IL50 L/R
PORT TUBE,
336805-001
See page 12
SCREW, (10)
#8X.75" PB PPH BLK
900101-012
AMPLIFIER,
NOT FOR SALE
NETWORK,
336476-001
TRIM
RING,
336162-001
GRILLE CUP, (3)
333249-003
SCREW, (3)
#8X1" PB PPH BLK
900101-016
GRILLE, WOOFER,
Part of Set - See
Upper Grille Options
Exploded View
CABINET,
IL50
(NOT FOR SALE)
GRILLE CUP, (7)
333249-003
WOOFER,
335808-001
SCREW, (3)
#8X.75" PB PPH BLK
900101-012
SPIKE (4),
331360-001
SCREW, (4)
#6X.75" PB PPH BLK
903401-012
(ROTATED)
TRANSDUCER,
SCREW, (6)
#6X.75" PB PPH BLK
GRILLE CUP, (6)
SCREW, (6)
BUMP-ON (4),
#8X.75" PB PPH BLK
330104-001
900101-012
13
SCREW, (4)
6-19X.375 MS PPH BLK
905401-006
VOLUME CONTROL
ASS'Y w/CABLE,
336250-001, R
336250-002, L
SCREW, (6)
MID RANGE
#6X.75" PB PPH BLK
903401-012
335741-001
SCREW, (4)
8-18X.5ZINK MS PPH BLK
903401-012
333249-003
GRILLE, BLACK, LEFT 335612-072
GRILLE, BLACK, RIGHT 335612-071
GRILLE, MIDNIGHT BLUE, LEFT 335612-052
GRILLE, MIDNIGHT BLUE, RIGHT 335612-051
GRILLE, RICH BURGUNDY, LEFT 335612-062
GRILLE, RICH BURGUNDY, RIGHT 335612-061
GRILLE, GRAY, LEFT 335612-042
GRILLE, GRAY, RIGHT 335612-041
PEDESTAL,
336256-001
SCREW, (2)
#8X.75" PB PPH BLK
900101-012
905802-008
TWEETER,
335225-002
BAFFLE,
336163-001, R
336163-002, L
