- Page 1 Item # : BU48RAD3D Assembly Instructions Please visit our website for the most current instructions, assembly tips, report damage, or request parts. www.walkeredison.com Walker Edison Revised 24/05/2019 (E) ® © Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved.
-
Page 2: General Assembly Guidelines
Concealed hinges are three-way adjustable. Horizontal In-and-Out Vertical by screw adjustment by loosening the hinge-arm Via slots in the mounting mounting screw or via cam plate or via cam adjustment adjustment © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. -
Page 3: Parts List
Parts List © Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. -
Page 4: Hardware List
Glue tube Philips head screwdriver required for assembly (not included) The hardware quantities listed above are required for proper assembly. Some extra hardware may also have been included. © Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. - Page 5 Step 1 Insert wooden dowel (A) into parts (2,3),using cam bolt (C) secure part (2) with Philips head screwdriver as per diagram. © Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved.
- Page 6 Step 2 Insert wooden dowel (A) into parts (8,9),using cam bolt (C) secure parts (5,6) with Philips head screwdriver as per diagram. © Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved.
- Page 7 Step 3 Using cam lock (B) secure part (8) to part (2) with Philips head screwdriver as per diagram. © Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved.
- Page 8 Step 4 Using cam lock (B) secure part (9) to part (2) with Philips head screwdriver as per diagram. © Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved.
- Page 9 Step 5 Insert part (13) into parts (2,8,9) as per diagram. © Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved.
- Page 10 Step 6 Using bolt (E) secure part (3) into parts (8,9) with hex key (F) as per diagram. © Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.10...
- Page 11 Step 7 Insert part (14) into parts (2,3) as per diagram. © Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.11...
- Page 12 Step 8 Using cam lock (B) secure parts (2,3) into part (5) with Philips head screwdriver as per diagram. © Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.12...
- Page 13 Step 9 Using bolt (G) secure part (4,7) into part (5) with hex key (F) as per diagram. © Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.13...
- Page 14 Using bolt (G) and cam lock (C) secure part (4,7) into parts (2,3,6) ,and using bolt (H) secure part (7) to part (3) with hex key (F) as per diagram. © Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.14...
- Page 15 Step 11 Using bolt (H) secure part (1) to parts (4,5,6) with hex key (F) as per diagram. © Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.15...
- Page 16 Step 12 Using screw (M) secure plastic wedge (N) with Philips head screwdriver as per diagram. © Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.16...
- Page 17 Step 13 Put sticker (D) cover the holes as per diagram. © Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.17...
- Page 18 Step 14 Insert shelf support pin into parts (5,6,8,9) as per diagram. © Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.18...
- Page 19 Step 15 Put parts (11,12) as per diagram. © Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.19...
- Page 20 Using screw (R) secure west hinge (P) to part (15) , using bolt (K) secure part (15) to handle (L) with Philips head screwdriver as per diagram. © Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.20...
- Page 21 Step 17 Using screw (R) secure west hinge (Q) to part (16) ,using bolt (K) secure part (16) to handle (L) with Philips head screwdriver as per diagram. © Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.21...
- Page 22 Step 18 Using screw (R) secure west hinge (Q) to parts (6,16) with Philips head screwdriver as per diagram. © Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.22...
- Page 23 Step 19 Using screw (R) secure west hinge (P) to parts (9,15) with Philips head screwdriver as per diagram. © Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.23...
- Page 24 Step 20 Using screw (R) secure west hinge (Q) to parts (5,16) with Philips head screwdriver as per diagram. © Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.24...
- Page 25 Step 21 By adjusting the feet, ensure that the table is on the same level. © Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.25...
- Page 26 Step 22 Using screw (S) secure plastic strap (U) into part (2) with Philips head screwdriver as per diagram. © Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.26...
- Page 27 Wall Using screw (T) secure plastic strap (U) and nut (V) into wall with Philips head screwdriver as per diagram. © Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.27...
-
Page 28: Final Assembly
Step 24 Final Assembly © Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.28...
