- Page 1 HOT WATER MODULE (MULTI TYPE) Owner’s Manual R410A For commercial use Indoor Unit Model name: <Mid temperature Hot Water Module> MMW-UP0271LQ-E MMW-UP0561LQ-E English...
-
Page 2: Table Of Contents
Contents Original instruction Thank you very much for purchasing TOSHIBA Hot Water Module. Please read this owner’s manual carefully before using your Hot Water Module. 1 Precautions for safety ..........3 •... - Page 3 (including the hot water modules) made by Toshiba Carrier Corporation or, alternatively, he or she has been instructed in such matters by an individual or individuals who have been trained and is thus thoroughly acquainted with the knowledge...
-
Page 4: Precautions For Safety
– 3 – Precautions for safety • Be sure to use the company-specified products for the separately purchased parts. Use of non-specified products may result in fire, The manufacturer shall not assume any liability for the damage caused electric shock, water leakage, etc. Have the installation performed by by not observing the description of this manual. - Page 5 contact a qualified service person. Take steps to ensure that the CAUTION power will not be turned on (by marking “out of service” near the To disconnect the appliance form the main supply circuit breaker, for instance) until qualified service person arrives. •...
- Page 6 – 5 – • Ask for cleaning of the hot water module to be performed by the Information on the transportation, handling and storage of the dealer. carton Cleaning the hot water module in an improper manner may cause insulation failure of electric parts, etc.
-
Page 7: Part Names
Part names Display section All icons on the display are shown for this explanation. Icons related to heating do not appear for cooling only models. Operations are not accepted when “ ” is flashing. Hot water module Electrical control box Water outlet Earth screw Equipped on the electrical... - Page 8 – 7 – 3-2. Wired remote controller (RBC-AMSU51- ) Switching between the normal display and detailed display Push and hold the [ CANCEL] button and [ MONITOR] button at the same time for more than 4 seconds Refer to Owner’s Manual of RBC-AMSU51- for the detailed operation method.
-
Page 9: Basic Operation
Basic operation OFF timer operation Follow the following steps when you use the hot water module or change settings first time. OFF timer: the indoor unit stops running when the set time is reached. From the next time, the hot water module can operate at selected settings only by pressing ON/OFF button. ... -
Page 10: Installation
– 9 – Installation Notes on operations and performance Location Check before operation The protective device may activate in the following cases: • Hot water module is allowed to install indoors. • Turn on the power switch at least 12 hours before starting operation. -
Page 11: Maintenance
Maintenance <Connecting to SHRM-e> • If the Standard indoor unit is used at outside temperature out of the operating conditions, safety Before the operating season WARNING protection may operate, which may cause cooling or heating not to operate. Ask a qualified service person to clean the drain For daily maintenance, make sure to ask the At that time, “... -
Page 12: Troubleshooting
– 11 – Troubleshooting CAUTION When the following symptoms are found, check the points described below before asking repair servicing. If any of the following conditions occur, turn off the main power supply switch and immediately contact the dealer: • Switch operation does not work properly. Abnormal phenomenon Cause •... -
Page 13: Specifications
If a problem occurs with the air Sound pressure level (dBA) conditioner (including Hot water Model Weight (kg) Main unit Heating module), the OFF timer indicator MMW-UP0271LQ-E 17.8 alternately shows the check code and MMW-UP0561LQ-E 20.3 the indoor Unit No. in which the problem occurred. - Page 14 – 13 – Declaration of Conformity Manufacturer: TOSHIBA CARRIER CORPORATION 336 Tadehara, Fuji-shi, Shizuoka-ken 416-8521 JAPAN TCF holder: TOSHIBA CARRIER EUROPE S.A.S Route de Thil 01120 Montluel FRANCE Hereby declares that the machinery described below: Generic Denomination: Hot Water Module...
