- Page 1 Item # : BU36LENBC Assembly Instructions Please visit our website for the most current instructions, assembly tips, report damage, Revised 31/07/2019(L） Walker Edison or request parts. www.walkeredison.com ® © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
-
Page 2: General Assembly Guidelines
A Phillips head screwdriver is required for the assembly of this product . VII. Power tools should not be used to assemble this product. VIII. Drill may be needed for securing product to wall. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. -
Page 3: Parts List
Parts List © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. -
Page 4: Hardware List
Glue tube Philips head screwdriver required for assembly (not included) The hardware quantities listed above are required for proper assembly. Some extra hardware may also have been included. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. - Page 5 Step 1 Using screw (M) attach part (17) into part (1) with Philips head screwdriver as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
- Page 6 Step 2 Secure cam bolt(B) to part (1) with Philips head screwdriver as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
- Page 7 Step 3 Insert wooden dowel (A) into parts (3,4,5) , secure cam bolt (B) to parts (3,4,6,8) with Philips head screwdriver as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
- Page 8 Step 4 Using cam lock(C) secure part (6) to parts (3,5) ,part (8) to part (4) with Philips head screwdriver as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
- Page 9 Step 5 Insert wooden dowel (A) into parts (10,12,13) as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
- Page 10 Step 6 Using screw (J) attach part (13) into parts (2,12) with Philips head screwdriver as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. P.10...
- Page 11 Step 7 Using cam lock(C) secure parts (10,12) to part (3) with Philips head screwdriver as per diagram. Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. P.11 ©...
- Page 12 Step 8 Using cam lock(C) secure part (4) to parts (10,12) with Philips head screwdriver as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. P.12...
- Page 13 Step 9 Using bolt (E) attach part (2) into parts (3,4,5) with hex key (F) as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. P.13...
- Page 14 Step 10 Using bolt (H) secure plastic wedge (G) to parts (14,15,16) with hex key (F) as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. P.14...
- Page 15 Step 11 Using bolt (H) secure plastic wedge (G) on parts (14,15) to part (16) with hex key (F) as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. P.15...
- Page 16 Step 12 Using bolt (H) attach plastic wedge (G) on parts (14,15,16) to part (2) with hex key (F) as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. P.16...
- Page 17 Step 13 Put part (7) into parts (2,3,4,5) as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. P.17...
- Page 18 Step 14 Using cam lock(C) secure part (1) to parts (3,4,5) with Philips head screwdriver as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. P.18...
- Page 19 Step 15 Place sticker (D) cover the holes as per diagram . © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. P.19...
- Page 20 Using screw (S) attach parts (R)and (Q) into part (9) ,then using handle bolt (L) attach handle (K) into part (9) with Philips head screwdriver as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. P.20...
- Page 21 (T) in the same level. So the shelf is not titled .Put part (11) into unit as per diagram. Tilt and rest the adjustable shelf (11) onto the shelf support pins . © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. P.21...
- Page 22 Pick up the door (9), and fit the pulley (R) over the slider rails on the bottom panel (2) ,then place the pulley (Q) into top panel (1) , till it click into pulley (R) as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. P.22...
- Page 23 Step 19 Using screw (P) secure plastic wedge (N) to part (7) with Philips head screwdriver as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. P.23...
- Page 24 Step 20 Using screw (X) attach velcro strap (U) into part (1) with Philips head screwdriver as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. P.24...
- Page 25 Wall Using screw (V) attach Velcro strap (U) into plug (W) to wall with Philips head screwdriver as per diagram. Copyright 2019 by Walker Edison Furniture Co., LLC. All rights reserved. P.25 ©...
- Page 26 Step 22 Final Assembly © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. P.26...
