8.3 辅助触头、报警触头
8.3.1 辅助、报警触头接入相应外围控制电路
8.3 Auxiliary contact, alarm contact
8.3.1 Auxiliary and alarm contacts accessed into relative external control circuit/
分类
Category
辅助触头
Auxiliary contact
报警触头
Alarm contact
8.3.2 辅助、报警触头状态指示图
8.3.2 Status indicator diagrams of auxiliary and alarm contacts
附件名称
Accessary Name
辅助触头
Auxiliary contact
报警触头
Alarm contact
8.4 电动操作机构
在外加电源情况下，可通过电动操作机构对断路器进
行合、分操作。
8.4 Motor-operated mechanism
The breaker can be closed and opened by an motor-operated
mechanism in the condition of external power supply.
