TC-Helicon VoiceTone T1 User Manual page 5

6
5
4
3
2
1
7 8 9
11
1 - Effect on/off footswitch
2 - Effect active LED indicator
3 - Dynamics amount control
10
4 - Adaptive Shape EQ amount control
5 - MIC GAIN control for input level
6 - Balanced XLR mic input
12
7 - Balanced XLR mono output
8 - Power in
9 - USB connector to computer
10 - Input level LED; green=signal, red=clip
11 - Effect on/off via optional mic (MP-75): in=on
12 - Warmth adds bass EQ
