 256QAM Symbol Rate : 5 Msps Measurement Filter :Root Nyquist+None Reference Filter : Nyquist+None Roll Off : 1.0 Measurement Interval:4096 symbol Repeat steps 4 to 7.
Page 187 Performance Test Items Table 5.2.2-1 Residual Vector Error Measured Modulation Symbol Max. Uncer- Pass Value Signal Name Frequency Method Rate Value tainty /Fail [% (rms)] 50 MHz TestSignal /4DQPSK 4 ksps 500 MHz MS269xA 0.5% 50 MHz TestSignal 64QAM 4 ksps 500 MHz MS2830A 1.0%...
Page 188: Testing Methods - Symbol Rate Error
Chapter 5 Performance Test 5.2.3 Testing Methods - Symbol Rate Error (1) Test target standards  Symbol rate error (2) Measuring instrument for tests  Vector signal generator: MG3700A + MX370102A  Power meter  3-dB attenuator (3) Setup MS2690A/MS2691A/MS2692A MG3700A or MS2830A 10 MHz...
Page 189 Performance Test Items (4) Test Procedure Use the default values (value following preset execution) for parameters whose values are not indicated in the following procedure. <Procedure> Set the MG3700A as follows:  Frequency : 30.0 MHz : – 15 dBm ...
Page 190 Input the output signal from the MG3700A to the power meter and adjust this output level so that the power reading is –15 dBm + Correction value (–3.09 dB) ± 0.1 dB. Input the output signal from the MG3700A to the MX269017A. Press to perform measurement.
Page 191: Chapter 6 Other Functions
Chapter 6 Other Functions This chapter describes other functions of this application. Selecting Other Functions ......... 6-2 Setting Title ..............6-2 Erasing Warmup Message ........6-2...
Page 192: Selecting Other Functions
Chapter 6 Other Functions 6.1 Selecting Other Functions Pressing (Accessory) on the main function menu displays the Accessory function menu. Table 6.1-1 Accessory function menu Function Menu Display Function Keys Title Sets the title character string. Displays (On) or hides (Off) the title Title (On/Off) character string.
Page 193: Appendix A Default Value List
Appendix A Default Value List Frequency Carrier Frequency 1.000 GHz RF Spectrum Frequency Band Mode Normal (When MS2691A/MS2692A-003, MS2830A-041/043/044/045 is installed) Signal Level Too Low Display Micro Wave Preselector Bypass (When MS2692A-067/167 or MS2830A-007/067/167 is installed) Amplitude Input Level –10.00 dBm Pre-Amp Offset Offset Value...
Page 194 Appendix A Default Value List 2nd Word Search Disable 2nd Word Search Slot Slot 0 2nd Word Sync Word Length 1 symbol 2nd Word Sync Word 2nd Word Sync Word Offset 0 symbol Origin Offset Cancel Origin Offset Reference Offset Modulation Analysis Re-measurement mode Re-measurement Threshold...
Page 195 Appendix A Default Value List Result6 Result7 Symbol Rate Error Bar Graph Result1 Tx Power dBm –50 Unit Bar Graph Result2 Mod. Fidelity (rms) Unit Specific Word Setting Slot Number Top Position 1 bit Word Width 8 bit BER Setting Slot Number Trace ( Power vs Time ) Trace Mode...
Page 196 Appendix A Default Value List A-4.
Page 197: Appendix B Symbol Mapping
Appendix B Symbol Mapping The following lists the initial symbol data (symbol mapping) values that correspond to the symbol allocation values for each modulation method and describes the file specification method for changing the symbol mapping. B.1 Symbol Mapping Defaults ■...
Page 198 Appendix B Symbol Mapping ■ QPSK Figure B.1-2 QPSK Symbol Allocation Table B.1-2 QPSK Symbol data Allocation Symbol data...
Page 199 Appendix B Symbol Mapping ■ O-QPSK Figure B.1-3 O-QPSK Symbol Allocation Table B.1-3 O-QPSK Symbol data Allocation Symbol data...
Page 200 Appendix B Symbol Mapping ■  /4DQPSK Figure B.1-4  /4DQPSK Symbol Allocation Table B.1-4  /4QPSK Symbol data Differential Symbol data +/4 +3/4 –3/4 –/4...
