INTRODUCTION
OH
This service manual describes the lat�st information for the
IC-271 at the time of publication.
VERSION NO.
MODEL
#02
#03
IC-2710H
#05
#07
#08
ORDERING PARTS
Be sure to include the following four points when ordering
replacement parts:
1. 10-digit order numbers
2. Component part number and name
3. Equipment model name and unit name
4. Quantity required
<SAMPLE O RDE R>
1180001070 S.IC TA7805F
88 10009140 Screw PH M2.6 6
x
Addresses are provided on the inside back cover for your
convenience.
VERSION
SYMBOL
Europe EUR
Italy ITA
U.S.A. USA
Australia AUS
Asia SEA
ZK
IC-2710H MAIN UNIT 1 piece
IC-2710H Bottom cover 6 pieces
DANGER
N EVE R connect the transceiver to an AC outlet or to a DC
power supply that uses more than 16 V. Such a connection
could cause a fire hazard and/or electric shock.
DO NOT expose the transceiver to rain, snow or any liq­
uids.
DO NOT reverse the polarities of the power supply when
connecting the transceiver.
DO NOT apply an RF signal of more than 20 dBm (100
mW) to the antenna connector. This could damage the
transceiver's front end.
REPAIR NOTES
1. Make sure a problem is internal before disassembling
the transceiver.
2. DO N OT open the transceiver until the transceiver is
disconnected from its power source.
3. DO NOT force any of the variable components. Turn
them slowly and smoothly.
4. DO NOT short any circuits or electronic parts. An insu­
5. ON
lated tuning tool MUST be used for all adjustments.
DO N O T keep power
transceiver is defective.
6. DO N OT transmit power into a signal generator or a
sweep generator.
7. ALWAYS connect a 50 dB or more attenuator between
the transceiver and a deviation meter or spectrum ana­
lyzer when using such test equipment.
8. R EAD the instructions of test equip ment thoroughly
before connecting equipment to the transceiver.
for a long time when the
