Preparing For Assembly - Artec Sensor Melody Assembly Instructions Manual

Sensor Melody Light Robot
1
x
1
x
Connect the sensor
connecting cable to
each sensor.
Make sure the cable is inserted correctly!
Reverse Side of LED/Light Sensor/Buzzer
Gray cable Gray cable
Black cable Black cable
Preparing for Assembly Preparing for Assembly
1
x
1
x
Sensor Connecting Cable
Sensor side
1
x
1
x
Reverse Side of Sound Sensor
Gray cable Gray cable
Black cable Black cable
1
x
7
x
Circuit board side
03
