Page 5: Table Of Contents
Content Introduction ..................5 Safety and general information ..............6 Installation requirements ................. 7 Builders opening................7 Flue requirements................7 Instruction for Installation ................ 9 Gas connection ................9 Preparing the appliance..............9 Placing the appliance................ 9 Building the surround............... 10 Placing the log set ................ -
Page 6: Introduction
1 Introduction Note: these instructions should be read carefully and retained for future reference. Please leave these instructions with the user. Special features: • Realistic flame pattern by use of the patented Log burner technology • Room sealed appliance, inlet and outlet are led to the outside using a natural draught concentric pipe system (100 mm/150 mm) (no power fan required) •... -
Page 7: Safety And General Information
2 Safety and general information Before installation, ensure that the local distribution conditions (identification of the type of gas and pressure) and the adjustment of the appliance are compatible. This gas appliance is factory set and can not be adjusted. This appliance does not contain any component manufactured from asbestos or any asbestos related products. -
Page 8: Installation Requirements
• always ventilate the space above the appliance. Use a Faber ventilation grid • to avoid cracking, the plaster has to dry for at least 1 day per millimetre plaster •... - Page 9 4. elbows and bends at the transition of horizontal to vertically are not to be counted 5. the wall mounted terminal counts for 1 meter 3.2.1 Terminal position Verify if the required terminal position meets the local installation regulations regarding disturbance, good functioning and ventilation: The terminal must be located so that the outlet is not obstructed.
-
Page 10: Instruction For Installation
4 Instruction for Installation Gas connection Pipe work from the meter to the appliance must be of adequate size. The complete installation including the meter must be tested for soundness. A means of isolation must be provide in the supply to facilitate servicing. Ensure that the gas pipe does not interfere with the removal or replacement of the burner tray or of the controls. -
Page 11: Building The Surround
Building the surround The figures shown are indicative for one possibility. There is a lot of freedom to build a surround around the honest. However always keep in mind: • Upside of opening has to be equal with the opening of the appliance (see figure 1.5) •... -
Page 12: Commissioning (Functional Checks)
5 Commissioning (functional checks) Pilot ignition check • Ignite the pilot light as described in the user manual • Check if the pilot burner stays alight • Extinguish the pilot burner Check functional burner and pilot burner The appliance is preset to give the correct heat input. No further adjustment is necessary. Always check the inlet pressure and burner pressure: •... -
Page 13: Handing Over (Final Check And Customer Briefing)
6 Handing over (final check and customer briefing) • Instruct the customer on the full operation of the appliance and the remote control, including replacement of batteries • Advise the customer how to clean the appliance including the glass • Hand over these instructions including the user guide to the consumer •... - Page 14 Attention: Before placing the glass: check the glass sealing rope is in good condition and makes an effective seal. Be sure that there are no fingerprints on the glass. It is not possible to remove those prints after you burn the appliance for a while (they are burnt in). Place the glass in front of the appliance and fix the glass frame or use the glass clamps.
-
Page 15: Appendix A: Example Calculation
Appendix A: Example calculation Calculation 1: Calculating horizontal extension fig. 2a: Flue length C + E = 1m + 1m Elbows D = 2m Total horizontal extension Measure or calculate effective height (Hvert) Flue length A Roof mounted terminal Total effective height According to the table in Appendix B is this situation allowed without a flue restrictor. -
Page 16: Appendix B: Flue Restrictor
Determine according to the table the right flue restrictor size • When meeting an X, and when the values are outside the table, the combination is not allowed • Normally the 30 mm flue restrictor is preinstalled Horizontal length (m) Honest 15 < < < <... -
Page 17: Appendix C: Installation Of The Flue
Appendix C: Installation of the flue Connection with use of concentric duct material Make a hole of ø 153 mm for the wall or roof mounted terminal. The horizontal pipes need to rise away from the appliance at a rate of 3 degrees per metre Build the system starting from the appliance on. -
Page 18: Appendix E: Technical Specifications
Appendix E: Technical specifications Country Gas type Towngas 2 Appliance type C11/ C31 Reference gas G150.1 Input (nett) Efficiency class Inlet pressure mbar Gasrate 1080 (Bij 15º C en 1013 mbar) gram/h Working pressure (high) mbar Injector size (3x) 4mm Reduced input restr 2,5 mm Pilot assembly... -
Page 19: Appendix F: Dimensions
Appendix F: Dimensions > > > >... -
Page 20: Appendix G: Ventilation Grid
Appendix G: Ventilation Grid 19 < < < <... -
Page 21: Appendix H : Service Hatch
Appendix H : Service Hatch > > > >... - Page 23 > > > >...
