Twinkly Lumations Generation II Instruction Manual

Smart led light strings, wrapped dome straight lights

Advertisement

smart LED light strings
Wrapped Dome Straight Lights
INSTRUCTIONS GUIDE
FOR INDOOR AND OUTDOOR USE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lumations Generation II and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Twinkly Lumations Generation II

  • Page 1 smart LED light strings Wrapped Dome Straight Lights INSTRUCTIONS GUIDE FOR INDOOR AND OUTDOOR USE...
  • Page 2 warning READ AND KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE IMPORTANT SAFETY INSTRUCTIONS When using electrical products, basic precautions should always be followed including the following: READ AND FOLLOW ALL SAFETY INSTRUCTIONS. 1. Do not use seasonal products outdoors unless marked suitable for indoor and outdoor use. When used outdoors, this product must be connected to a Ground Fault Circuit Interrupting (GFCI) outlet.
  • Page 3 2. Make sure connectors are fully inserted and secured. Twist all connector rings until hand tight. 3. Some Twinkly light sets (models dependable) allow multiple strings setup. To avoid the risk of fire or personal injury, do NOT exceed the maximum wattage capacity of adapter.
  • Page 4 Technical Specifications Rated Wattage Total Wattage Maxlmum Maximum Light Strings Light Description AC Adapter of Light String of Light String Wattage Capacity can be Connected Counts Color (Amps) and Adapter of Adapter (Same model) USA / Canada Version Input:120 V~ / 60 Hz, 0.45 A 5.3 W (220 mA) 8.5 W 26 W (1.08 A)
  • Page 5 Rated Wattage Total Wattage Maxlmum Maximum Light Strings Light Description AC Adapter of Light String of Light String Wattage Capacity can be Connected Counts Color (Amps) and Adapter of Adapter (Same model) USA / Canada Version Input:120 V~ / 60 Hz, 0.45 A 4.4 W (185 mA) 7.4 W 26 W (1.08 A)
  • Page 6 Add-on Connector * Product outlook varies by models. Add-on Connector only available in specific models. 1. Connect the Twinkly light string to the power adapter. 2. Plug the power adapter into a power socket and the lights will switch on.
  • Page 7 multiple strings setup * Images for reference only Open the cap 1. Refer to the "Maximum Light Strings can be Connected" column in the Technical Specifications table to confirm if your light set model allows multiple strings setup. Do not attempt multiple light strings setup if N/A is marked.
  • Page 8 controller BUTTON • CONTINUOUS GREEN: Direct Wi-Fi mode, connected • FLASHING GREEN: Direct Wi-Fi mode, no device connected • CONTINUOUS BLUE: Home Wi-Fi network mode, connected LED INDICATOR • FLASHING BLUE: Home Wi-Fi network mode, connection in progress • FLASHING RED: Home Wi-Fi network mode, unable to connect •...
  • Page 9: Preset Effects

    GLOW Light arrangements vary by models Twinkly comes with 5 preset effects that may be used without downloading the app. Simply plug in the light string to a power outlet, then press the button on the controller to switch between the 5 preset effects.
  • Page 10 Generation I Generation II 1. Go to App Store/Google Play Store (or scan QR code).  2. Download and install the Twinkly app. 3. Launch Twinkly app. 4. Select GENERATION II controller for your lights. Follow the setup process on the app.
  • Page 11: Connection Modes

    Connecting... A. HOME WI-FI NETWORK CONNECTION B. DIRECT Wi-Fi CONNECTION Twinkly uses Bluetooth for the setup process only. Wi-Fi connection is required for operation. You can use: A. Home Wi-Fi network connection (recommended): Connect with your home/office WiFi from the list of available networks.
  • Page 12 Mapping complete MAPPING Map the layout of your decoration to unlock the full potential of your Twinkly lights like advanced effects, drawing and many upcoming features.
  • Page 13 mapping tips Note: For best results, avoid reflective surfaces behind the tree, keep the mobile camera steady during the process and ensure a moderate ambient light (not too dark).
  • Page 14: Online Manual

    online manual Browse, play and edit effects Gallery Create new effects Group multiple devices together Download new effects...
  • Page 15 A P P L Y 1. Open the Effects Gallery. 2. Select the desired effect to see the real-time preview on your Twinkly set-up. 3. Swipe left or right to browse effect. 4. Tap “Apply” to store the effect and play continuously.
  • Page 16: Troubleshooting

    • Check that the LED status indicator on the controller is lit • If this does not work, stop the Twinkly application and launch it again • • If this does not work, try to Reset (see Reset procedure below) •...
  • Page 17 1. Unplug Twinkly from the power socket. Press and hold the controller button. 2. While holding the button, plug in Twinkly. 3. Keep holding the button until all LEDs turn red, then release the button.
  • Page 18 Polygroup Trading Limited ® To know more about your twinkly and its other cool features, please visit: Unit 606, 6th Floor, Fairmont House, No.8 Cotton Tree Drive, Central, Hong Kong www.polygroup.com/twinkly...
  • Page 19: Important Note

    FCC Caution: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 20 ISEDC Warning This device complies with Innovation, Science, and Economic Development Canada licence- exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
