Summary of Contents for Walker Edison BU60BALWM

  • Page 2: General Assembly Guidelines

    Concealed hinges are three-way adjustable. Horizontal In-and-Out Vertical by screw adjustment by loosening the hinge-arm Via slots in the mounting mounting screw or via cam plate or via cam adjustment adjustment © Copyright 2020, by Walker Edison Furniture Co., LLC. All rights reserved.
  • Page 6 Insert wooden dowel (A) into parts (4,5,12,13,14,22) as per diagram.
  • Page 7 Insert wooden dowel (A) into part (3), secure cam bolt (D) into parts (1,3,4,5) with Philips head screwdriver as per diagram.
  • Page 8 Pick up the slider arm (Z) and separate the slide Runner for the following Steps. Extend the Slide .Runner all the way forward,press the plastic release lever of the alider arm up and pull the Slide Runner Complete out .
  • Page 9 Using screw (L) attach part (Z) into parts (4,5) with Philips head screwdriver as per diagram.
  • Page 10 Using screw (L) attach part (Z) into parts (12) , then using screw (L) attach part (Z) into parts (18,19) with Philips head screwdriver as per diagram.
  • Page 11 Using bolt (E) attach part (3) into part (12) with hex key (F) as per diagram.
  • Page 12 Using cam lock(C) secure parts (4,14) to part (3) with Philips head screwdriver as per diagram.
  • Page 13 Using cam lock(C) secure parts (5,13) to part (3) with Philips head screwdriver as per diagram.
  • Page 14 Step 9 Put part (15) as per diagram. © Copyright 2020 b Walker Edison Furniture Co., LLC. All rights reserved. P.14...
  • Page 15 Step 10 Using bolt (E) attach part (2) into parts (4,5,13,14) with hex key (F) as per diagram. © Copyright 2020, by Walker Edison Furniture Co., LLC. All rights reserved. P.15...
  • Page 16 Step 11 Using bolt (G) attach part (24) into part (23) with hex key (F) as per diagram. © Copyright 2020, by Walker Edison Furniture Co., LLC. All rights reserved. P.16...
  • Page 17 Step 12 Using bolt (H) attach parts (23,24) into part (2) with hex key (F) as per diagram. © Copyright 2020, by Walker Edison Furniture Co., LLC. All rights reserved. P.17...
  • Page 18 Step 13 Put part (16) as per diagram. © Copyright 2020 b Walker Edison Furniture Co., LLC. All rights reserved. P.18...
  • Page 19 Step 14 Using cam lock (C) secure part (1) into parts (4,5,12) with Philips head screwdriver as per diagram. © P.19 Copyright 2020, by Walker Edison Furniture Co., LLC. All rights reserved.
  • Page 20 Step 15 Using screw (S) secure plastic wedge (R) with Philips head screwdriver as per diagram. © P.20 Copyright 2020, by Walker Edison Furniture Co., LLC. All rights reserved.
  • Page 21 Using screw (L) attach handle (U) to part (17) with Philips head screwdriver as per diagram.
  • Page 22 Step 17 Using screw (M) attach parts (18,19) to part (20) with Philips head screwdriver as per diagram. © P.22 Copyright 2020 b Walker Edison Furniture Co., LLC. All rights reserved.
  • Page 23 Step 18 Put part (21) as per diagram. © P.23 Copyright 2020, by Walker Edison Furniture Co., LLC. All rights reserved.
  • Page 24 Using screw (M) secure part (20) to part (22) with Philips head screwdriver as per diagram.
  • Page 25 Using cam lock (B) secure part (17) to parts (18,19) , then using cam lock (C) secure part (17) to part (22) with Philips head screwdriver as per diagram.
  • Page 26 Step 21 Place sticker (Q) cover the holes as per diagram . © P.26 Copyright 2020 b Walker Edison Furniture Co., LLC. All rights reserved.
  • Page 27 © P.27 Copyright 2020 b Walker Edison Furniture Co., LLC. All rights reserved.
  • Page 28 (N,P) in the same level. So the shelf is not titled .Put parts (6,7,8) into unit as per diagram.Tilt and rest the adjustable shelf (6,7,8) onto the shelf support pins . © P.28 Copyright 2020 b Walker Edison Furniture Co., LLC. All rights reserved.
  • Page 29 Using screw (K) attach Europe hinge (J) into parts (9,10,11) ,then using screw (L) attach handle (U) to parts (9,10,11) with Philips head screwdriver as per diagram. © P.29 Copyright 2020 b Walker Edison Furniture Co., LLC. All rights reserved.
  • Page 30 Using screw (K) attach Europe hinge (J) into parts (4,5,14) with Philips head screwdriver as per diagram. Open and close the doors ,if necessary adjust the screws for a good fit. © P.30 Copyright 2020 b Walker Edison Furniture Co., LLC. All rights reserved.
  • Page 31 Step 26 Position the assembled unit at the desired location ,if necessary adjust the floor leveler at the bottom of the legs to level the unit . © P.31 Copyright 2020 b Walker Edison Furniture Co., LLC. All rights reserved.
  • Page 32 Step 27 Using screw (V) attach Velcro strap (X) into part (1) with Philips head screwdriver as per diagram. © P.32 Copyright 2020 b Walker Edison Furniture Co., LLC. All rights reserved.
  • Page 33 Wall Using screw (W) attach Velcro strap (X) into Nut (Y) to wall with Philips head screwdriver as per diagram. © P.33 Copyright 2020, by Walker Edison Furniture Co., LLC. All rights reserved.
  • Page 34 Step 29 Final Assembly © P.34 Copyright 2020, by Walker Edison Furniture Co., LLC. All rights reserved.