Page 201 Appendix B Symbol Mapping ■ 8PSK Figure B.1-5 8PSK Symbol Allocation Table B.1-5 8PSK Symbol data Allocation Symbol data...
Page 202 Appendix B Symbol Mapping ■ 16QAM Figure B.1-6 16QAM Symbol Allocation Table B.1-6 16QAM Symbol data Symbol Allocation Symbol data Allocation data 0111 0010 0101 0000 1101 1000 1111 1010 0110 0011 0100 0001 1100 1001 1110 1011...
Page 203 Appendix B Symbol Mapping ■ 64QAM Figure B.1-7 64QAM Symbol Allocation Table B.1-7 64 QAM Symbol data Symbol Symbol Symbol Symbol Allocation Allocation Allocation Allocation data data data data 100010 100111 110111 110010 100000 100101 110101 110000 101000 101101 111101 111000 101010 101111...
Page 204 Appendix B Symbol Mapping ■ 2FSK Figure B.1-8 2FSK Symbol Allocation Table B.1-8 2FSK Symbol data Direction Symbol data –...
Page 205 Appendix B Symbol Mapping ■ 4FSK Figure B.1-9 4FSK Symbol Allocation Table B.1-9 4FSK Symbol data Direction Symbol data –1 –3...
Page 206 Appendix B Symbol Mapping ■ 2ASK Figure B.1-10 2ASK Symbol Allocation Table B.1-10 2ASK Symbol data Allocation Symbol data B-10...
Page 207 Appendix B Symbol Mapping B.2 Specifying Configuration File for Mapping Edit The following describes how to specify the configuration file used to edit the mapping with this application. Create this file in the text format. Any file name and extension can be specified.
Page 208 Appendix B Symbol Mapping Table B.2-1 Settings for Allocation and Symbol data Allocation Symbol data Allocation Symbol data 1000 1101 1010 1111 0010 0111 0000 0101 1001 1100 1011 1110 0011 0110 0001 0100 Specify the symbol 1000 data for allocation 0 1010 Specify the symbol on the first line.
Page 209 Appendix C Predefined Settings List The following Common Setting Parameter values are specified if the Preset Dialog Parameter function was used. Table C-1 Parameter setting list Parameter Table RCR39_PI4DQPSK_TCH_UL RCR39_PI4DQPSK_TCH_DL T61_SCPC_v1_0_SC T61_SCPC_v1_1_40ms_SC T61_SCPC_v1_1_20ms_SC T61_FDMA_PSC_UL T61_FDMA_PSC_DL T86_CCH_UL T86_CCH_DL T86_TCH_UL T86_TCH_DL T98_PI4DQPSK_SC T98_4FSK_SC BPSK-20kbps GFSK-100kbps...
Page 210 Appendix C Predefined Settings List Table C-1 Parameter setting list (Cont’d) Parameter Table P25_C4FM C-12 P25_CQPSK C-12 P25_LSM C-13 P25_WCQPSK C-13 P25_IB_Burst_STD_Type1 C-14 P25_IB_Burst_STD_Type2 C-14 P25_IB_LCH0_STD_Type1 C-15 P25_IB_LCH0_STD_Type2 C-15 P25_IB_LCH0_Symmetrical_Type1 C-16 P25_IB_LCH0_Symmetrical_Type2 C-16 P25_IB_LCH1_STD_Type1 C-17 P25_IB_LCH1_STD_Type2 C-17 P25_OB_STD C-18 P25_OB_STD_BER C-18 DMR_BS_sourced_Voice C-19...
Page 211: Appendix C Predefined Settings List
Appendix C Predefined Settings List Table C-2 Predefined Settings List RCR39_PI4DQPSK_TCH_UL RCR39_PI4DQPSK_TCH_DL Measuring Object Frame Formatted Frame Formatted Modulation Type PI/4DQPSK PI/4DQPSK Symbol Rate 16000 sps 16000 sps Span Up Measurement Filter Root Nyquist Root Nyquist 2nd Measurement Filter None None Reference Filter Nyquist...
Page 212 Appendix C Predefined Settings List Table C-3 Predefined Settings List T61_SCPC_v1_0_SC T61_SCPC_v1_1_40ms_SC Measuring Object Frame Formatted Frame Formatted Modulation Type PI/4DQPSK PI/4DQPSK Symbol Rate 4800 sps 4800 sps Span Up 1st Measurement Filter Root Nyquist Root Nyquist 2nd Measurement Filter None None 1st Reference Filter...
