CURING LIGHT LED.C
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CURING LIGHT LED.C and is the answer not in the manual?

Questions and answers

Summary of Contents for Guilin Woodpecker Medical Instrument CURING LIGHT LED.C

  • Page 1 CURING LIGHT LED.C USER’S MANUAL...
  • Page 2: Table Of Contents

    Content 1. Introduction ..............1 2. Principle and usage ............. 1 3. Structure and components ........... 1 4. Technical specifications ..........1 5. Instruction of recharging ..........2 6. Operation ..............3 7. Cleaning , Disinfection and Sterilization ..... 4 8.
  • Page 3: Introduction

    1. Introduction Guilin Woodpecker Medical Instrument Co., Ltd. is a high- tech enterprise in researching, developing, and producing dental equipment, and has a perfect quality assurance system, main products including ultrasonic scaler, curing light, micro motor, apex locator and ultrasurgery etc.
  • Page 4: Instruction Of Recharging

    4.4 Working condition: Environment temperature: 5℃ to 40℃ Relative humidity: 30%~75% Atmosphere pressure: 70kPa to 106kPa 4.5 Dimensions: Φ23mm×263mm 4.6 Net weight: 124g 4.7 Consumption power: ≤8W 4.8 Protection type against electrical shock: classⅡ 4.9 Protection against electrical shock: type B 4.10 Protection against harmful ingress of water or particular matter: ordinary equipment (IPX0) 4.11 Safety in the presence of flammable anesthetic mixture...
  • Page 5: Operation

    Picture 1 6. Operation 6.1 Let the cathode of the battery face down to the battery compartment, and tighten it to the main unit (See Picture 1). 6.2 Take off the red cap from the optical fiber and then insert the metal part into the front of LED.C, make sure to screw the fiber to the end.
  • Page 6: Cleaning , Disinfection And Sterilization

    6.6 During the operation, aim blue light at the position needing solidification. Press the ON/OFF switch, the LED starts to work under the selected mode. Then it counts down to “0” second to end the solidification. 6.7 After the operation, please clean the fiber with calico in order not to affect the light intensity.
  • Page 7 cases, the manufacturer takes no responsibility. This device shall not be exposed to high temperature above 138℃. Processing limit The products have been designed for a large number of sterilization cycles. The materials used in manufacture were selected accordingly. However with every renewed preparation for use, thermal and chemical stresses will result in ageing of the products.
  • Page 8 clean tray. Notes a) The water used here must be pure water, distilled water or deionized water. 7.2 Preparation before cleaning Steps Tools: tray, soft brush, clean and dry soft cloth Remove optical fiber from main unit and put it into the clean tray. Use a clean soft brush to carefully brush the optical fiber until the dirt on surface is not visible.
  • Page 9 be distilled water, deionized water or multi-enzyme. But please ensure that the selected cleaning agent is compatible with the product. b) In washing stage, the water temperature should not exceed 45 °C, otherwise the protein will solidify and it would be difficult to remove.
  • Page 10 Dry the product repeatedly if necessary (refer to section “Drying”). Notes a) Before use, you must carefully read the operating instructions provided by the equipment manufacturer to familiarize yourself with the disinfection process and precautions. b) With this equipment, cleaning, disinfection and drying will be carried out together.
  • Page 11 Pharmacopoeia or the United States Pharmacopoeia). f) After cleaning, the chemical residue should be less than 10mg / L. g)The air used for drying must be filtered by HEPA. h) Regularly repair and inspect the disinfector. 7.5 Drying If your cleaning and disinfection process does not have an automatic drying function, dry it after cleaning and disinfection.
  • Page 12 to continue to be used. 7.6.3 Check the product. If the accessories are found to be damaged, please replace it before use. And the new accessories for replacement must be cleaned, disinfected and dried. 7.6.4 If the service time (number of times) of the product reaches the specified service life (number of times), please replace it in time.
  • Page 13 effective steam sterilization was provided by a verified testing laboratory. Notes a) Only products that have been effectively cleaned and disinfected are allowed to be sterilized; b) Before using the sterilizer for sterilization, read the Instruction Manual provided by the equipment manufacturer and follow the instructions.
  • Page 14: Precaution

    Notes: a) The storage environment should be clean and must be disinfected regularly; b) Product storage must be batched and marked and recorded. 7.10 Transportation 1 . P r e v e n t e x c e s s i v e s h o c k a n d v i b r a t i o n d u r i n g transportation, and handle with care;...
  • Page 15: Contraindication

    and Lithium battery, because other brand pedestal charger, adapter and Lithium battery are likely to damage the circuit. 8.5 Please recharge the battery in cool and ventilated room. 8.6 It is forbidden to self-taking apart the battery, in order not to result in short-circuit or leakage.
  • Page 16: Packing List

    12. Packing List The components of the equipment are listed in the packing list. 13. Troubleshooting Faulty Possible cause Solution l. Battery has run down. 1. Charge the LED.C. 2. Battery is fixed upside 2.Refix the battery, pay down. attention to the ends of the Non-indication 3.
  • Page 17: Storage And Transportation

    Faulty Possible cause Solution Indicator light 1.Check the power supply 1.Power supply cord is of pedestal cord and connect it well. not connected well. doesn't shine in 2.Refix the battery, pay 2. Battery is fixed upside the process of attention to the ends of the down.
  • Page 18: Manufacturer's Right

    16. Manufacturer’s right We reserve the rights to change the design of the equipment, the technique, fittings, the instruction manual and the content of the original packing list at any time without notice. If there are some differences between blueprint and real equipment, take the real equipment as the norm.
  • Page 19: Statement

    Atmospheric pressure for storage Appliance compliance WEEE directive Follow Instructions for Use Authorised Representative in the EUROPEAN COMMUNITY 18. Statement All rights of modifying the product are reserved to the manufacturer without further notice. The pictures are only for reference. The final interpretation rights belong to GUILIN WOODPECKER MEDICAL INSTRUMENT CO., LTD.
  • Page 24 ZMN-BZ-263 V3.9-2020804...
