Vendlet Standard Quick Manual

VENDLET
Reset*
Standard

THE USE

1. Elevate the bed to the right working height.
2. Double-click the button to activate the VENDLET system. The VENDLET
system produces an acoustic signal and the green diode over the power
symbol turns on. When the hand control has been inactive for 90 seconds,
the system is off again.
3. The patient is repositioned by operating the hand control.
Tighten the sheet on
the red bar
Slacken the sheet
on the red bar
Raise
the red bar
Lower
the red bar
Speed Adjustment
The The button works button works
as a stop button as a stop button
4. If it is estimated that the bedridden must use side rails, raise the bars.
Slacken the sheet.
5. If it is estimated that the bedridden should not use side rails, lower the bars.
Slacken the sheet.
Always, keep focus on the client when using VENDLET.
* If the hand control is flashing, reset the system by simultaneously pressing
the two top buttons on the hand control. You will hear 10 rhythmic beeps.
Press and hold the buttons until the beeping stops.
VENDLET must be used
and installed in accordance
with the manual
+45 9631 0050
QUICK GUIDE
Reset*
Scan the QR
code to watch
instruction
videos
vendlet@vendlet.dk
Tighten the sheet on
the blue bar
Slacken the sheet
on the blue bar
Raise
the blue bar
Lower
the blue bar
Flash light
Power w.
illuminated diode/
stop
www.vendlet.dk
