Hose reel pump assembly
85751
85753
December 2012
Date of issue
Form number
404483
Section
A21
Page
9A
D A N G E R
Read manual prior to installation or use
of this product. Keep manual nearby for
future reference. Failure to follow
instructions and safety precautions may
result in death or serious injury.
Assembly, disassembly and
repair guide
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lincoln 85751
Summary of Contents for Lincoln 85751
- Page 1 Assembly, disassembly and repair guide Hose reel pump assembly 85751 85753 December 2012 Date of issue D A N G E R Form number 404483 Read manual prior to installation or use Section of this product. Keep manual nearby for Page future reference.
-
Page 2: Table Of Contents
Explanation of signal words for safety ......... 3 Use of this manual .............. 4 Overview................4 Appropriate use ..............4 General description and information ........4 Operation ................8 Disassembly ............... 9 Assembly ................. 12 Parts and tools ..............16 Lincoln industrial standard warranty ......... 21... -
Page 3: Safety
Safety Explanation of signal words for safety Read and carefully observe these installation instructions before installing, operating or troubleshooting the assembly. The assembly must be installed, maintained and repaired exclusively by persons familiar with the instructions. This is the safety alert symbol. It is used Assemble this equipment only after safety to alert you to potential physical injury instructions and this guide have been read... -
Page 4: Use Of This Manual
Model 85751 is a 24 V DC, 5 gallon, pump. Appropriate use 7:1 ratio FlowMaster II pump. Model 85753... - Page 5 Voltage Pump Follower Connecting Reel, control valve assembly hose and swivel Pump w/ bucket lid and follower 274886 24 V DC 85751 274878 274888 276358 12 V DC 85753 274818 274888 Pump as above with reel, 50 ft. (15 m) 274887...
- Page 6 Fig. 2 Pump dimensions 10.82 8.71 (221) (275) 6.97 5.79 (147) (177) 8.93 (227) 13.74 (349)
- Page 7 Pump installation Pressure switch adjustment Notice The pressure switch is factory set at Refer to the FlowMasterII pump 5,800 psi (400 bar). Pump life will be service sheet for information on the increased by maintaining a lower pump shut pump. Refer to parts list on page 13. off pressure.
-
Page 8: Disassembly
Disassembly Fig. 5 6 Pull out the locking wedge (26) using While the pressure switch will provide years needle nose pliers. of service, in time, components will wear 7 With the connector body (25) removed, out. It is possible to replace the switch pull the boot (24) off of the wire. - Page 9 Inspection 17 Using a small rod or stiff wire 0.093 in. Notice (0,2 cm) or smaller, push the spool While the pressure switch will provide years If the spring and steel plunger are assembly (33) up from the bottom and of service, in time, components will wear serviceable, it is recommended that the remove it from the body.
-
Page 10: Assembly
Assembly Fig. 8 Notice Seat all parts against the bottom of the bore. Failure to comply may result in equipment damage. Notice Prior to starting assembly perform inspection of all parts. Lightly coat rubbing surfaces of spool (33) and ball (19) as well as both o-ring seals with a good quality NLGI grease to Notice ease assembly. - Page 11 Troubleshooting Condition Possible cause Corrective action Pump does not run. Pump is seized or damaged. Refer to applicable pump manual. Incorrectly wired. Refer to applicable pump manual and check wiring diagram. Pump speeds up or runs erratically. Low level of grease or reservoir Fill reservoir.
-
Page 12: Parts And Tools
Parts and tools Tool and consumable list in. open end wrench in. open end wrench in. open end wrench 12 in. adjustable wrench in. hex head wrench in. hex head wrench in. hex head wrench in. hex head wrench in. hex head wrench in. - Page 13 Cord grip 273169 Hex head screw, -20 x 50169 Connector pins 274629 Pump assembly Model Voltage Bare pump Service page section 85751 24 V DC 85750 Section C8 page 364 series 85753 12 V DC 85752 Section C8 page 365 series...
- Page 14 Fig. IPB 1 14 13...
- Page 15 Fig. IPB 2 Pressure switch assembly 274630...
- Page 16 Fig. IPB 3 Lid assembly 274878...
-
Page 17: Lincoln Industrial Standard Warranty
Hemisphere or East Asia: Please contact Lincoln warrants the equipment manufac- Lincoln GmbH and Co. Kg, Walldorf, tured and supplied by Lincoln to be free from Germany, for your warranty rights. defects in material and workmanship for a period of one (1) year following the date of... - Page 18 A global presence provides SKF customers uniform quality standards and worldwide product availability. ® SKF is a registered trademark of the SKF Group. ® Lincoln is a registered trademark of Lincoln Industrial Corp. ™ FlowMaster II is a trademark of Lincoln Industrial Corp.
