- Page 1 INSTRUCTION MANUAL Cordless Vacuum Cleaner VC002GL VC004GL Read before use.
-
Page 2: Specifications
Do not short the battery cartridge. • See the chapter “MAINTENANCE” for the appropriate details of precautions during user maintenance. SPECIFICATIONS Model: VC002GL VC004GL Standard filter type Powder filter (for dry dust) Maximum air volume (with BL4040, ø38 mm x 2.5 m hose) 2.7 m... -
Page 3: Safety Warnings
The vibration total value (tri-axial vector sum) deter- and electronic equipment, accumulators mined according to EN60335-2-69: and batteries may have a negative impact on the environment and human health. Model VC002GL Do not dispose of electrical and electronic Vibration emission (a ) : 2.5 m/s or less appliances or batteries with household Uncertainty (K) : 1.5 m/s... - Page 4 Do not attempt to pick up flammable materials, 22. The machine should be technically inspected fire works, lighted cigarettes, hot ashes, hot by the manufacturer, or an instructed person, metal chips, sharp materials such as razors, at least annually, consisting of, for example, needles, broken glass or the like.
- Page 5 It will nails, coins, etc. also void the Makita warranty for the Makita tool and charger. Do not expose battery cartridge to water or rain.
-
Page 6: Parts Description
If accidentally swallowed, seek medical supplied case or a static-free container. attention immediately. 26. Do not insert any devices other than Makita Use the wireless unit only with Makita tools. wireless unit into the slot on the tool. Do not expose the wireless unit to rain or wet 27. -
Page 7: Functional Description
With a single battery FUNCTIONAL Only one battery is required as a power source in either DESCRIPTION the left or right battery slot. The cleaner automatically determines which battery slot is available according to operating conditions. CAUTION: Always be sure that the appliance Installation and uninstallation is switched off and the battery cartridges are To install battery cartridges, release the lock first,... - Page 8 Indicating the remaining battery Battery indicators on control panel capacity The remaining battery capacity can be read on the control panel at any time. Press the check button, and Press the check button on the battery cartridge to indi- the left and right indicators will show the battery charge cate the remaining battery capacity.
- Page 9 Fig.9 Let the appliance and battery(ies) cool down. ► 1. Caster 2. Stopper lever 3. Unlocked position If no improvement can be found by restoring protection 4. Locked position system, then contact your local Makita Service Center. 9 ENGLISH...
- Page 10 Mount the head unit over the tank and secure NOTE: When moving the cleaner, make sure that the them with the locking latches. caster is unlocked. Moving the cleaner with the caster in a locked position may cause damage to the caster. Carriage handle CAUTION: Lift and carry the appliance with...
- Page 11 Install the paper pack into the tank with its card- Spread the other top edges of the bag outwards over board opening hooked on the paper pack holder. the top rims of the tank. Place the prefilter over the poly- ethylene bag to fasten the opening of the bag securely.
- Page 12 Installing MAKPAC adapter NOTE: Take the polyethylene bag out of the tank carefully to avoid it from being scratched and torn by the edges inside the tank. Optional accessory NOTE: Empty the polyethylene bag before it Connectable and stackable MAKPAC storage cases becomes full.
- Page 13 Lift the push bar up and tighten the knob to prepare Connections with your work tools installing the MAKPAC cases onto the cleaner. (Country specific) By connecting the vacuum cleaner to any available work tools compatible with the cleaner, it works as a dust extractor for your power tools.
- Page 14 Attachments with lock function Adjusting lengths of slide-type extension wand Optional accessory NOTICE: When installing the attachment with Optional accessory lock function, be sure to align the release button A slide-type extension wand can be combined for with the hook on the attachment. If they are not shorter and longer lengths.
- Page 15 Fig.28 object with a sharp edge. ► 1. Lid NOTE: Wireless activation needs Makita tools Insert the wireless unit to the slot and then close the lid. equipped with the wireless unit. When inserting the wireless unit, align the projections NOTE: Prior to the initial use of the wireless activa- with the recessed portions on the slot.
- Page 16 Tool registration for the cleaner NOTE: A Makita tool supporting the wireless activa- tion function is required for the tool registration. NOTE: Finish installing the wireless unit to the tool before starting the tool registration.
- Page 17 Connect the hose of the cleaner with the tool. To stop the wireless activation, push the wireless activa- tion button on the tool, or set the stand-by switch on the cleaner to "I" or "O". NOTE: The wireless activation lamp on the tool will stop blinking in blue when there is no operation for 2 hours.
- Page 18 Press the wireless activation button on the cleaner Erasing all tool registrations for 6 seconds. The wireless activation lamp blinks in green and then become red. After that, press the wire- You can erase all tool registrations from the cleaner as less activation button on the tool in the same way.
- Page 19 Description of the wireless activation lamp status Fig.39 ► 1. Wireless activation button 2. Wireless activation lamp The wireless activation lamp shows the status of the wireless activation function. Refer to the below table for the meaning of the lamp status. Status Wireless activation lamp Description...
- Page 20 Before asking for repairs, conduct your own inspection first. If you find a problem that is not explained in the manual, do not attempt to dismantle the tool. Instead, ask Makita Authorized Service Centers, always using Makita replace- ment parts for repairs.
-
Page 21: Maintenance
To maintain product SAFETY and RELIABILITY, repairs, any other maintenance or adjustment should be performed by Makita Authorized or Factory Service Centers, always using Makita replacement parts. Fig.40 ► 1. Multi hook 2. Accessories and attachments not... - Page 22 Pipes (with an optional stopper installed) can be placed Cleaning of powder filter (HEPA) and into the pipe holder when not using the cleaner for a prefilter short time. Clean out the powder filter, prefilter and damper at regular intervals since clogged filters and damper may result in poor suction performance.
-
Page 23: Optional Accessories
OPTIONAL ACCESSORIES CAUTION: These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose. - Page 24 Makita Europe N.V. Jan-Baptist Vinkstraat 2, 3070 Kortenberg, Belgium Makita Corporation 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan 885913-220 www.makita.com 20210615...