Page 213 Appendix C Predefined Settings List Table C-4 Predefined Settings List T61_SCPC_v1_1_20ms_SC T61_FDMA_PSC_UL Measuring Object Frame Formatted Frame Formatted Modulation Type PI/4DQPSK PI/4DQPSK Symbol Rate 4800 sps 4800 sps Span Up Measurement Filter Root Nyquist Root Nyquist 2nd Measurement Filter None None Reference Filter Nyquist...
Page 214 Appendix C Predefined Settings List Table C-5 Predefined Settings List T61_FDMA_PSC_DL T86_CCH_UL Measuring Object Frame Formatted Frame Formatted Modulation Type PI/4DQPSK 16QAM Symbol Rate 4800 sps 11250 sps Span Up Measurement Filter Root Nyquist Root Nyquist 2nd Measurement Filter None None Reference Filter Nyquist...
Page 215 Appendix C Predefined Settings List Table C-6 Predefined Settings List T86_CCH_DL T86_TCH_UL Measuring Object Frame Formatted Frame Formatted Modulation Type 16QAM 16QAM Symbol Rate 11250 sps 11250 sps Span Up Measurement Filter Root Nyquist Root Nyquist 2nd Measurement Filter None None Reference Filter Nyquist...
Page 216 Appendix C Predefined Settings List Table C-7 Predefined Settings List T86_TCH_DL T98_PI4DQPSK_SC Measuring Object Frame Formatted Frame Formatted Modulation Type 16QAM PI/4DQPSK Symbol Rate 11250 sps 4800 sps Span Up Measurement Filter Root Nyquist Root Nyquist 2nd Measurement Filter None None Reference Filter Nyquist...
Page 217 Appendix C Predefined Settings List Table C-8 Predefined Settings List T98_4FSK_SC BPSK-20kbps Measuring Object Frame Formatted Frame Formatted Modulation Type 4FSK BPSK Auto Deviation − − Symbol Rate 2400 sps 300 ksps Span Up Measurement Filter ARIB STD-T98 None 2nd Measurement Filter None None Reference Filter...
Page 218 Appendix C Predefined Settings List Table C-9 Predefined Settings List GFSK-100kbps Measuring Object Frame Formatted Modulation Type 2FSK Auto Deviation Modulation Index Symbol Rate 100 ksps Span Up Measurement Filter None 2nd Measurement Filter None Reference Filter Gaussian 2nd Reference Filter None Roll Off 0.50...
Page 219 Appendix C Predefined Settings List Table C-10 Predefined Settings List O-QPSK-250ksps O-QPSK-250ksps_2 Measuring Object Frame Formatted Frame Formatted Modulation Type O-QPSK O-QPSK Auto Deviation — — Modulation Index — — Symbol Rate 1 Msps 1 Msps Span Up Measurement Filter None None 2nd Measurement Filter...
Page 220 Appendix C Predefined Settings List Table C-11 Predefined Settings List T102_PART1 T102_PART2 Measuring Object Frame Formatted Frame Formatted Modulation Type 4FSK 4FSK Auto Deviation Modulation Index − − Symbol Rate 2.4 ksps 2.4 ksps Span Up Measurement Filter Root Nyquist ARIB STD-T98 2nd Measurement Filter Inverse Gaussian...
Page 221 Appendix C Predefined Settings List Table C-12 Predefined Settings List P25_C4FM P25_CQPSK Measuring Object Frame Formatted Frame Formatted Modulation Type 4FSK PI/4 DQPSK Auto Deviation − Modulation Index − − Symbol Rate 4.8 ksps 4.8 ksps Span Up Measurement Filter None None 2nd Measurement Filter...
Page 222 Appendix C Predefined Settings List Table C-13 Predefined Settings List P25_LSM P25_WCQPSK Measuring Object Frame Formatted Frame Formatted Modulation Type PI/4 DQPSK PI/4 DQPSK Auto Deviation − Modulation Index − − Symbol Rate 4.8 ksps 4.8 ksps Span Up Measurement Filter None None 2nd Measurement Filter...
Page 223 Appendix C Predefined Settings List Table C-14 Predefined Settings List P25_IB_Burst_STD_Type1 P25_IB_Burst_STD_Type2 Measuring Object Frame Formatted Frame Formatted Modulation Type H-CPM H-CPM Auto Deviation Modulation Index — — Maximum Frequency Deviation 3000 3000 Symbol Rate 6 ksps 6 ksps Span Up —...
