GRAVITY BIN ORGANIZER
TOOLS NEEDED
Phillips
Screwdriver
Upright x 2 (1 left, 1 right)
Crossbeam x 1
Figure 1
PAGE 1 OF 2
1-800-295-5510
uline.com
10mm Wrench
PARTS LIST
Shelf x 8
INSTRUCTIONS
1. Attach the crossbeam to one of the uprights using
3 bolts and 3 locknuts. Make sure that the back
lip of the upright is facing inside. Repeat for the
second upright. (See Figure 1)
Brace x 2 (1 set)
10mm Locknut and Bolt x 48
0714 IH-3892
Advertisement
Table of Contents
Related Manuals for U-Line GRAVITY BIN ORGANIZER
Summary of Contents for U-Line GRAVITY BIN ORGANIZER
- Page 1 π 1-800-295-5510 uline.com GRAVITY BIN ORGANIZER TOOLS NEEDED 10mm Wrench Phillips Screwdriver PARTS LIST Upright x 2 (1 left, 1 right) Shelf x 8 Brace x 2 (1 set) 10mm Locknut and Bolt x 48 Crossbeam x 1 INSTRUCTIONS 1. Attach the crossbeam to one of the uprights using Figure 1 3 bolts and 3 locknuts.
- Page 2 INSTRUCTIONS CONTINUED 2. Attach top shelf to uprights using 2 bolts and Figure 2 2 locknuts on each side. Repeat for remaining 7 shelves. (See Figure 2) 3. Attach 1 brace diagonally to the back of the unit Figure 3 using 2 bolts and 2 locknuts.
