Summary of Contents for Guilin Woodpecker Medical Instrument X-Cure
-
Page 2: Table Of Contents
Content 1. Introduction ..................1 2. Product Performance Structure and Components ......1 3. Basic Technical Specifications ............3 4. Installation and Demounting .............. 4 5. Operation ................... 4 6. Precaution ................... 5 7. Contraindication ................. 6 8. Daily maintenance ................6 9. -
Page 3: Introduction
1. Introduction Guilin Woodpecker Medical Instrument Co., Ltd. is a high-tech enterprise in researching, developing, and producing dental equipment, and has a perfect quality assurance system, main products including ultrasonic scaler, curing light, apex locator and ultrasurgery etc. 1.1 Features... -
Page 5: Basic Technical Specifications
3. Basic Technical Specifications 3.1 Size: 276mm×28mm×30mm 3.2 Net weight: 750g 3.3 The components of machine: see the packing list. 3.4 Adapter: 3.4.1 classified by power supply The power supply by the rechargeable battery. 3.4.2 Rechargeable Lithium battery: Battery model: ICR18490,Battery capacity: 1400mAh Battery has over-voltage, over current and short circuit protection 3.4.3 Adapter(charge) Adapter input: AC100~240V 50Hz/60Hz 0.8AMax... -
Page 6: Installation And Demounting
3.6.2 Protection degree against electrical shock: Type B 3.6.3 Protection against harmful ingress of water or particular matter: ordinary equipment (IPX0),can’t be waterproof. 3.6.4 operation mode: short time run equipment. 3.6.5 Safety in the presence of flammable anesthetic mixture with air, oxygen or nitrous oxide: not suitable under this condition. -
Page 7: Precaution
immediately by short pressing the button. If the main unit gets hot obviously, please turn off the device until the main unit becomes cool. Please don’t make it continuously illuminate more than 10 times. 5.9 Low power detect circuit is fixed inside of the main unit, when low power is detected, the battery symbol on OLED screen become wink, please charge in time. -
Page 8: Contraindication
pedestal, otherwise the battery charging might be failed because of the poor contact. 6.8 Do not disassemble the Lithium battery, it will lead to the circuit short or the electrolyte leakage. 6.9 Do not squeeze, shake and short the battery, do not store the battery with metal material. -
Page 9: Trouble Shooting
designed and supplied by other manufacturers. 8.3 The accessory of the product should be cleaned by clean water or sterilized liquid. Do not soak. 8.4 Please clean the resin remained on the top of the main unit after using to avoid infecting the life-span or solidified effect. 9. -
Page 10: Storage And Transportation
10. Storage and transportation 10.1 The equipment should be handled carefully and lightly, kept away from the shaking source, installed or stored at shadowy, dry, cool and ventilated places. 10.2 Don't store the equipment together with articles that are combustible, poisonous, caustic, and explosive. 10.3 This equipment should be stored in the environment where the humidity is 10%~93%, the atmosphere pressure is 70kPa~106kPa and the temperature is -20℃~55℃. -
Page 11: Emc - Declaration Of Conformity
Guidance and manufacturer’s declaration - electromagnetic emissions The models X-Cure are intended for use in the electromagnetic environment specified below. The customer or the user of the models X-Cure should assure that it is used in such an environment. Emissions test... - Page 12 Guidance & Declaration — electromagnetic immunity The models X-Cure are intended for use in the electromagnetic environment specified below. The customer or the user of the models X-Cure should assure that It is used in such an environment. Electromagnetic IEC 60601 test...
- Page 13 Guidance & Declaration - Electromagnetic immunity The models X-Cure are intended for use in the electromagnetic environment specified below. The customer or the user of the models X-Cure should assure that it is used in such an environment. I m m u n i t y...
-
Page 14: Statement
To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the models X-Cure are used exceeds the applicable RF compliance level above, the model X-Cure should be observed to verify normal operation. -
Page 15: Dental Caries Testing Principle
INSTRUMENT CO., LTD. The industrial design, inner structure, etc, have claimed for several patents by WOODPECKER, any copy or fake product must take legal responsibilities. 17.Dental caries testing principle... - Page 16 ZMN/WI-09-390 V1.4-20190928...