Page 224 Appendix C Predefined Settings List Table C-15 Predefined Settings List P25_IB_LCH0_STD_Type1 P25_IB_LCH0_STD_Type2 Measuring Object Frame Formatted Frame Formatted Modulation Type H-CPM H-CPM Auto Deviation Modulation Index — — Maximum Frequency Deviation 3000 3000 Symbol Rate 6 ksps 6 ksps Span Up —...
Page 225 Appendix C Predefined Settings List Table C-16 Predefined Settings List P25_IB_LCH0_ P25_IB_LCH0_ Symmetrical_Type1 Symmetrical_Type2 Measuring Object Frame Formatted Frame Formatted Modulation Type H-CPM H-CPM Auto Deviation Modulation Index — — Maximum Frequency Deviation 3000 3000 Symbol Rate 6 ksps 6 ksps Span Up —...
Page 226 Appendix C Predefined Settings List Table C-17 Predefined Settings List P25_IB_LCH1_STD_Type1 P25_IB_LCH1_STD_Type2 Measuring Object Frame Formatted Frame Formatted Modulation Type H-CPM H-CPM Auto Deviation Modulation Index — — Maximum Frequency Deviation 3000 3000 Symbol Rate 6 ksps 6 ksps Span Up —...
Page 227 Appendix C Predefined Settings List Table C-18 Predefined Settings List P25_OB_STD P25_OB_STD_BER Measuring Object No Formatted Frame Formatted Modulation Type 4FSK 4FSK Auto Deviation Modulation Index — — Maximum Frequency Deviation 2250 2250 Symbol Rate 6 ksps 6 ksps Span Up —...
Page 228 Appendix C Predefined Settings List Table C-19 Predefined Settings List DMR_BSsourced_Voice DMR_BSsourced_Data Measuring Object Frame Formatted Frame Formatted Modulation Type 4FSK 4FSK Auto Deviation Modulation Index − − Symbol Rate 4.8 ksps 4.8 ksps Span Up Measurement Filter Root Nyquist Root Nyquist 2nd Measurement Filter None...
Page 229 Appendix C Predefined Settings List Table C-20 Predefined Settings List DMR_MSsourced_Voice DMR_MSsourced_Data Measuring Object Frame Formatted Frame Formatted Modulation Type 4FSK 4FSK Auto Deviation Modulation Index − − Symbol Rate 4.8 ksps 4.8 ksps Span Up Measurement Filter Root Nyquist Root Nyquist 2nd Measurement Filter None...
Page 230 Appendix C Predefined Settings List Table C-21 Predefined Settings List DMR_MSsourced_RC NXDN_2_4ksps Measuring Object Frame Formatted Frame Formatted Modulation Type 4FSK 4FSK Auto Deviation Modulation Index − — Symbol Rate 4.8 ksps 2.4 ksps Span Up Measurement Filter Root Nyquist Root Nyquist 2nd Measurement Filter None...
Page 231 Appendix C Predefined Settings List Table C-22 Predefined Settings List NXDN_4_8ksps Measuring Object Frame Formatted Modulation Type 4FSK Auto Deviation Modulation Index − Symbol Rate 4.8 ksps Span Up Measurement Filter Root Nyquist 2nd Measurement Filter Inverse Rect Reference Filter Nyquist 2nd Reference Filter None...
Page 232 Appendix C Predefined Settings List C-24.
Page 233: Appendix D User Defined Filter
Appendix D User Defined Filter This section explains the User Defined Filter definition and the filter definition file description method. D.1 User Defined Filter Definition The User Defined Filter is defined as shown below. • There must be a FIR filter coefficient string expressing the 8 times oversampling time response (as real number) for the symbol rate.
Page 234 Appendix D User Defined Filter Example: Definition file description for 9 tap FIR filter When the filter coefficient string is set as shown in Table D.2-1, the setting file is described as shown in Table D.2-1. Table D.2-1 9 Tap FIR Filter Coefficient String Filter Filter Allocation...
Page 235: Appendix E Ber Pattern
Appendix E BER Pattern This appendix explains the test patterns prepared for BER pattern in BER setting. Test Patterns for APCO Project25 Phase1 The BER patterns in Table E-1 are test patterns defined by TIA-102.CAAA-C. (Except P25_PN9) Table E-1 BER Pattern Pattern name Description P25_Tone...
