- Page 1 Factory Mount Mirror Monitor with License Plate Camera (USA size) User Manual...
-
Page 2: Box Contents
Factory Mount Mirror Monitor with License Plate Camera (USA) Introduction Thank you for purchasing your EchoMaster automotive monitor. Your monitor displays a clear, high resolution image of the area surrounding your vehicle, meaning your maneuvring and vehicle awareness will be greatly improved. -
Page 3: Fitting Instructions
Installation Guide MRC-LP01CP Factory Mount Mirror Monitor with License Plate Camera (USA) Fitting Instructions Choose a mounting location that will not obscure the driver’s view. Also please ensure that the unit is not mounted in a location that will obstruct the operation of any airbags. - Page 4 Installation Guide MRC-LP01CP Factory Mount Mirror Monitor with License Plate Camera (USA) Fitting Instructions - (continued) Attaching the camera to bracket NOTE: The triangular notch on the top of the camera indicates top of the camera Installation (Honda, Acura, Subaru, Scion)
- Page 5 Installation Guide MRC-LP01CP Factory Mount Mirror Monitor with License Plate Camera (USA) Adaptor Installation Installation (Volkswagen, Audi) Remove original mirror Slide Factory mirror down, toward the Remove the mirror. bottom of the windsheild email - support@aampglobal.com (US) tel - 1-800-477-2267 (US)
- Page 6 Installation Guide MRC-LP01CP Factory Mount Mirror Monitor with License Plate Camera (USA) Installation (Volkswagen, Audi) Adaptor Installation email - support@aampglobal.com (US) tel - 1-800-477-2267 (US) email - technical.eu@aampglobal.com (Europe)
- Page 7 Installation Guide MRC-LP01CP Factory Mount Mirror Monitor with License Plate Camera (USA) Installation (Jeep, Dodge, Chrysler, RAM) Remove original mirror Carefully pull top of the shroud Carefully pull shroud down toward the sides of the vehicle, (away from windscreen) on both sides.
- Page 8 Installation Guide MRC-LP01CP Factory Mount Mirror Monitor with License Plate Camera (USA) Operating Instructions 1. While using the Video 1 Input, you can press the Power button to turn the monitor ON/OFF 2. While using the Video 2 Input (Backup Camera), you can press the Power button for 1.5 seconds to turn the monitor ON/OFF, or use a short press...
-
Page 9: Wiring Diagram
Installation Guide MRC-LP01CP Factory Mount Mirror Monitor with License Plate Camera (USA) Wiring Diagram email - support@aampglobal.com (US) tel - 1-800-477-2267 (Florida) - 1-888-883-2760 (California) email - technical.eu@aampglobal.com (Europe) -
Page 10: Specifications
Installation Guide MRC-LP01CP Factory Mount Mirror Monitor with License Plate Camera (USA) Specifications Camera Sensor Type 1/3” CMOS LEDs Illumination 0.1 LUX Viewing Angle 170 degrees Mirror Image Normal Image Water/Debris-Proof IP68 Parking Lines Selectable Audio Power Supply 12V DC Current <50mA... - Page 11 Installation Guide MRC-LP01CP Factory Mount Mirror Monitor with License Plate Camera (USA) Mirror Monitor Screen Size 4.3” Aspect Ratio 16:9 Power Supply 12VDC Resolution 480x272 Luminance 1000 Contrast 500:1 TV Format Auto OSD Languages English Video Inputs Audio Inputs Triggers...
- Page 12 15500 Lightwave Drive, Suite 202, Clearwater, Florida 33760 Woolmer Way, Bordon, Hampshire, United Kingdom email - support@aampglobal.com (US) tel - 1-800-477-2267 (Florida) - 1-888-883-2760 (California) email - technical.eu@aampglobal.com (Europe) Echomaster is a brand of AAMP Global. www.echomaster.com REV 250717...
