Infinity Interlude IL30 Technical Manual

Technical Manual
Interlude IL30
ACOUSTIC & ELECTRICAL SPECIFICATIONS:
Nominal Impedance:
l
Max Amp Power
l
Frequency Response
l
Sensitivity:
l
Crossover Frequency:
l

SYSTEM COMPONENTS:

Cabinet
l
Grille, (Platinum)
l
Low-Frequency Transducer:
l
DC Resistance
High-Frequency Transducer:
l
DC Resistance
Crossover Network
l

PACKING

Infinity Systems, Inc. 250 Crossways Park Dr., Woodbury, New York 11797
89
150 watts*
48 Hz - 22,000Hz (E3dB)
88dB (2.83V @ 1 meter)
2800Hz; 24dB/octave
IL30 (Not for Sale)
335827-001
6-1/2" (165mm) C.M.M.D.,
shielded (335741-001)
4.5 ohms E10%
1" (25mm) C.M.M.D.,
shielded (335225-003)
3.5 ohms E10%
336023-001
AURAL SWEEP TEST SPECIFICATIONS:
System Aural Sweep Test
l
L.F. Aural Sweep Test
l
H.F. Aural Sweep Test
l
PHYSICAL SPECIFICATIONS:
Enclosure dimensions:
l
Weight
l
WARRANTY:
Refer to Warranty Statement packed with each product.
l
* The maximum recommended amplifier power rating will
ensure proper system headroom to allow for occasional peaks.
We do not recommend sustained operation at these maximum
power levels.

WIRING DIAGRAM

NETWORK, IL30
336023-001
IL30 SCHEMATIC
L1
2.0mH
+IN
-IN
C2
2.4 F
100V
+IN
L2
0.20mH
-IN
6.0V Input 40 Hz to 22 kHz
5.0V Input 40 Hz to 3 kHz
2.83V Input 2 kHz to 22 kHz
36" x 8-1/2" x 8-3/4"
(914mm x 216mm x 222mm)
34 lbs (15.5 kg) Each
HIGH FREQUENCY
TRANSDUCER
335225-003
+ -
YEL
YEL/BLK
GRN
GRN/BLK
LOW FREQUENCY
TRANSDUCER
335741-001
GRN
C1
10.0 F
100V
GRN/BLK
L3
C3 0.07mH
11.0 F
100V
YEL
R1
6.50 ohm
10W
YEL/BLK
Rev1 04/03
+
L.F.
-
+
H.F.
-