Page 236 Appendix E BER Pattern Test Patterns for APCO Project25 Phase2 The BER patterns in Table E-2 are test patterns defined by TIA-102.CCAA. Table E-2 BER Pattern Pattern name Description P25_Phase2_STTP-OB1031_Frame0 Outbound Standard Tone Test Pattern Super Frame 1 P25_Phase2_STTP-OB1031_Frame1 Outbound Standard Tone Test Pattern Super Frame 2 P25_Phase2_STTP-OB1031_Frame2 Outbound Standard Tone Test Pattern...
Page 237: Appendix F Mask For Power Vs Time
Appendix F Mask for Power vs Time This appendix explains the mask setting for Power vs Time prepared as Preset setting. Mask Setting for DMR The mask settings for DMR in Table F-1 comply with ETSI TS 102 361-1(V2.1.1 (2012-04). For details of setting values, refer to Table F-2 and F-3.
Page 238 Appendix F Mask for Power vs Time Table F-3 DMR_RC_burst Time Fail Logic [ms] [ms] [dBm] Rise Upper –2.61 –99.99 –57.00 –2.61 –99.99 –57.00 ABS or REL –2.61 4.00 –57.00 –0.10 4.00 –0.10 1.00 Fall Upper 0.11 1.00 0.11 4.00 2.60 4.00 –57.00...
Page 239 Appendix F Mask for Power vs Time Mask Setting for P25 Phase2 The mask settings for APCO-P25 Phase2 in Table F-4 comply with TIA-102.CCAA and TIA-102.CCAB. For details of setting values, refer to Table F-5 and F-6. Table F-4 Mask Setting for P25 Phase2 Mask name Description Setting...
Page 240 Appendix F Mask for Power vs Time Table F-6 P25_Phase2_IB_Burst_MeasInt168 Time Fail Logic [ms] [ms] [dBm] Rise Upper –1.28 –99.99 –57.00 ABS or REL –1.28 4.00 –57.00 –0.09 4.00 –0.09 1.00 Fall Upper 0.09 1.00 0.09 4.00 1.28 4.00 –57.00 ABS or REL 1.28 –99.99...
Page 241: Appendix G Filter Function
Appendix G Filter Function This section describes the filter function. G.1 Gaussian/Gaussian2 Filter The impulse response is expressed as the formula below when the filter is set to Gaussian.            ...
Page 242 Appendix G Filter Function The following figure shows the comparison of amplitude characteristics between the filter types (Gaussian and Gaussian2). (Horizontal axis: Frequency normalized to the symbol rate, BT = 0.5, Over Sampling = 8) In comparison with Gaussian2, Gaussian has the narrower passband, and its amplitude becomes 0 at an integer multiples of the Symbol Rate frequency, due to the influence of rect(t/T).
Page 243: Index
Index References are to page numbers. Symbol and Numbers Common Setting Dialog ....... 3-9 Continuous Measurement ......3-5 1st Local Output connector ......2-7 Convergence ..........3-36 1st Word / 2nd Word ........3-33 Copy key ............2-3 Count ............3-43 Cursor key .............
Page 244 Index Frame Formatted ........3-15 Frequency ............. 3-6 Magnitude Error Frequency Band Mode ......... 3-6 peak ............3-91 Frequency Error ......... 3-90 rms ............3-91 Front panel ........... 2-2 Magnitude Error vs Symbol ....... 3-78 FSK Error Magnitude vs Symbol ......... 3-96 peak ............
Page 245 Index Reference Filter ........ 3-24, 3-26 reference frequency signal ......2-9 Next Trace ........... 3-44 Re-measurement mode ....... 3-47 Next View ............ 3-44 Remote lamp ..........2-4 Non-Formatted ........... 3-15 Replay ............3-116 Numeric ............3-87 Result Select ..........3-45 Numeric keypad ...........
Page 246 Index specifications ..........1-4 standard configuration ......... 1-3 Video Trigger Level ........3-70 Status message ..........3-2 Stop Replaying ..........3-116 Wide IF Video Trigger Level ...... 3-70 Storage ............3-43 Count ............3-44 Zoom In/Zoom Out ........3-44 Mode ............3-44 Storage Count ..........
